Sharp 20F650 Service Manual

Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
44
20F650
D812 RH-EX0263TAZZY X Zener Diode, 8.1V AB
D1081 VHD1SS119//-1Y X 1SS119 AA
D1085 RH-EX1393CEZZY X Zener Diode, 5.1V AB
D1086 RH-EX1393CEZZY X Zener Diode, 5.1V AB
D1089 RH-EX1393CEZZY X Zener Diode, 5.1V AB
D1091 VHD1SS119//-1Y X 1SS119 AA
D1094 VHD1SS119//-1Y X 1SS119 AA
D1095 VHD1SS119//-1Y X 1SS119 AA
D1801 VHD1SS119//-1Y X 1SS119 AA
VA701 RH-VXA009WJZZ X Varistor
PACKAGED CIRCUITS
å PR702 RMPTP0026CEZZ X Packaged Circuit AF
X801 RCRSAA009WJZZ X Crystal, 3.58MHz AC
FILTERS
CF201 RFiLC0447CEZZ X Filter AB
CF802 RFiLC0446CEZZ X Filter, 4.5MHz AB
SF201 RFiLC0405CEZZ X Filter AD
COILS
L203 VP-DF270K0000Y X Peaking 27µHAB
L204 VP-XF1R2K0000Y X Peaking 1.2µHAB
L602 RCiLP0223CEZZ X Coil 3.3µHAB
å L701 RCiLF0078PEZZ X Coil AF
å L703 RCiLF0078PEZZ X Coil AF
L751 RCiLP0179CEZZ+ X Coil AB
L801 VP-DF100K0000Y X Peaking 10µHAB
L802 VP-DF100K0000Y X Peaking 10µHAB
L803 VP-DF100K0000Y X Peaking 10µHAB
L804 VP-XF150K0000Y X Peaking 15µHAB
L806 VP-DF100K0000Y X Peaking 10µHAB
L807 VP-XF1R5K0000Y X Peaking 1.5µH
L1861 VP-XF8R2K0000Y X Peaking 8.2µHAB
L1862 VP-XF8R2K0000Y X Peaking 8.2µHAB
TRANSFORMERS
çå T602 RTRNFA095WJZZ X H-Volt Transformer AR
å T603 RTRNZA058WJZZ X Transformer AB
å T701 RTRNWA179WJZZ X Transformer
CAPACITORS
C201 VCEA0A1CW476M+X 47 16V Electrolytic AB
C202 VCEA0A0JW108M+ X 1000 6.3V Electrolytic AB
C203 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C205 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C206 VCEA0A1HW106M+X 10 50V Electrolytic AB
C207 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C208 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C209 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C210 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C213 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C301 VCEA0A1CW477M+X 470 16V Electrolytic AB
C304 VCEA0A1CW106M+X 10 16V Electrolytic AA
C308 VCKYCY1HB822KY X 8200p 50V Ceramic AA
C310 VCEA0A1HW105M+X 1 50V Electrolytic AB
C311 VCEA0A1HW105M+X 1 50V Electrolytic AB
C312 VCEA0A1HW335M+X 3.3 50V Electrolytic AA
C313 VCKYCY1HB822KY X 8200p 50V Ceramic AA
C317 VCE9GA1CW106M+X 10 16V Elect.(N.P) AB
C318 VCEA0A1CW107M+X 100 16V Electrolytic AB
C321 VCEA0A1HW335M+X 3.3 50V Electrolytic AA
C322 VCEA0A1HW105M+X 1 50V Electrolytic AB
C391 VCKYPA1HB102K+ X 1000p 50V Ceramic AA
C392 VCQYTA1HM103J+ X 0.01 50V Mylar AB
C393 VCEA0A1EW108M+X 1000 25V Electrolytic AB
C434 VCE9GA1CW106M+X 10 16V Elect.(N.P) AB
C435 VCE9GA1CW106M+X 10 16V Elect.(N.P) AB
C436 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C437 VCE9GA1HW106M+X 10 50V Elect.(N.P) AB
C438 VCEA0A1CW106M+X 10 16V Electrolytic AA
C439 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C452 VCE9GA1CW106M+X 10 16V Elect.(N.P) AB
C505 VCEA0A1HW107M+X 100 50V Electrolytic AB
C508 VCFYAA2AA224J+ X 0.22 100V AC
C511 VCEA0A1VW477M+X 470 35V Electrolytic AB
C512 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C513 RC-EZA332WJZZ+ X Electrolytic
C515 VCEACA1HC335J+ X 3.3 50V Electrolytic AB
C601 VCQYTA1HM563J+ X 0.056 50V Mylar AA
C602 VCEA0A1HW475M+X 4.7 50V Electrolytic AB
C603 VCEA0A1HW105M+X 1 50V Electrolytic AB
