AFC2 (NO SYNC) HORIZONTAL AFC2 GAIN F51 0(NORMAL) / 1(DOWN) 0 FIX
GAMMA GAMMA CORRECTION QTY F52 0~3 0 FIX BUS SETUP
BS-D/C BLACK STRETCH CONTROL LEVEL F53 0~15 10 FIX
BS-GAIN BLACK STRETCH LEVEL F54 0(NORMAL) / 1(DOWN) 0 FIX
OM-DET OVER MODULATION DETECT F55 0(OFF) / 1(ON) 0 FIX
SL-TV SLICE LEVEL OF SYNC DETECTION TV F56 0~7 2 FIX
SL-AV SLICE LEVEL OF SYNC DETECTION AV F57 0~7 4 *FIX BUS SETUP
SL-YUV SLICE LEVEL OF SYNC DETECTION YUV F58 0~7 4 FIX
VD2/VD1/AS/FBP-TV VD2 & VD1-VERT SYNC DETECT MIN
WIDTH MSB & LSB RESPECTIVELY, AS-
TV/AV/YUV SWITCH & CH CHANGE, FBP-
FLYBACK PULSE SLICE LEVEL (TV)
F59 0~15 6 FIX
VD2/VD1/AS/FBP-AV VD2 & VD1-VERT SYNC DETECT MIN
WIDTH MSB & LSB RESPECTIVELY, AS-
TV/AV/YUV SWITCH & CH CHANGE, FBP-
FLYBACK PULSE SLICE LEVEL (AV)
F60 0~15 14 FIX
VD2/VD1/AS/FBP-YUV VD2 & VD1-VERT SYNC DETECT MIN
WIDTH MSB & LSB RESPECTIVELY, AS-
TV/AV/YUV SWITCH & CH CHANGE, FBP-
FLYBACK PULSE SLICE LEVEL (YUV)
F61 0~15 14 FIX
VDL COLOUR DIFF. INPUT PHASE ADJ F62 0~3 0 FIX
UDL COLOUR DIFF. INPUT PHASE ADJ F63 0~3 0 FIX
AUTO-SCM-KIL-TV SECAM COLOUR KILLER SENSITIVITY
(TV)
F64 0~3 1 FIX
SECAM-BGP INTERNAL SECAM BGP TIMING F65 0~3 0 FIX
N45 INHIBIT 50Hz NTSC 4.43 F66 0(NORMAL) / 1(INHIBIT) 0 FIX
TXT-POS-H (TELE-
TEXT)
TELETEXT HORIZONTAL POSITION F67 0~63 0 FIX
TXT-POS-V (TELE-
TEXT)
TELETEXT VERTICAL POSITION F68 0~63 0 FIX
OSD-POS OSD POSITION F69 0~127 9 FIX
CP CHARGE PUMP F70 0(FAST TUNING) /
1(MODERATE SPEED
TUNING)
1FIX
SMALL-SURR (S-
CTRL)
SURROUND MODE SELECT F71 0(EALA EFFECT LARGE)
/ 1(EALA EFFECT SMALL)
0FIX
SUB-BASS (S-CTRL) SUB BASS CONTROL F72 0(0dB), 1(-1dB), 2(-2dB),
3(-3dB), 4(0dB), 5(+1dB),
6(+2dB), 7(+3dB)
6FIX
SUB-TREB (S-CTRL) SUB TREBLE CONTROL F73 0(0dB), 1(-1dB), 2(-2dB),
3(-3dB), 4(0dB), 5(+1dB),
6(+2dB), 7(+3dB)
0FIX
AGC-ADJ (S-CTRL) AGC LEVEL ADJUST F74 0(AGC Off), 1(300mVrms),
2(400mVrms), 3(500Vrms),
4(600mVrms)
0FIX
AGC-SW-OFF
(NICAM)
NICAM AGC SWITCH OFF F75 0(DISABLE, FIX GAIN),
1(ENABLE)
0FIX
AGC-GAIN-ADJ
(NICAM)
NICAM AGC GAIN ADJUST F76 0~31 0 FIX
FM-LEVEL-ADJ
(NICAM)
FM LEVEL ADJUST F77 -15~0~+15 0 FIX
IGR-LEVEL-ADJ
(NICAM)
IGR LEVEL ADJUST F78 -15~0~+15 0 FIX
NICAM-BG-LVL-ADJ
(NICAM)
NICAM B/G LEVEL ADJUST F79 -15~0~+15 0 FIX
NICAM-I-LVL-ADJ
(NICAM)
NICAM I LEVEL ADJUST F80 -15~0~+15 0 FIX
NICAM-DK-LVL-ADJ
(NICAM)
NICAM D/K LEVEL ADJUST F81 -15~0~+15 0 FIX
NICAM-LOW-ERR-LIM
(NICAM)
NICAM LOWER ERROR LIMIT F82 0~255 0 FIX
NICAM-UPP-ERR-LIM
(NICAM)
NICAM UPPER ERROR LIMIT F83 0~255 0 FIX
IGR-GAIN-ADJ (IGR) IGR GAIN ADJUST F84 -6~0~+7 0 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH
INITIAL
DATA
FIX/ADJ/
AUTO
REMARK
