Sharp 20MR10 User Manual

Ref. No. Part No. Description Code Ref. No. Part No. Description Code
24
20MR10
R2044 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R2045 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2048 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2049 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2060 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2061 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R2063 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2065 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R2066 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2067 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2072 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
(IC2101:M24C16B)
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
(IC2101:M24C16B)
R2103 VRD-RA2BE101J J 100 1/8W Carbon AB
(IC2102:BR2416E2)
R2104 VRD-RA2BE101J J 100 1/8W Carbon AB
(IC2102:BR2416E2)
R2201 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2202 VRD-RA2BE473J J 47k 1/8W Carbon AA
R2203 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R2211 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2212 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2213 VRD-RA2BE223J J 22k 1/8W Carbon AA
R2401 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2402 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2403 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2404 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
SWITCHES
S2501 QSW-K0202PEZZ J Power AC
or
QSW-K0079GEZZ
S2502 QSW-K0202PEZZ J VOL-Down AC
or
QSW-K0079GEZZ
S2503 QSW-K0202PEZZ J VOL-Up AC
or
QSW-K0079GEZZ
S2504 QSW-K0202PEZZ J CH-Down AC
or
QSW-K0079GEZZ
S2505 QSW-K0202PEZZ J CH-Up AC
or
QSW-K0079GEZZ
MISCELLANEOUS PARTS
F701 QFS-B4023CEZZ J Fuse 4A/125V AC
or
QFS-B0421GEZZ
FB351 RBLN-0047CEZZ J Ferrite Bead AB
or
RBLN-0091GEZZ
FB601 RBLN-0047CEZZ J Ferrite Bead AB
FB2002 RBLN-0037CEZZ J Ferrite Bead AB
or
RBLN-0091GEZZ
PWB-A: DUNTKA358WEX0
MAIN UNIT (Continued)
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J903 QJAKE0205CE09 J Jack, Audio-In AD
or
QJAKE0159CEZZ
J905 QJAKE0205CE04 J Jack, Video-In AD
or
QJAKE0158CEZZ
P302 QPLGN0261CEZZ J Plug, 2-pin(S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P601 QPLGN0660CEZZ J Plug, 6-pin(K) AC
P651 QPLGN0361CEZZ J Plug, 3-pin(TP651-3) AB
P701 QPLGN0260CEZZ J Plug, 2-pin(M) AC
P751 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin(TP2001-5) AB
RMC2601 RRMCU0252CEZZ X R/C Receiver AH
or
RRMCU0232CEZZ
HM602 LX-GZ3001PEZZ J Screw AB
HM604 LX-GZ3001PEZZ J Screw AB
HM612 LX-GZ3001PEZZ J Screw AB
HM613 LX-GZ3002PEZZ J Screw AB
HM614 LX-GZ3002PEZZ J Screw AB
HM726 LX-GZ3002PEZZ J Screw AB
HM740 LX-GZ3002PEZZ J Screw AB
HM741 LX-GZ3002PEZZ J Screw AB
HM742 LX-GZ3002PEZZ J Screw AB
RDA501 PRDAR0297PEFW J Heat Sink, for IC501 AD
RDA602 PRDAR0216PEFW J Heat Sink, for Q602 AE
RDA701 PRDAR0026PEFW J Heat Sink, for Q701 AD
LX-BZ3100CEFD J Screw AA
!
