46
20D2-S/G
21D1-S/G
21D2-S/G
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
FILTERS
CF251 RFiLC0318CEZZ R Filter, FiLC0318CE AG
CF252 RFiLC0465CEZZ R Filter, FiLC0465CE AD
SF201 RFiLC0442CEZZ R Filter, FiLC0442CE AL
COILS
L202 VP-DF270K0000Y R Peaking 27µHAB
L203 VP-DF270K0000Y R Peaking 27µHAB
L251 VP-XF100K0000Y R Peaking 10µHAB
L252 VP-XF6R8K0000Y R Peaking 6.8µHAB
å L701 RCiLF0096PEZZ R Coil, CiLF0096PE AF
L751 RCiLP0225CEZZ R Coil, CiLP0225CE AF
L802 VP-DF100K0000Y R Peaking 10µHAB
L803 VP-DF100K0000Y R Peaking 10µHAB
L1030 VP-DF100K0000Y R Peaking 10µHAB
L1050 VP-DF100K0000Y R Peaking 10µHAB
L1051 VP-DF100K0000Y R Peaking 10µHAB
TRANSFORMERS
å T601 RTRNZ0144PEZZ R Transformer AE
å T602 RTRNF0229PEZZ R H-Volt Transformer AY
å T701 RTRNW0015PEZZ R Transformer AL
CAPACITORS
C201 VCEA0A1CW476M+ R 47 16V Electrolytic AB
C202 VCEA0A1AW337M+ R 330 10V Electrolytic AC
C203 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C204 VCEA0A0JW477M+ R 470 6.3V Electrolytic AC
C205 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C206 VCEA0A1HW106M+ R 10 50V Electrolytic AB
C231 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C232 VCKYCY1HB821K R 820p 50V Ceramic AA
C233 VCKYCY1HB472K R 4700p 50V Ceramic AA
C234 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C251 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C252 VCEA0A1CW107M+ R 100 16V Electrolytic AC
C301 VCEA0A1CW477M+ R 470 16V Electrolytic AC
C304 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C306 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C310 VCEA0A1HW105M+ R 1 50V Electrolytic AB
C311 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C312 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C316 VCEA0A1CW107M+ R 100 16V Electrolytic AC
C331 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C332 VCQYTA1HM103J+ R 0.01 50V Mylar AB
C333 VCEA0A1CW108M R 1000 16V Electrolytic AD
C352 VCEA0A1CW106M+ R 10 16V Electrolytic AB
(20D2-S)
C352 VCE0A1HW105M+ R 1 50V Electrolytic AB
(21D1-S/G)
C354 VCEA0A1CW106M+ R 10 16V Electrolytic AB
(20D2-S)
C354 VCE0A1HW105M+ R 1 50V Electrolytic AB
(21D1-S/G)
C356 VCKYCY1HB472K R 4700p 50V Ceramic AA
C359 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C360 VCE9GA1HW225M+ R 2.2 50V Electrolytic AB
(N.P)
C409 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C410 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C411 VCKYCY1HB102K R 1000p 50V Ceramic AA
C412 VCEA0A1CW477M+ R 470 16V Electrolytic AC
C501 VCKYPA1HB102K+ R 1000p 50V Ceramic AA
C504 VCKYCY1HB103K R 0.01 50V Ceramic AA
C505 VCEA0A1HW107M+ R 100 50V Electrolytic AB
C507 VCKYCY1HB103K R 0.01 50V Ceramic AA
C508 VCFYSA1JB224J+ R 0.22 63V Mylar AD
C509 VCEA0A1CW477M+ R 470 16V Electrolytic AC
C510 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C514 VCFYSA1JB473J+ R 0.047 63V Mylar AC
C529 VCKYCY1CB823KY R 0.082 16V Ceramic AH
C531 VCKYCY1HB102K R 1000p 50V Ceramic AA
C532 VCKYCY1HB102K R 1000p 50V Ceramic AA
C533 VCQYTA1HM104J+ R 0.1 50V Mylar AB
C601 VCQYTA1HM563J+ R 0.056 50V Mylar AB
C602 V CEA0A1HW475M+ R 4.7 50V Electrolytic AB
C603
VCEA0A1HW105M+ R 1 50V Electrolytic AB
C604 VCEA0A2EW106M R 10 250V Electrolytic AD
C605 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C606 VCFPVC2DB474J R 0.47 200V AE