C604 VCEA0A2EW336M+X 33 250V Electrolytic AB
C606 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
çå C607 VCFPVC3ZA912H X 9100p 1.8kVM.Polypro AE
C608 VCQYTA2AA103K+ X 0.01 100V Mylar
C610 VCEA0A1EW227M+X 220 25V Electrolytic AB
C611 VCFPVC2DB334J X 0.33 200V M.Polypro AB
C642 VCEA0A1EW476M+X 47 25V Electrolytic AB
C643 VCEA0A1CW477M+X 470 16V Electrolytic AB
C650 VCKYPA2HB101K+ X 100p 500V Ceramic AB
å C701 RC-FZ029SCEZZ X 0.22 50V
C702 RC-KZ0029CEZZ+ X 0.01 250V Cermic AB
C703 RC-KZ0029CEZZ+ X 0.01 250V Cermic AB
å C705 RC-EZA104WJZZ X 470 200V Electrolytic
C706 VCEA0A1VW226M+X 22 35V Electrolytic AB
C708 VCKYPA1HB471K+ X 470p 50V Ceramic AA
C709 VCEA9M1HW105M+X 1 50V Electrolytic AA
C710 VCFYFA1HA104J+ X 0.1 50V Mylar AB
C711 VCKYPA1HB681K+ X 680p 50V Ceramic AA
C713 RC-KZ016SCEZZ X 470p 250V Ceramic AD
C718 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C743 VCKYPH3DB561K X 560p 2kV Ceramic AB
å C750 VCKYPA2HB102K+ X 1000p 500V Ceramic AB
C751 RC-KZ0106GEZZ X 3300p 250V Ceramic AB
C752 VCKYPH3DB561K X 560p 2kV Ceramic AB
C753 RC-EZ0724CEZZ X 100 160V Electrolytic AC
C754 RC-EZ0638CEZZ X 33 160V Electrolytic AC
C755 VCQYTA1HM103J+ X 0.01 50V Mylar AB
C756 VCEA0A1EW228M+X 2200 25V Electrolytic
C757 VCKYCY1HB471KY X 470p 50V Ceramic AA
C784 RC-KZ0341CEZZ X 1000p 2kV Ceramic
C801 VCFYFA1HA105J+ X 1 50V Mylar AB
C802 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C803 VCEA9M1CW476M+X 47 16V Electrolytic AA
C804 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C805 VCEA0A1HW105M+X 1 50V Electrolytic AB
C806 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C807 VCEA0A1CW337M+X 330 16V Electrolytic AB
C808 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C809 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C810 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C811 VCEA9M1CW106M+X 10 16V Electrolytic AA
C814 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C815 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C816 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C817 VCEA9M1CW107M+X 100 16V Electrolytic AB
C818 VCEA9M1HW475M+X 4.7 50V Electrolytic
C819 VCCCCY1HH121JY X 120p 50V Ceramic AA
C820 VCEA9M1HW474M+X 0.47 50V Electrolytic AA
C821 VCKYCY1HF153ZY X 0.015 50V Ceramic AA
C822 VCE9GA1HW105M+X 1 50V Elect.(N.P) AB
C823 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C824 VCEA0A1CW337M+X 330 16V Electrolytic AB
C825 VCE9GA1HW105M+X 1 50V Elect.(N.P) AB
C826 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C827 VCEA0A1CW476M+X 47 16V Electrolytic AB
C828 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C829 VCEA9M1CW476M+X 47 16V Electrolytic AA
C831 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C833 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C834 VCEA0A1CW107M+X 100 16V Electrolytic AB
C835 VCEA0A1CW106M+X 10 16V Electrolytic AA
C836 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C837 VCEA9M1HW105M+X 1 50V Electrolytic AA
C839 VCCCCY1HH680JY X 68p 50V Ceramic AA
C840 VCFYFA1HA105J+ X 1 50V Mylar AB
C841 VCCCCY1HH101JY X 100p 50V Ceramic AA
C842 VCEA9M1HW474M+X 0.47 50V Electrolytic AA
C843 VCEA0A1HW105M+X 1 50V Electrolytic AB
C845 VCKYCY1CF224ZY X 0.22 16V Ceramic AA
