Sharp 20F650 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
45
20F650
C846 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C847 VCCCCY1HH220JY X 22p 50V Ceramic AA
C848 VCEA9M1HW105M+X 1 50V Electrolytic AA
C1001 VCEA0A1AW107M+X 100 10V Electrolytic AA
C1003 VCEA0A1CW226M+X 22 16V Electrolytic AB
C1004 VCKYCY1CF474ZY X 0.47 16V Ceramic AB
C1006 VCEA0A1HW225M+X 2.2 50V Electrolytic AB
C1007 VCEA0A1CW107M+X 100 16V Electrolytic AB
C1008 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C1009 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C1011 VCKYCY1HB221KY X 220p 50V Ceramic AA
C1012 VCEA0A1HW105M+X 1 50V Electrolytic AB
C1013 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1014 VCE9GA1HW475M+X 4.7 50V Elect.(N.P) AB
C1015 VCCCCY1HH101JY X 100p 50V Ceramic AA
C1016 VCKYCY1EF104ZY X 0.1 25V Ceramic AA
C1020 VCEA0A0JW477M+ X 470 6.3V Electrolytic AB
C1081 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C1849 VCFYFA1HA223J+ X 0.022 50V Mylar AA
C1855 VCKYCY1HB561KY X 560p 50V Ceramic AA
C1856 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1861 VCCCCY1HH221JY X 220p 50V Ceramic AA
C1862 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1863 VCCCCY1HH221JY X 220p 50V Ceramic AA
C1864 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1868 VCEA9M1CW336M+X 33 16V Electrolytic
RESISTORS
RJ1 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ3 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ5 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ9 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ10 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ12 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ13 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ14 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ17 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ18 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ19 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ20 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ22 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ25 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ26 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ29 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ30 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
RJ101 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R201 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R202 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R205 VRS-CY1JF680JY X 68 1/16W Metal Oxide AA
R206 VRS-CY1JF122JY X 1.2k 1/16W Metal Oxide AA
R207 VRS-CY1JF221JY X 220 1/16W Metal Oxide AA
R208 VRS-CY1JF331JY X 330 1/16W Metal Oxide AA
R209 VRS-CY1JF392JY X 3.9k 1/16W Metal Oxide AA
R216 VRS-RG3LB333J+ X 33k 3W Metal Oxide AB
R220 VRS-CY1JF221JY X 220 1/16W Metal Oxide AA
R301 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R302 VRN-RL3DB1R2J+ X 1.2 2W Metal Film AB
R303 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R304 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R305 VRS-CY1JF274JY X 270k 1/16W Metal Oxide AA
R307 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R308 VRS-CY1JF392JY X 3.9k 1/16W Metal Oxide AA
R311 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R314 VRS-CY1JF392JY X 3.9k 1/16W Metal Oxide AA
R315 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R362 VRS-CY1JF332JY X 3.3k 1/16W Metal Oxide AA
R363 VRS-CY1JF564JY X 560k 1/16W Metal Oxide AA
R365 VRS-CY1JF564JY X 560k 1/16W Metal Oxide AA
R366 VRS-CY1JF332JY X 3.3k 1/16W Metal Oxide AA
R381 VRS-CY1JF564JY X 560k 1/16W Metal Oxide AA
R382 VRS-CY1JF332JY X 3.3k 1/16W Metal Oxide AA
R383 VRS-CY1JF564JY X 560k 1/16W Metal Oxide AA
R384 VRS-CY1JF332JY X 3.3k 1/16W Metal Oxide AA