Metalized Polypro Film
C607 VCFPVC3ZA772H R 7700p 1800V AD
Metalized Polypro Film
C608 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C610 VCEA0A1CW108M R 1000 16V Electrolytic AD
C611
VCEA0A1EW476M+ R 47 25V Electrolytic AB
C612 VCEA0A1CW477M+ R 470 16V Electrolytic AC
C620 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C640 VCFYSB2EB823J R 0.082 250V AD
Metalized Polypro Film
C651 VCQYTA1HM222J+ R 2200p 50V Mylar AA
C652 VCQYTA1HM472J+ R 4700p 50V Mylar AB
C653 VCEA0A1HW105M+ R 1 50V Electrolytic AB
C654 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C655 VCEA0A1HW106M+ R 10 50V Electrolytic AB
C656 VCEA0A1HW474M+ R 0.47 50V Electrolytic AB
C657 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C658 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C701 RC-FZ031SCEZZ R 0.1 275V AD
Metalized Polypro Film
C702 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC
C703 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC
C704 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC
C705 RC-EZA072WJZZ R 220 400V Electrolytic AN
C709 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C710 VCEA0A1HW476M+ R 47 50V Electrolytic AB
C711 VCKYPA1HB102K+ R 1000p 50V Ceramic AA
C712 VCKYPA1HB471K+ R 470p 50V Ceramic AA
å C751 RC-KZ0102GEZZ R 680p AC250V Ceramic AE
C752 VCKYPH3DB561K R 560p 2000V Ceramic AC
C753 RC-EZ0776CEZZ R 100 160V Electrolytic AF
C754 RC-EZA069WJZZ R 33 160V Electrolytic AE
C755 VCEA0A1CW108M R 1000 16V Electrolytic AD
C756 VCQYTA1HM103J+ R 0.01 50V Mylar AB
C759 VCEA0A0JW477M+ R 470 6.3V Electrolytic AC
C760 VCEA0A0JW228M R 2200 6.3V Electrolytic AD
C801 VCEA0A1HW105M+ R 1 50V Electrolytic AB
C803 VCEA0A1CW107M+ R 100 16V Electrolytic AC
C804 VCKYCY1HB222K R 2200p 50V Ceramic AA
C805 VCKYD41HB102KY R 1000p 50V Ceramic AA
C806 VCKYD41HB102KY R 1000p 50V Ceramic AA
C807 VCKYD41HB102KY R 1000p 50V Ceramic AA
C808 VCEA0A1CW107M+ R 100 16V Electrolytic AC
C809 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C810 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C811 VCEA0A1CW107M+ R 100 16V Electrolytic AC
C812 VCFYFA1HA224J+ R 0.22 50V Mylar AB
C813 VCFYFA1HA224J+ R 0.22 50V Mylar AB
C814 VCKYCY1HB471K R 470p 50V Ceramic AA
C816 VCKYCY1HB471K R 470p 50V Ceramic AA
C1001 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1002 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1003 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C1004 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1005 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1006 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C1008 VCCCCY1HH330J R 33p 50V Ceramic AA
C1009 VCCCCY1HH330J R 33p 50V Ceramic AA
C1010 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1011 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1012 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1013 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1014 VCEA0A1CW106M+ R 10 16V Electrolytic AB
C1016 VCQYTA1HM104J+ R 0.1 50V Mylar AB
C1018 VCKYCY1HB221K R 220p 50V Ceramic AA
C1019 VCEA0A1HW225M+ R 2.2 50V Electrolytic AB
C1024 VCQYTA1HM104J+ R 0.1 50V Mylar AB
RESISTORS
RJ2 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ9 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ10 VRS-CY1JF000JY R 0 1/16W Metal Oxide AA
