20D2-S/G
21D1-S/G
21D2-S/G
EEPROM ITEMS OSD DATA LENGTH
INITIAL DATA
FIX/ADJ REMARK
AGC TAKE OVER POINT AGC 0~63 14 ADJ
VERTICAL SLOPE V-LIN 0~63 32 ADJ
VERTICAL AMPLITUDE V-AMP 0~63 32 ADJ
VERTICAL SHIFT V-CENT 0~63 32 ADJ
HORIZONTAL SHIFT H-CENT 0~63 32 ADJ
EAST-WEST WIDTH H-SIZE 0~63 32 *FIX
HORIZONTAL PARALLELOGRAM EW// 0~63 32 *FIX
EAST-WEST PARABOLA/WIDTH PARA 0~63 32 *FIX
EAST-WEST UPPER CORNER PARABOLA COR (U) 0~63 32 *FIX
EAST-WEST LOWER CORNER PARABOLA COR (L) 0~63 32 *FIX
EAST-WEST TRAPEZIUM TRAPE 0~63 32 *FIX
HORIZONTAL BOW HB 0~63 32 *FIX
S-CORRECTION S-COR 0~63 0 ADJ *4
WHITE POINT RED STD WHITE TEMP DRI-RS 0~63 32 *FIX
WHITE POINT GREEN STD WHITE TEMP DRI-GS 0~63 32 ADJ
WHITE POINT BLUE STD WHITE TEMP DRI-BS 0~63 32 ADJ
WHITE POINT RED COOL WHITE TEMP DRI-RC 0~63 25 ADJ *3
WHITE POINT GREEN COOL WHITE TEMP DRI-GC 0~63 32 ADJ *3
WHITE POINT BLUE COOL WHITE TEMP DRI-BC 0~63 32 ADJ
SAME AS (DRI-BS) DATA
WHITE POINT RED WARM WHITE TEMP DRI-RW 0~63 32 *FIX
WHITE POINT GREEN WARM WHITE TEMP DRI-GW 0~63 32 ADJ (DRI-GS)-7 DATA
WHITE POINT BLUE WARM WHITE TEMP DRI-BW 0~63 32 ADJ (DRI-BS)-7 DATA
MAX VOLUME SUB-VOL 0~63 63 *FIX
SUB CONTRAST SUB-CON 0~63 63 ADJ
SUB COLOUR SUB-COL 0~63 32 ADJ
SUB BRIGHTNESS SUB-BRI 0~63 32 ADJ
SUB TINT SUB-TINT 0~63 32 ADJ
SUB SHARPNESS SUB-SHP 0~63 32 (20) *FIX
MAX HOTEL VOLUME HTL-VOL 0~63 32 *FIX
HOTEL PROGRAM NUMBER HTL-PRG
0~99 OR>99FOR NONE
255 *FIX
OSD GRB REFERENCE RGB 0~15 15 ADJ
BLACK LEVEL OFF-SET R CUT-R 0~63 32 ADJ
BLACK LEVEL OFF-SET G CUT-G 0~63 32 ADJ
CATHODE DRIVE LEVEL CDL 0~15 0 ADJ *2
Y-DELAY TIME FOR PAL(TV) [YD] DL-PT 0~15 12 *FIX
Y-DELAY TIME FOR SECAM(TV) [YD] DL-ST 0~15 15 *FIX
Y-DELAY TIME FOR N358 (TV) [YD] DL-3T 0~15 12 *FIX
Y-DELAY TIME FOR N443 (TV) [YD] DL-4T 0~15 12 *FIX
Y-DELAY TIME FOR B/W (TV) [YD] DL-TV 0~15 12 *FIX
Y-DELAY TIME FOR PAL (AV) [YD] DL-PA 0~15 12 *FIX
Y-DELAY TIME FOR SECAM (AV) [YD] DL-SA 0~15 15 *FIX
Y-DELAY TIME FOR N358 (AV) [YD] DL-3A 0~15 12 *FIX
Y-DELAY TIME FOR N443 (AV) [YD] DL-4A 0~15 12 *FIX
Y-DELAY TIME FOR B/W (AV) [YD] DL-AV 0~15 12 *FIX
COLOUR OFFSET (PAL) COL-OP 0~15 8 ADJ *5
COLOUR OFFSET (SECAM) COL-OS 0~15 8 ADJ *5
COLOUR OFFSET (NTSC358) COL-O3 0~15 4 ADJ *5
COLOUR OFFSET (NTSC443) COL-O4 0~15 4 ADJ *5
SHARPNESS OFFSET (PAL) SHP-OP 0~15 8 *FIX
SHARPNESS OFFSET (SECAM) SHP-OS 0~15 4 *FIX
SHARPNESS OFFSET (NTSC358) SHP-O3 0~15 12 FIX
AFTER SHORT JA 137 & JA 138 ,AND TURN ON THE MAIN POWER SWITCH,READ DATA FROM EEPROM
ADDRESS 00H ~ 03H,AND COMPARE TO THE LIST BELOW, IF DIFFERENT, INITIALIZE THE EEPROM.
