14V-L70M
RJ2 VRS-CY1JF000J 00, 1/16W M-Ox.
RJ4 VRS-CY1JF000J 00, 1/16W M-Ox.
C703 RC-KZ0029CEZZ 0.01, 250V Ceramic RJ8 VRS-CY1JF000J 00, 1/16W M-Ox.
C704 RC-KZ0029CEZZ 0.01, 250V Ceramic RJ9 VRS-CY1JF000J 00, 1/16W M-Ox.
C705 RC-EZ1044CEZZ 150, 400V EL. RJ10 VRS-CY1JF000J 00, 1/16W M-Ox.
C706 RC-KZ0038CEZZ 470p,2000V Ceramic RJ13 VRS-CY1JF000J 00, 1/16W M-Ox.
C707 VCFYJU2JA333K
0.033
µ
, 630V Mylar
RJ14 VRS-CY1JF000J 00, 1/16W M-Ox.
C709 RC-KZ0039CEZZ 680, 2kV Ceramic RJ15 VRS-CY1JF000J 00, 1/16W M-Ox.
C710 VCEA0A1HW476M 47, 50V EL. RJ16 VRS-CY1JF000J 00, 1/16W M-Ox.
C711 VCKYPA1HB102K 1000p,50V Ceramic RJ17 VRS-CY1JF000J 00, 1/16W M-Ox.
C712 VCKYPA1HB471K 470p, 50V Ceramic RJ19 VRS-CY1JF000J 00, 1/16W M-Ox.
! C721 VCKYPH3DB561K 560p,2000V Ceramic RJ21 VRS-CY1JF000J 00, 1/16W M-Ox.
! C751 RC-KZ1037CEZZ 3300p,AC250V Ceramic RJ26 VRS-CY1JF000J 00, 1/16W M-Ox.
! C752 VCKYPH3DB561K 560p,2000V Ceramic RJ28 VRS-CY1JF000J 00, 1/16W M-Ox.
! C753 RC-EZ0724CEZZ 100, 16V EL. RJ32 VRS-CY1JF000J 00, 1/16W M-Ox.
! C754 RC-EZ0724CEZZ 100, 16V EL. RJ35 VRS-CY1JF000J 00, 1/16W M-Ox.
! C755 VCEA0A1CW108M 1000, 16V EL. RJ37 VRS-CY1JF000J 00, 1/16W M-Ox.
! C756 VCQYTA1HM103J 0.01, 50V Mylar RJ38 VRS-CY1JF000J 00, 1/16W M-Ox.
C759 VCEA0A0JW477M 470, 6.3V EL. RJ41 VRS-CY1JF000J 00, 1/16W M-Ox.
C760 VCEA0A0JW228M 2200, 6.3V EL. RJ42 VRS-CY1JF000J 00, 1/16W M-Ox.
C801 VCEA0A1HW105M 1.0, 50V EL. RJ43 VRS-CY1JF000J 00, 1/16W M-Ox.
C802 VCEA0A1CW337M 330, 16V EL. RJ46 VRS-CY1JF000J 00, 1/16W M-Ox.
C803 VCEA0A1CW107M 100, 16V EL. RJ49 VRS-CY1JF000J 00, 1/16W M-Ox.
C804 VCKYCY1HB222K 2200p,50V Ceramic RJ50 VRS-CY1JF000J 00, 1/16W M-Ox.
C805 VCKYD41HB102K 1000p,50V Ceramic RJ51 VRS-CY1JF000J 00, 1/16W M-Ox.
C806 VCKYD41HB102K 1000p,50V Ceramic RJ52 VRS-CY1JF000J 00, 1/16W M-Ox.
C807 VCKYD41HB102K 1000p,50V Ceramic RJ53 VRS-CY1JF000J 00, 1/16W M-Ox.
C808 VCEA0A1CW107M 100, 16V EL. RJ71 VRS-CY1JF000J 00, 1/16W M-Ox.
