Sharp 20F650 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
43
20F650
PICTURE TUBE
å VB51QDK190X4E X Picture Tube
å L706 RCiLGA032WJZZ X Degaussing Coil AR
QEARCA012WJZZ X Grounding Strap AC
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-A DUNTKD070WEA0 – MAIN Unit —
PWB-B DUNTKA599WEG3 – CRT Unit —
PWB-C DUNTKC574WEA2 – MTS Unit —
DUNTKD070WEA0
PWB-A MAIN UNIT
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY NOT INDEPENDENTLY.
å TU201 VTUVT1T5UF202 X VHF Tuner AP
INTEGRATED CIRCUITS
IC301 VHiAN17821A-1 X AN17821A AH
IC401 VHiMM1501XN-1Y X MM1501XNRE AC
IC402 VHiMM1501XN-1Y X MM1501XNRE AC
å IC501 VHiAN15525A-1 X AN15525A
IC601 VHiKA78R09AP1 X I.C. AC
å IC701 VHiSTRW6753-1 X I.C. AG
å IC702 RH-FXA003WJZZ X PC123Y82 AB
å IC703 VHiSE125N++-F X SE125N AD
IC801 VHiM61251CF1EQ X I.C. AN
IC1001 RH-iXB301WJZZY X I.C.
IC1003 VHiBR24L16F-1Y X BR24L16F-WE2 AF
TRANSISTORS
Q201 VS2SC2735//1EY X 2SC2735 AB
Q601 VS2SC2235Y/1E+ X 2SC2235Y
Q602 VSTT2140+++-F X TT2140+++ AD
Q603 VS2SC3198-G-1+ X 2SC3198-G AB
Q604 VS2SD601AR/-1Y X 2SD601AR AB
Q701 VS2SD601AR/-1Y X 2SD601AR AB
Q702 VS2SD601AR/-1Y X 2SD601AR AB
Q751 VS2SD468-C/-1+ X 2SD468-C AB
Q752 VS2SD468-C/-1+ X 2SD468-C AB
Q753 VS2SC3198-G-1+ X 2SC3198-G AB
Q754 VS2SD468-C/-1+ X 2SD468-C AB
Q801 VS2SD601AR/-1Y X 2SD601AR AB
Q804 VS2SB709AR/-1Y X 2SB709AR AB
Q805 VS2SD601AR/-1Y X 2SD601AR AB
Q1001 VS2SD601AR/-1Y X 2SD601AR AB
Q1073 VS2SD601AR/-1Y X 2SD601AR AB
DIODES
D201 RH-EX0676GEZZY X Zener Diode, 33V AB
D203 VHD1SS119//-1Y X 1SS119 AA
D393 RH-DX0247CEZZY X DX0247CE
D502 VRD-RA2BE103JY X 10k 1/8W Carbon AA
D503 RH-EX0612GEZZY X Zener Diode, 5.1V AB
D505 RH-DX0441CEZZY X DX0441CE AB
D510 RH-DX0131CEZZY X DX0131CE AB
D601 VHD1SS119//-1Y X 1SS119 AA
D602 VHD1SS244//-1Y X 1SS244 AB
D603 RH-EX0663GEZZY X Zener Diode, 24V
D606 RH-DX0131CEZZY X DX0131CE AB
å D701 RH-DX0476CEZZ X DX0476CE AC
D702 RH-DX0490CEZZY X DX0490CE AB
D703 VHD1SS119//-1Y X 1SS119 AA
D704 RH-EX0650GEZZY X Zener Diode, 18V AB
D705 RH-DX0066GEZZY X DX0066GE AB
D706 RH-DX0066GEZZY X DX0066GE AB
D707 RH-DX0066GEZZY X DX0066GE AB
D708 RH-EX0621GEZZY X Zener Diode AB
D710 VHD1SS119//-1Y X 1SS119 AA
D711 VHD1SS119//-1Y X 1SS119 AA
D713 RH-EX0606GEZZY X Zener Diode AB
D714 VHD1SS119//-1Y X 1SS119 AA
D716 RH-EX0601GEZZY X Zener Diode AB
D751 RH-DXA006WJZZ X DXA006WJ AB
D752 RH-DX0247CEZZ X DX0247CE
D801 RH-EX1393CEZZY X Zener Diode, 5.1V AB
D802 RH-EX0630GEZZY X Zener Diode, 9.1V AB
D803 VHD1SS119//-1Y X 1SS119 AA
D806 VHD1SS119//-1Y X 1SS119 AA
D810 RH-EX0263TAZZY X Zener Diode, 8.1V AB
D811 RH-EX0263TAZZY X Zener Diode, 8.1V AB
REPLACEMENT PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual ; electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does no have the same safety characteristic as the factory recom-
mended replacement parts shown in this service manual may create
shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the fol-
lowing informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free; 1-
800-BE-SHARP
Ref. No. Part No. ★ Description Code
★ MARK: SPARE PARTS-DELIVERY SECTION
' MARK: X-RAY RELATED PARTS
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques sp
éleciales de s élecurit éle, sont identifi élees dans ce manuel : les pi`eces
élelectriques qui pr élesentent ces particularit éles, sont rep éler élee
par la marque å et sont hachur élees dans les listes de pi`eces et dans
les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr éLesente
pas les m éoemes caract éLeristiques de s élecurit éle que la pi`ece
recommand élee parl'usine et dans ce manuel de service, peut provoquer
une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
★ MARQUE: SECTION LIVRAISON DES PIECES DERECHANGE
' MARQUE: PIECES RELATIVE AUX RAYONS X
Ref. No. Part No. ★ Description Code
