14V-L70M
P1002 QPLGN0541CEZZ Plug, 5-pin (BC)
RMC1001 RRMCU0222CEZZ R/C Receiver
R1014 VRS-CY1JF101J 100, 1/16W M-Ox. RDA301 PRDAR0119GJFW Heatsink for IC301
R1015 VRS-CY1JF332J 3.3k, 1/16W M-Ox. RDA501 PRDAR0118GJFW Heatsink for IC501
R1016 VRS-CY1JF101J 100, 1/16W M-Ox. RDA701 PRDAR0298PEFW Heatsink for IC701
R1017 VRS-CY1JF332J 3.3k, 1/16W M-Ox. TP201 QLUGP0102PEZZ Lug, Test Point
R1020 VRS-CY1JF101J 100, 1/16W M-Ox. LHLDP1066PE00 LED Holder
R1021 VRS-CY1JF183J 18k, 1/16W M-Ox. LHLDW1104PEZZ Holder (H-wire)
R1022 VRS-CY1JF101J 100, 1/16W M-Ox. LHLDW1105PEZZ Holder (K-wire)
R1023 VRS-CY1JF221J 220, 1/16W M-Ox. LX-BZ3049GEFD Screw
R1024 VRS-CY1JF183J 18k, 1/16W M-Ox. LX-BZ0086TAFD Screw
R1025 VRS-CY1JF101J 100, 1/16W M-Ox. LX-TZ3004CEFD Screw
R1026 VRS-CY1JF224J 220k, 1/16W M-Ox. QCNW-2608PEZZ K-wire
R1032 VRS-CY1JF332J 3.3k, 1/16W M-Ox. QCNW-2609PEZZ H-wire
R1034 VRS-CY1JF101J 100, 1/16W M-Ox. RBLN-A004WJZZ Bead Ring (D751)
R1035 VRS-CY1JF332J 3.3k, 1/16W M-Ox. J1 QPGV-0407PJZZ J. Wire (Blue)
R1036 VRS-CY1JF332J 3.3k, 1/16W M-Ox. J2 QPGV-0409PJZZ J. Wire (White)
R1037 VRS-CY1JF101J 100, 1/16W M-Ox. J3 QPGV-0408PJZZ J. Wire (Red)
R1038 VRS-CY1JF101J 100, 1/16W M-Ox. J4 QPGV-0402PJZZ J. Wire (Violet)
R1039 VRS-CY1JF223J 22k, 1/16W M-Ox. J13 QPGV-0405PJZZ J. Wire (Orange)
R1040 VRS-CY1JF101J 100, 1/16W M-Ox. J17 QPGV-0402PJZZ J. Wire (Violet)
R1041 VRS-CY1JF101J 100, 1/16W M-Ox.
R1042 VRD-RA2BE471J 470, 1/8W Carbon
R1046 VRS-CY1JF101J 100, 1/16W M-Ox.
R1047 VRS-CY1JF332J 3.3k, 1/16W M-Ox.
R1050 VRS-CY1JF392J 3.9k, 1/16W M-Ox.
R1051 VRS-CY1JF683J 68k, 1/16W M-Ox.
R1066 VRS-CY1JF273J 27k, 1/16W M-Ox.
R1072 VRS-CY1JF101J 100, 1/16W M-Ox.
R1073 VRS-CY1JF101J 100, 1/16W M-Ox.
JA721 VRD-RA2BE102J 1.2k, 1/8W Carbon
S1001 QSW-K0003AJZZ Switch, CH UP
S1002 QSW-K0003AJZZ Switch, CH DOWN
S1003 QSW-K0003AJZZ Switch, VOL UP
S1004 QSW-K0003AJZZ Switch, VOL DOWN
S1005 QSW-K0003AJZZ
Switch,
PIC/PRESET
S702 QSW-P0591CEZZ Switch, POWER
! F701 QFS-C3229CEZZ Fuse, T3.15AL
F331 RBLN-0091CEZZ Ferrite Bead
FB601 RBLN-0091CEZZ Ferrite Bead
FH701 QFSHD1013CEZZ Fuse Holder
FH702 QFSHD1014CEZZ Fuse Holder
J409 QJAKFA004WJZZ Jack, Rear AV-In
P301 QPLGN0241CEZZ Plug, 2-pin (S)
P601 QPLGN0660CEZZ Plug, 6-pin (F)
P603 QPLGN0341CEZZ Plug, 3-pin (TP651-3)
P701 QPLGN0260CEZZ Plug, 2-pin
P702 QPLGN0269GEZZ Plug, 2-pin
Ref. No. Part No. Description
PWB-A: DUNTKA541WEF2 MAIN UNIT
Ref. No. Part No. Description
(Continued)
MISCELLANEOUS PARTS
SWITCHES
