Sharp 14V-L70M - Page 27

Q870 RH-TX0110BMZZ TX0110BM
Q871 RH-TX0110BMZZ TX0110BM
Q872 RH-TX0110BMZZ TX0110BM
Q883 RH-TX0124BMZZ TX0124BM
Q885 RH-TX0124BMZZ TX0124BM
Q887 RH-TX0124BMZZ TX0124BM
D881 RH-DX0048GEZZ Diode
D882 RH-DX0048GEZZ Diode
D883 RH-DX0048GEZZ Diode
D884 RH-DX0048GEZZ Diode
D885 RH-DX0048GEZZ Diode
C871 VCCSCY1HL471J 470p, 50V Ceramic
C872 VCCSCY1HL471J 470p, 50V Ceramic
C873 VCCSCY1HL471J 470p, 50V Ceramic
C875 VCKYPA2HB102K 1000p, 500V Ceramic
C876 RC-KZ0150CEZZ 1000p, 3kV Ceramic
C878 VCEA0A2EW106M 10, 250V EL.
C880 VCCSCY1HL471J 470p, 50V Ceramic
C881 VCKYPA1HB471K 470p, 50V Ceramic
C882 VCKYPA1HB471K 470p, 50V Ceramic
C886 VCKYPA2HB102K 1000p, 500V Ceramic
R879 VRS-CY1JF471J 470, 1/16W M-Ox.
R880 VRS-CY1JF471J 470, 1/16W M-Ox.
R881 VRS-CY1JF471J 470, 1/16W M-Ox.
R882 VRS-VV3DB153J 15k, 2W M-Ox.
R883 VRD-RM2HD272J 2.7k, 1/2W Carbon
R884 VRS-VV3DB153J 15k, 2W M-Ox.
R885 VRD-RM2HD272J 2.7k, 1/2W Carbon
R886 VRS-VV3DB153J 15k, 2W M-Ox.
R887 VRD-RM2HD272J 2.7k, 1/2W Carbon
R888 VRS-CY1JF471J 470, 1/16W M-Ox.
R892 VRS-CY1JF102J 1.0k, 1/16W M-Ox.
R893 VRS-CY1JF102J 1.0k, 1/16W M-Ox.
R894 VRS-CY1JF102J 1.0k, 1/16W M-Ox.
R898 VRS-CY1JF471J 470, 1/16W M-Ox.
R899 VRS-CY1JF471J 470, 1/16W M-Ox.
! SC881 QSOCV0017PEZZ CRT Socket
L881 Jumper Wire
LHLDW1104PEZZ Holder (H-wire)
LHLDW1105PEZZ Holder (K-wire)
14V-L70M
Ref. No. Part No. Description Ref. No. Part No. Description
TRANSISTORS
DIODES
CAPACITORS
RESISTORS
[M-Ox. …Metal Oxide]
MISCELLANEOUS PARTS
[EL. …Electrolytic]
PWB-B: DUNTKA542WEA0 CRT UNIT
29