Address : Data Address : Data
00H : 55H 02H : 43H
01H : 4FH 03H : A1H
EEPROM ITEMS OSD DATA LENGTH
INITIAL DATA
FIX/ADJ REMARK
SHARPNESS OFFSET (NTSC443) SHP-O4 0~15 8 *FIX
VERTICAL SCAN DISABLE VSD
0(DISABLE)/1(ENABLE)
0*FIX
BLACK STRETCH BKS
0(DISABLE)/1(ENABLE)
1 *FIX
AUTOMATIC VOLUME LEVELING AVL
0(DISABLE)/1(ENABLE)
1*FIX
FAST FILTER IF-PLL FFI
0(DISABLE)/1(ENABLE)
0 *FIX
ENABLE VERTICAL GUARD (RGB BLANKING)
EVG
0(DISABLE)/1(ENABLE)
1*FIX
EHT TRACKING MODE (HCO) EHT
0(DISABLE)/1(ENABLE)
1*FIX
OVERSCAN SWITCH OFF OSO
0(DISABLE)/1(ENABLE)
0*FIX
AUTO COLOUR LIMIT ACL
0(DISABLE)/1(ENABLE)
0*FIX
FORCED COLOUR LIMIT FCO
0(DISABLE)/1(ENABLE)
0*FIX
SOUND SYSTEM M S-M
0(DISABLE)/1(ENABLE)
0*FIX
SOUND SYSTEM DK S-DK
0(DISABLE)/1(ENABLE)
1 ADJ
SOUND SYSTEM I S-I
0(DISABLE)/1(ENABLE)
1 ADJ
SOUND SYSTEM BG S-BG
0(DISABLE)/1(ENABLE)
1*FIX
PLAYBACK SECAM P-SECAM
0(DISABLE)/1(ENABLE)
1ADJ
FE (RF) NTSC 3.58 F-N358
0(DISABLE)/1(ENABLE)
0*FIX
FE (RF) NTSC 4.43 F-N443
0(DISABLE)/1(ENABLE)
1 ADJ
FE (RF) SECAM F-SECAM
0(DISABLE)/1(ENABLE)
1 ADJ
VIDEO MUTE AT IDENT LOSS VMI
0(DISABLE)/1(ENABLE)
1*FIX
VIDEO MUTE AT PROGRAM/SOURCE CHANGE
VMC
0(DISABLE)/1(ENABLE)
1*FIX
HOTEL MODE HTL
0(DISABLE)/1(ENABLE)
0*FIX
REDUCED FM DEMODULATOR GAIN FOR BTSC SIGNAL
BTSC
0(DISABLE)/1(ENABLE)
0*FIX
NUMBER OF EXTERNAL AV SOURCE AV
0 FOR1 AV/1 FOR 2AV
1 (0) *FIX
FM WINDOW SELECTION FMWS
0(DISABLE)/1(ENABLE)
0*FIX
SOUND MUTE BIT 0 SM0
0(DISABLE)/1(ENABLE)
1 *FIX
SOUND MUTE BIT 1 SM1
0(DISABLE)/1(ENABLE)
0 *FIX
THAI LANGUAGE THA
0(DISABLE)/1(ENABLE)
0*FIX
ARABIC LANGUAGE ARA
0(DISABLE)/1(ENABLE)
1 *FIX
MALAY LANGUAGE MAL
0(DISABLE)/1(ENABLE)
1*FIX
CHINESE LANGUAGE CHI
0(DISABLE)/1(ENABLE)
1*FIX
FRENCH LANGUAGE FRE
0(DISABLE)/1(ENABLE)
1*FIX
RUSSIAN LANGUAGE RUS
0(DISABLE)/1(ENABLE)
1 *FIX
FORCED V-SYNC SLICING LEVEL FSL
0(DISABLE)/1(ENABLE)
0*FIX
SYNC OF OSD HP2
0(DISABLE)/1(ENABLE)
0 *FIX
TUNER SELECTION (0:SHARP/ALPS;1:MURATA )
CPT
0(DISABLE)/1(ENABLE)
0 *FIX
BILINGUAL BIL
0(DISABLE)/1(ENABLE)
0 *FIX
IF AGC SPEED BIT 0 AGC0
0(DISABLE)/1(ENABLE)
1 *FIX
IF AGC SPEED BIT 1 AGC1
0(DISABLE)/1(ENABLE)
0 *FIX
PHI-1 TIME CONSTANT (RF) FOA-FE
0(DISABLE)/1(ENABLE)
0*FIX
PHI-1 TIME CONSTANT (RF) FOB-FE
0(DISABLE)/1(ENABLE)
0 *FIX
PHI-1 TIME CONSTANT (OFF AIR) FOA-AV
0(DISABLE)/1(ENABLE)
1*FIX
PHI-1 TIME CONSTANT (OFF AIR) FOB-AV
0(DISABLE)/1(ENABLE)
1*FIX
LED BLINK SPEED LED_F
0(DISABLE)/1(ENABLE)
0 (1) *FIX
VOLUME CONTROL PWM TABLE MSA
0(DISABLE)/1(ENABLE)
0 (1) *FIX
OUTPUT VERTICAL GUARD NDF
0(DISABLE)/1(ENABLE)
0 (1) *FIX
SMEF
DRI-RC 27 25
(DRI-GS)-5 (DRI-GS)-7DRI-GC
OTHER
NOTE :
1) *FIX: PLEASE DO NOT CHANGE FIXED DATA WITHOUT SPECIFIC INSTRUCTION.
Please set the EEPROM initial data according to the value in parenthesis ( ) before adjustment.
2) *2: CDL ADJUST = (9 for 21" SMEF model) and (7 for other)
*3: Adjust DRI-RC and DRI-GC as follows :
3)
4) *4: S-COR ADJUST = 20 FOR 21" and 17 FOR 20"
5) *5: ADJUST COLOUR OFFSET AFTER ADJUST SUB-COLOUR.
COLOUR OFFSET (PAL) COL-OP : 8 ------> 14
COLOUR OFFSET (SECAM) COL-OS : 8 ------> 14
COLOUR OFFSET (NTSC358) COL-O3 : 4 ------> 10
COLOUR OFFSET (NTSC443) COL-O4 : 4 ------> 10
