EEPROM ITEMS OSD DATA LENGTH
INITIAL DATA
FIX/ADJ REMARK
AGC TAKE OVER POINT AGC 0~63 14 ADJ
VERTICAL SLOPE V-LIN 0~63 32 ADJ
VERTICAL AMPLITUDE V-AMP 0~63 32 ADJ
VERTICAL SHIFT V-CENT 0~63 32 ADJ
HORIZONTAL SHIFT H-CENT 0~63 32 ADJ
S-CORRECTION S-COR 0~63 0 FIX
WHITE POINT RED STD WHITE TEMP DRI-RS 0~63 32 FIX
WHITE POINT GREEN STD WHITE TEMP DRI-GS 0~63 32 ADJ
WHITE POINT BLUE STD WHITE TEMP DRI-BS 0~63 32 ADJ
WHITE POINT RED COOL WHITE TEMP DRI-RC 0~63 25 FIX
WHITE POINT GREEN COOL WHITE TEMP DRI-GC 0~63 32 FIX (DRI-GS)-7 DATA
WHITE POINT BLUE COOL WHITE TEMP DRI-BC 0~63 32 FIX
SAME AS(DRI-BS)
WHITE POINT RED WARM WHITE TEMP DRI-RW 0~63 32 FIX
WHITE POINT GREEN WARM WHITE TEMP DRI-GW 0~63 32 FIX (DRI-GS)-7 DATA
WHITE POINT BLUE WARM WHITE TEMP DRI-BW 0~63 32 FIX (DRI-BS)-7 DATA
MAX VOLUME SUB-VOL 0~63 63 FIX
SUB CONTRAST SUB-CON 0~63 63 FIX
SUB COLOUR SUB-COL 0~63 32 ADJ
SUB BRIGHTNESS SUB-BRI 0~63 32 ADJ
SUB TINT SUB-TINT 0~63 32 ADJ
SUB SHARPNESS SUB-SHP 0~63 32 ADJ
MAX HOTEL VOLUME HTL-VOL 0~63 32 ADJ
HOTEL PROGRAM NUMBER HTL-PRG
0~99 OR>99FOR NONE
255 FIX
OSD GRB REFERENCE RGB 0~15 15 FIX
BLACK LEVEL OFF-SET R CUT-R 0~15 8 FIX
BLACK LEVEL OFF-SET G CUT-G 0~15 8 FIX
CATHODE DRIVE LEVEL CDL 0~15 0 FIX
Y-DELAY TIME FOR PAL(TV) [YD] DL-PT 0~15 12 FIX
Y-DELAY TIME FOR SECAM(TV) [YD] DL-ST 0~15 15 FIX
Y-DELAY TIME FOR N358 (TV) [YD] DL-3T 0~15 12 FIX
Y-DELAY TIME FOR N443 (TV) [YD] DL-4T 0~15 12 FIX
Y-DELAY TIME FOR B/W (TV) [YD] DL-TV 0~15 12 FIX
Y-DELAY TIME FOR PAL (AV) [YD] DL-PA 0~15 12 FIX
Y-DELAY TIME FOR SECAM (AV) [YD] DL-SA 0~15 15 FIX
Y-DELAY TIME FOR N358 (AV) [YD] DL-3A 0~15 12 FIX
Y-DELAY TIME FOR N443 (AV) [YD] DL-4A 0~15 12 FIX
Y-DELAY TIME FOR B/W (AV) [YD] DL-AV 0~15 12 FIX
COLOUR OFFSET (PAL) COL-OP 0~15 8 FIX
COLOUR OFFSET (SECAM) COL-OS 0~15 8 FIX
COLOUR OFFSET (NTSC358) COL-03 0~15 4 FIX
COLOUR OFFSET (NTSC443) COL-O4 0~15 4 FIX
SHARPNESS OFFSET (PAL) SHP-OP 0~15 8 FIX
SHARPNESS OFFSET (SECAM) SHP-OS 0~15 4 FIX
SHARPNESS OFFSET (NTSC358) SHP-O3 0~15 12 FIX
SHARPNESS OFFSET (NTSC443) SHP-O4 0~15 8 FIX
AFTER SHORT JA 122 & JA 124, AND TURN ON THE MAIN POWER SWITCH, READ DATA FROM EEPROM
ADDRESS 00H ~ 03H, AND COMPARE TO THE LIST BELOW, IF DIFFERENT, INITIALIZE THE EEPROM.