C809 VCKYCY1CF474Z 0.47, 16V Ceramic RJ72 VRS-CY1JF000J 00, 1/16W M-Ox.
C810 VCKYCY1CF474Z 0.47, 16V Ceramic RJ73 VRS-CY1JF000J 00, 1/16W M-Ox.
C811 VCEA0A1CW107M 100, 16V EL. RJ75 VRS-CY1JF000J 00, 1/16W M-Ox.
C812 VCFYFA1HA224J 0.22, 50V Mylar RJ76 VRS-CY1JF000J 00, 1/16W M-Ox.
C813 VCFYFA1HA224J 0.22, 50V Mylar RJ77 VRS-CY1JF000J 00, 1/16W M-Ox.
C814 VCKYCY1HB471K 470p, 50V Ceramic RJ78 VRS-CY1JF000J 00, 1/16W M-Ox.
C816 VCKYCY1HB471K 470p, 50V Ceramic RJ79 VRS-CY1JF000J 00, 1/16W M-Ox.
C1001 VCEA0A0JW107M 100, 6.3V EL. R201 VRS-CY1JF101J 100, 1/16W M-Ox.
C1002 VCEA0A0JW107M 100, 6.3V EL. R202 VRS-CY1JF101J 100, 1/16W M-Ox.
C1003 VCEA0A1CW106M 10, 16V EL. R205 VRS-CY1JF680J 68, 1/16W M-Ox.
C1004 VCKYCY1CF474Z 0.47, 16V Ceramic R206 VRS-CY1JF122J 1.2k, 1/16W M-Ox.
C1005 VCKYCY1CF474Z 0.47, 16V Ceramic R207 VRS-CY1JF221J 220, 1/16W M-Ox.
C1006 VCEA0A1CW106M 10, 16V EL. R208 VRS-CY1JF122J 1.2k, 1/16W M-Ox.
C1008 VCCCCY1HH330J 33p, 50V Ceramic R209 VRS-CY1JF392J 3.9k, 1/16W M-Ox.
C1009 VCCCCY1HH330J 33p, 50V Ceramic R212 VRS-CY1JF332J 3.3k, 1/16W M-Ox.
C1010 VCEA0A0JW107M 100, 6.3V EL. R216 VRS-VV3LB223J 22k, 3W M-Ox.
C1011 VCKYCY1CF474Z 0.47, 16V Ceramic R219 VRD-RA2BE392J 3.9k, 1/8W Carbon
C1012 VCKYCY1CF474Z 0.47, 16V Ceramic R220 VRS-CY1JF221J 220, 1/16W M-Ox.
C1013 VCEA0A0JW107M 100, 6.3V EL. R230 VRS-CY1JF473J 47k, 1/16W M-Ox.
C1016 VCQYTA1HM104J 0.1, 50V Mylar R231 VRD-RA2BE681J 680, 1/8W Carbon
C1018 VCKYCY1HB221K 220p, 50V Ceramic R232 VRS-CY1JF272J 2.7k, 1/16W M-Ox.
C1024 VCQYTA1HM104J 0.1, 50V Mylar R233 VRS-CY1JF101J 100, 1/16W M-Ox.
C1026 VCEA0A0JW107M 100, 6.3V EL. R234 VRS-CY1JF391J 390, 1/16W M-Ox.
R257 VRS-CY1JF181J 180, 1/16W M-Ox.
R258 VRS-CY1JF151J 150, 1/16W M-Ox.
R259 VRS-CY1JF471J 470, 1/16W M-Ox.
RJ1 VCKYCY1HB472K 4700p, 50V Ceramic R260 VRS-CY1JF392J 3.9k, 1/16W M-Ox.
Part No. Description
PWB-A: DUNTKA541WEF2 MAIN UNIT
(Continued)
Ref. No. Part No. Description Ref. No.
RESISTORS
[M-Ox. …Metal Oxide, M-Film …Metal Film]
26
