Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
41
14SL30
21SL40, 21SL70
PWB-A: DUNTK9432WEV2 (14SL30)
PWB-A: DUNTK9432WEV6 (21SL40/70)
CRT UNIT
TRANSISTORS
Q852 VS2SC2229O/1E J 2SC2229O AD
Q854 VS2SC2229O/1E J 2SC2229O AD
Q856 VS2SC2229O/1E J 2SC2229O AD
Q881 VS2SA1266-Y-1 J 2SA1266(Y) AA
or
VS2SA1015-Y-1
DIODES
You can substitute "RH-DX0045GEZZ" and "VHD-DX0446CEZZ" for
"VHD1SS119//-1".
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D885 VHD1SS119//-1 J Diode AB
COIL
L851 VP-DF151K0000 J Peaking 150µH AB
CAPACITORS
[EL.··· Electrolytic]
C851 VCKYPA1HB271K J 270p 50V Ceramic AA
C852 VCKYPA1HB271K J 270p 50V Ceramic AA
C853 VCKYPA1HB271K J 270p 50V Ceramic AA
C854 RC-KZ0016CEZZ J 0.01 1.4kV Ceramic AC
C881 VCEA0A1CW106M J 10 16V EL. AB
C883 VCEA0A1CW336M J 33 16V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
(21SL40/70)
R852 VRD-RA2BE271J J 270 1/8W Carbon AA
(14SL30)
R852 VRD-RA2BE221J J 220 /8W Carbon AA
(21SL40/70)
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
R854 VRD-RA2BE470J J 47 1/8W Carbon AA
(14SL30)
R855 VRD-RA2BE470J J 47 1/8W Carbon AA
(14SL30)
å R857 VRS-VV3AB123J J 12k 1W M-Ox. AA
R858 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE271J J 270 1/8W Carbon AA
(14SL30)
R860 VRD-RA2BE221J J 220 1/8W Carbon AA
(21SL40/70)
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
å R865 VRS-VV3AB123J J 12k 1W M-Ox. AA
R866 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
(21SL40/70)
R868 VRD-RA2BE271M J 270 1/8W Carbon AA
(14SL30)
R868 VRD-RA2BE221J J 220 1/8W Carbon AA
(21SL40/70)
R869 VRD-RA2BE121M J 120 1/8W Carbon AA
å R873 VRS-VV3AB123M J 12k 1W M-Ox. AA
R874 VRD-RM2HD332M J 3.3k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R882 VRD-RA2BE391J J 390 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R885 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0561CEZZ J Plug, 5-pin (GBN) AB
P852 QPLGN0461CEZZ J Plug, 4-pin (YBN) AB
SC851 QSOCV0842CEZZ J CRT Socket (14SL30) AH
SC851 QSOCV0933CEZZ J CRT Socket (21SL40/70) AH
MISCELLANEOUS PARTS
J1001 QJAKE0108CEZZ J Jack, Video in AC
J1002 QJAKE0183CEZZ J Jack, Audio in AE
(14SL30, 21SL40)
J1002 QJAKE0183CEZZ J Jack, Audio in (L) AE
(21SL70)
J1003 QJAKE0184CEZZ J Jack, Audio in (R) AE
(21SL70)
P1001 QPLGN0461CEZZ J Plug, 4-pin (D) (21SL40) AB
P1001 QPLGN0661CEZZ J Plug, 6-pin (D) (21SL70) AD
P1002 QPLGN0461CEZZ J Plug, 4-pin (E) AB
(14SL30, 21SL40)
P1002 QPLGN0661CEZZ J Plug, 6-pin (E) (21SL70) AD
PWB-C: DUNTK9883WEV0(14SL30)
PWB-C: DUNTK9883WEV1(21SL40)
PWB-C: DUNTK9883WEV2(21SL70)
FRONT AV UNIT