Address : Data Address : Data
00H : 55H 02H : 43H
01H : 4FH 03H : A1H
EEPROM ITEMS OSD DATA LENGTH
INITIAL DATA
FIX/ADJ REMARK
VERTICAL SCAN DISABLE VSD
0(DISABLE)/1(ENABLE)
0 FIX
BLACK STRETCH BKS
0(DISABLE)/1(ENABLE)
1 FIX
AUTOMATIC VOLUME LEVELING AVL
0(DISABLE)/1(ENABLE)
1 FIX
FAST FILTER IF-PLL FFI
0(DISABLE)/1(ENABLE)
0 FIX
ENABLE VERTICAL GUARD (RGB BLANKING)
EVG
0(DISABLE)/1(ENABLE)
1 FIX ONLY BLK
EHT TRACKING MODE (HCO) EHT
0(DISABLE)/1(ENABLE)
1 FIX
OVERSCAN SWITCH OFF OSO
0(DISABLE)/1(ENABLE)
0 FIX
AUTO COLOUR LIMIT ACL
0(DISABLE)/1(ENABLE)
0 FIX
FORCED COLOUR LIMIT FCO
0(DISABLE)/1(ENABLE)
0FIX
SOUND SYSTEM M S-M
0(DISABLE)/1(ENABLE)
0FIX
SOUND SYSTEM DK S-DK
0(DISABLE)/1(ENABLE)
1FIX *1
SOUND SYSTEM I S-I
0(DISABLE)/1(ENABLE)
1FIX *1
SOUND SYSTEM BG S-BG
0(DISABLE)/1(ENABLE)
1FIX
PLAYBACK SECAM P-SECAM
0(DISABLE)/1(ENABLE)
1FIX *1
FE (RF) NTSC 3.58 F-N358
0(DISABLE)/1(ENABLE)
0FIX
FE (RF) NTSC 4.43 F-N443
0(DISABLE)/1(ENABLE)
1 FIX *1
FE (RF) SECAM F-SECAM
0(DISABLE)/1(ENABLE)
1 FIX *1
VIDEO MUTE AT IDENT LOSS VMI
0(DISABLE)/1(ENABLE)
1 FIX
VIDEO MUTE AT PROGRAM/SOURCE CHANGE
VMC
0(DISABLE)/1(ENABLE)
1 FIX
HOTEL MODE HTL
0(DISABLE)/1(ENABLE)
0 FIX
REDUCED FM DEMODULATOR GAIN FOR BTSC SIGNAL
BTSC
0(DISABLE)/1(ENABLE)
0FIX
NUMBER OF EXTERNAL AV SOURCE AV
0 FOR1 AV/1 FOR 2AV
1FIX *2
FM WINDOW SELECTION FMWS
0(DISABLE)/1(ENABLE)
0FIX
SOUND MUTE BIT 0 SM0
0(DISABLE)/1(ENABLE)
1FIX
SOUND MUTE BIT 1 SM1
0(DISABLE)/1(ENABLE)
0FIX
THAI LANGUAGE THA
0(DISABLE)/1(ENABLE)
0FIX
ARABIC LANGUAGE ARA
0(DISABLE)/1(ENABLE)
1FIX *1
MALAY LANGUAGE MAL
0(DISABLE)/1(ENABLE)
1 FIX *1
CHINESE LANGUAGE CHI
0(DISABLE)/1(ENABLE)
1 FIX *1
FRENCH LANGUAGE FRE
0(DISABLE)/1(ENABLE)
1 FIX *1
RUSSIAN LANGUAGE RUS
0(DISABLE)/1(ENABLE)
1 FIX *1
FORCED V-SYNC SLICING LEVEL FSL
0(DISABLE)/1(ENABLE)
0 FIX
SYNC OF OSD HP2
0(DISABLE)/1(ENABLE)
0 FIX
TUNER CPT CPT
0(DISABLE)/1(ENABLE)
0 FIX
BILINGUAL BIL
0(DISABLE)/1(ENABLE)
0 FIX
IF AGC SPEED BIT 0 AGC0
0(DISABLE)/1(ENABLE)
1 FIX
IF AGC SPEED BIT 1 AGC1
0(DISABLE)/1(ENABLE)
0FIX
PHI-1 TIME CONSTANT (RF) FOA-FE
0(DISABLE)/1(ENABLE)
0FIX
PHI-1 TIME CONSTANT (RF) FOB-FE
0(DISABLE)/1(ENABLE)
0FIX
PHI-1 TIME CONSTANT (OFF AIR) FOA-AV
0(DISABLE)/1(ENABLE)
1 FIX
PHI-1 TIME CONSTANT (OFF AIR) FOB-AV
0(DISABLE)/1(ENABLE)
1 FIX
NOTE :
FIXED DATA, PLEASE DO NOT CHANGE WITHOUT SPECIFIC INSTRUCTION.
*1: MANUALLY CHANGE TO 0.
*2: FOR 14U10 & 14U15, SET TO 0.
