Sharp 14V-L70M - Page 23

C211 VCKYCY1HF103Z 0.01, 50V Ceramic
C231 VCKYCY1HF223Z 0.022, 50V Ceramic
D754 RH-EX0616GEZZ Zener Diode, 5.6V C232 VCKYCY1HB821K 820p,50V Ceramic
D755 RH-EX0603GEZZ Zener Diode, 3.9V C233 VCKYCY1HB472K 4700p,50V Ceramic
D801 RH-DX0048GEZZ Diode C234 VCKYCY1EF104Z 0.1, 25V Ceramic
D803 RH-DX0048GEZZ Diode C251 VCKYCY1HF223Z 0.022, 50V Ceramic
D804 RH-DX0048GEZZ Diode C252 VCEA0A1CW107M 100, 16V EL.
D805 RH-DX0048GEZZ Diode C301 VCEA0A1CW477M 470, 16V EL.
D806 RH-DX0048GEZZ Diode C304 VCEA0A1CW106M 10, 16V EL.
D810 RH-DX0048GEZZ Diode C307 VCEA0A1HW105M 1.0, 50V EL.
D1001 RH-PX0013PEZZ LED C310 VCEA0A1HW225M 2.2, 50V EL.
D1004 RH-DX0048GEZZ Diode C311 VCEA0A1HW105M 1.0, 50V EL.
D1012 RH-EX0611GEZZ Zener Diode C312 VCEA0A1HW225M 2.2, 50V EL.
D1018 RH-EX0263TAZZ Zener Diode ! C332 VCQYTA1HM103J 0.01, 50V Mylar
D1019 RH-EX0263TAZZ Zener Diode ! C333 VCEA0A1CW108M 1000, 16V EL.
D1020 RH-EX0263TAZZ Zener Diode C356 VCKYCY1HB682K 6800p,50V Ceramic
D1021 RH-EX0263TAZZ Zener Diode C359 VCEA0A1CW106M 10, 16V EL.
D1022 RH-EX0263TAZZ Zener Diode C360 VCEA0A1HW225M 2.2, 50V EL.
D1023 RH-EX0263TAZZ Zener Diode C409 VCKYCY1EF104Z 0.1, 25V Ceramic
D1031 RH-EX0610GEZZ Zener Diode C410 VCKYCY1EF104Z 0.1, 25V Ceramic
! VA701 RH-VX0073CEZZ Varistor C411 VCKYCY1HB102K 1000p,50V Ceramic
C501 VCKYPA1HB102K 1000p,50V Ceramic
C504 VCKYCY1HB103K 0.01, 50V Ceramic
PR702 RMPTP0028CEZZ Packaged Circuit C505 VCEA0A1HW107M 100, 50V EL.
X1001 RCRSB0300CEZZ Crystal C507 VCKYCY1HB103K 0.01, 50V Ceramic
C508 VCFYSA1JB224J 0.22, 63V Mylar
C509 VCEA0A1CW477M 470, 16V EL.
CF253 RFILC0446CEZZ Ceramic Filter C510 VCKYPA2HB102K
1000p,500V
Ceramic
L202 VP-DF270K0000
Peaking 27
µ
H
C514 VCFYSA1JB563J 0.056, 63V Mylar
L203 VP-DF270K0000
Peaking 27
µ
H
C529 VCKYCY1CB823K 0.082, 16V Ceramic
L204 VP-XF1R2K0000
Peaking 1.2
µ
H
C531 VCKYCY1HB102K 1000p,50V Ceramic
L253 VP-XF120K0000
Peaking 12
µ
H
C532 VCKYCY1HB102K 1000p,50V Ceramic
! L701 RCILF0096PEZZ Coil C533 VCQYTA1HM104J 0.1, 50V Mylar
! L751 RCILP0225CEZZ Coil C601 VCQYTA1HM563J 0.056, 50V Mylar
L802 VP-DF100K0000
Peaking 10
µ
H
C602 VCEA0A1HW475M 4.7, 50V EL.
L803 VP-DF100K0000
Peaking 10
µ
H
C603 VCEA0A1HW105M 1.0, 50V EL.
L1030 VP-DF100K0000
Peaking 10
µ
H
C604 VCEA0A2EW106M 10, 250V EL.
L1050 VP-DF100K0000
Peaking 10
µ
H
C605 VCKYPA2HB102K
1000p,500V
Ceramic
L1051 VP-DF100K0000
Peaking 10
µ
H
C606 VCFPFA2EB334J 0.33, 250V M-Poly.
SF201 RFILC0405CEZZ S.A.W. Filter C607 VCFPVC3ZA532H 5300p,1.5kV M-Poly.
C608 VCKYPA2HB102K
1000p,500V
Ceramic
C610 VCEA0A1CW108M 1000, 16V EL.
! T601 RTRNZ0144PEZZ Transformer C611 VCEA0A1EW476M 47, 25V EL.
! T602 RTRNF0228PEZZ H-Volt Transformer C612 VCEA0A1CW477M 470, 16V EL.
! T701 RTRNW0015PEZZ Transformer C620 VCKYPA2HB102K
1000p,500V
Ceramic
C640 VCFYSB2EB823J 0.082, 250V AD
C651 VCQYTA1HM222J 2200p, 50V Mylar
C652 VCQYTA1HM472J 4700p, 50V Mylar
C201 VCEA0A1CW476M 47, 16V EL. C653 VCEA0A1HW105M 1.0, 50V EL.
C202 VCEA0A1AW108M 1000, 10V EL. C654 VCKYCY1HF223Z 0.022, 50V Ceramic
C205 VCKYCY1HF103Z 0.01, 50V Ceramic C655 VCEA0A1HW106M 10, 50V EL.
C206 VCEA0A1HW105M 1.0, 50V EL. C656 VCEA0A1HW224M 0.22, 50V EL.
C207 VCKYCY1HB103K 0.01, 50V Ceramic C657 VCKYCY1EF104Z 0.1, 25V Ceramic
C208 VCKYCY1HB103K 0.01, 50V Ceramic C658 VCKYCY1EF104Z 0.1, 25V Ceramic
C209 VCKYCY1HB103K 0.01, 50V Ceramic ! C701 RC-FZ036SCEZZ 0.1, 275V Plastic
C210 VCKYCY1HF103Z 0.01, 50V Ceramic C702 RC-KZ0029CEZZ 0.01, 250V Ceramic
(Continued)
Ref. No. Part No. Description
PWB-A: DUNTKA541WEF2 MAIN UNIT
14V-L70M
PACKAGED CIRCUITS
FILTERS AND COILS
TRANSFORMERS
Ref. No. Part No. Description
CAPACITORS
[EL. …Electrolytic, M-Poly. …Metalized Polypro Film]
25
