20F650
No. Item Name IC Register Range Default
F55 PSW MTS PSW 0/1 0
F56 FAO-VOL MTS VOL 0~63 60
F57 CP PLL CHARGE PUMP 0/1 0
F58 CC LEVEL MICON CC LEVEL 0/1 0
F59 OSD POS MICON OSD POS 0/1 0
F60 OFFSET-ADJ-COL 1 Chips COLOR -32~+32 0
F61 OFFSET-ADJ-TINT 1 Chips TINT -32~+32 0
F62 OFFSET-ADJ-TINT-YUV 1 Chips BASEBAND-TINT -32~+32 0
F63 WAIT MD TIMER 1 Chips SLOW MODE 0/1 1
F64 R-CUT-YUV 1 Chips R-CUT(OFFSET) -63~+63 0
F65 G-CUT-YUV 1 Chips G-CUT(OFFSET) -63~+63 0
F66 B-CUT-YUV 1 Chips B-CUT(OFFSET) -63~+63 0
F67 R-DRI-YUV 1 Chips R-DRI(OFFSET) -63~+63 0
F68 B-DRI-YUV 1 Chips B-DRI(OFFSET) -63~+63 0
F69 CONTRAST OFFSET 1 Chips CONTRAST(OFFSET) -63~+63 0
F70 BRIGHTNESS OFFSET 1 Chips BRIGHT(OFFSET) -63~+63 0
F71
AV2 BRIGHTNESS OFFSET
1 Chips BRIGHT(OFFSET) -15~+15 7
Setting Mode Items (Continued)