R431 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R432 VRS-CY1JF750JY X 75 1/16W Metal Oxide AA
R433 VRS-CY1JF750JY X 75 1/16W Metal Oxide AA
R434 VRS-CY1JF750JY X 75 1/16W Metal Oxide AA
R435 VRS-CY1JF750JY X 75 1/16W Metal Oxide AA
R436 VRD-RA2BE101JY X 100 1/8W Carbon AA
R437 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R438 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R461 VRS-CY1JF750JY X 75 1/16W Metal Oxide AA
R462 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R503 VRN-RL3DB1R2J+ X 1.2 2W Metal Film AB
R504 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R506 VRS-RG3AB331J+ X 330 1W Metal Oxide AB
R507 VRD-RM2HD1R0JY X 1 1/2W Carbon AA
R513 VRD-RM2HD333JY X 33k 1/2W Carbon AA
R514 VRD-RM2HD682JY X 6.8k 1/2W Carbon AA
R520 VRS-CY1JF153JY X 15k 1/16W Metal Oxide AA
R524 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R525 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R526 VRD-RA2BE101JY X 100 1/8W Carbon AA
R601 VRD-RM2HD820JY X 82 1/2W Carbon
R602 VRD-RA2BE393JY X 39k 1/8W Carbon AA
R603 VRD-RA2BE273JY X 27k 1/8W Carbon AA
R604 VRD-RA2BE473JY X 47k 1/8W Carbon AA
R605 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R607 VRD-RM2HD121JY X 120 1/2W Carbon
å R608 VRD-RM2HD102JY X 1k 1/2W Carbon AA
R609 VRD-RM2HD270JY X 27 1/2W Carbon AA
å R611 VRN-RL3AB1R0J+ X 1 1W Metal Film AB
å R612 VRD-RM2HD270JY X 27 1/2W Carbon AA
R613 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R614 VRD-RA2BE154JY X 150k 1/8W Carbon AA
R615 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R616 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R617 VRS-CY1JF123JY X 12k 1/16W Metal Oxide AA
R618 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R621 VRN-RL2HC4R7J+ X 4.7 1/2W Metal Film AB
R622 VRS-VV3DB682J X 6.8k 2W Metal Oxide AA
R631 VRS-KT3LB391J X 390 3W Metal Oxide AB
R637 VRD-RA2BE331JY X 330 1/8W Carbon AA
R638 VRD-RA2BE181JY X 180 1/8W Carbon AA
R639 VRD-RM2HD271JY X 270 1/2W Carbon
R642 VRN-RL3DB2R2J+ X 2.2 2W Metal Film
R661 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R662 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R701 VRW-KQ3NC1R5K X 1.5 7W CEMENT AB
R702 VRD-RM2HD154JY X 150k 1/2W Carbon AA
R703 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R704 VRD-RA2BE101JY X 100 1/8W Carbon AA
å R705 VRN-RL3DBR47J+ X 0.47 2W Metal Film
å R706 VRN-RL3DBR39J+ X 0.39 2W Metal Film
R707 VRS-CY1JF223JY X 22k 1/16W Metal Oxide AA
R709 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R710 VRD-RM2HD220JY X 22 1/2W Carbon AA
R711 VRD-RA2EE122JY X 1.2k 1/4W Carbon AA
R712 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R713 VRD-RA2BE102JY X 1k 1/8W Carbon AA
å R717 RR-DZ0049CEZZY X 3.9M 1/2W Carbon AB
R725 VRD-RM2HD821JY X 820 1/2W Carbon AA
R726 VRN-RL2HCR47J+ X 0.47 1/2W Metal Film AB
R730 VRD-RA2BE222JY X 2.2k 1/8W Carbon AA
R753 VRD-RM2HD124JY X 120k 1/2W Carbon AA
R754 VRN-RL3AB8R2J+ X 8.2 1W Metal Film AB
R756 VRS-RG3DB121J+ X 120 2W Metal Oxide AB
R801 VRS-CY1JF561JY X 560 1/16W Metal Oxide AA
R802 VRS-CY1JF682JY X 6.8k 1/16W Metal Oxide AA
R803 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R804 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R805 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R806 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R807 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R808 VRD-RA2BE273JY X 27k 1/8W Carbon AA
R812 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R814 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R815 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R816 VRS-CY1JF223JY X 22k 1/16W Metal Oxide AA
R817 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R823 VRD-RA2BE101JY X 100 1/8W Carbon AA
R824 VRD-RA2BE101JY X 100 1/8W Carbon AA
