Sharp 20F630 User Manual

25
25-1
25-2
20F630
CU20F630
ADJUSTMENT ITEM ADJUSTMENT POSITION CONTROL PRE-ADJUST REQUIREMENT CONTENT INPUT CONDITION OUTPUT
ADJUSTMENT PROCEDURE
TRI-VISION
– STEP RANGE –
–
AFTER ALL ADJUSTMENT FINISHED. RATING SYS. DOWNLOAD SIGNAL A/B (PRCC SIG) INCLUDED SIGNAL. AC 120V, RF INPUT CONFIRMATION BY CRT SCREEN
(DOWNLOADING CONFIRMATION) 1) RECEIVE THE DOWNLOAD A SIGNAL. 2) SELECT V-CHIP CONTROL MENU THEN ON THE DOWNLOAD. 3) UNPLUG THE AC THEN PLUG AGAIN. 4) BACK TO V-CHIP CONTROL MENU, CHECK THE DOWNLOADED
RATIING AND NAME.
(UPLOADING CONFIRMATION) 1) RECEIVE THE DOWNLOAD B SIGNAL. 2) UNPLUG THE AC CORD AND PLUG IT AGAIN. 3) BACK TO V-CHIP CONTROL MENU, CHECK THE DOWNLOADED
RATING AND NAME.
~ Do check one sample that been picked up for presenting the specified
group sample.
[COMFIRMATION]
ADJUSTMENT ITEM ADJUSTMENT POSITION CONTROL PRE-ADJUST REQUIREMENT CONTENT INPUT CONDITION OUTPUT
ADJUSTMENT PROCEDURE
1) SET THE SOUND VOLUME CONTROL MORE THAN 1. 2) ADJUST BUS DATA OF M01 UNTIL THE VOLTAGE OF 39 PIN BE-
COME AS SPECIFIED BELOW.
MS LEVEL ADJUSTMENT
M01 STEP RANGE 0~15
I
2
C BUS CONTROL
OPTION SET UP, BUS SET UP, VCO ADJ, RF-AGC NO SIGNAL SIGNAL (400HZ 100% MODULATION) AC 120V, RF INPUT
IC 3001 39 PIN
[CHECKING SPEC] 490 ± 10mVrms (CHECKING SPEC :490 ± 20mVrms)

Sharp 20F630 Specifications

General

Brand	Sharp
Model	20F630
Category	TV
Language	English
