21L-FG1SA/SF/SM/RU
3 – 10
FM-ID-SPEED
(NICAM)
FM SOUND IDENTIFICATION MODE F85 0(SLOW) / 1(MEDIUM) /
2(FAST) / 3(OFF)
0FIX
NICAM-AUTO-MUTE NICAM AUTO DETECTION F86 0(MUTE) / 1(DEMUTE) 0 FIX
AUTO-SCM-KIL-AV-
YUV
SECAM COLOUR KILLER SENSITIVITY
(AV/YUV)
F87 0~3 1 FIX
AFC1-GAIN-TV MSB OF HORIZONTAL AFC GAIN1 (TV) F88 0(NORMAL) / 1(x2) /
2(x1.5) / 3(3.5)
0FIX
AFC1-GAIN-AV MSB OF HORIZONTAL AFC GAIN1 (AV) F89 0(NORMAL) / 1(x2) /
2(x1.5) / 3(3.5)
3FIX
AFC1-GAIN-YUV MSB OF HORIZONTAL AFC GAIN1 (YUV) F90 0(NORMAL) / 1(x2) /
2(x1.5) / 3(3.5)
3FIX
CON-REDUCE CONTRAST (PICTURE LEVEL) CONTROL F91 0(0%)~1(25%)~2(50%) 0 FIX
TAKE-OFF-TV TAKEOFF/BPF OF CHROMA BPF PRO-
CESSING TV
F92 0(BPF) / 1(TAKEOFF) 1 FIX
TAKE-OFF-AV TAKEOFF/BPF OF CHROMA BPF PRO-
CESSING AV
F93 0(BPF) / 1(TAKEOFF) 0 FIX
TAKE-OFF-YUV TAKEOFF/BPF OF CHROMA BPF PRO-
CESSING YUV
F94 0(BPF) / 1(TAKEOFF) 0 FIX
C-ANGLE (103 DEG/
95 DEG)
CHROMA MODULATION ANGLE F95 0(103DEG) / 1(95DEG) 1 FIX
AC-FAIL-WO-BRIGHT PICTURE BLACK LEVEL (BRIGHT) CON-
TROL - AC FAILURE
F96 0~255 255 FIX
FORCED-SCM-KIL-TV FORCED SECAM COLOUR KILLER SEN-
SITIVITY (TV)
F97 0~3 2 FIX
FORCED-SCM-KIL-AV-
YUV
FORCED SECAM COLOUR KILLER SEN-
SITIVITY (AV/YUV)
F98 0~3 2 FIX
R-Y ADJ. COLOUR EDGE IMPROVEMENT F99 0(DISABLE) / 1(ENABLE) 1 FIX
V-DEMUTE-DELAY VIDEO DEMUTE DELAY F100 0~255 0 *FIX BUS SETUP
S-DEMUTE-DELAY SOUND DEMUTE DELAY F101 0~255 0 *FIX BUS SETUP
MER S-BOOSTER FREQ. CHARACTERISTIC
CONTROL
F102 0~255 0 FIX
MEL1 S-BOOSTER LEVEL1 F103 0~255 0 FIX
MEL2 S-BOOSTER LEVEL2 F104 0~255 0 FIX
MEL3 S-BOOSTER LEVEL3 F105 0~255 0 FIX
MEL4 S-BOOSTER LEVEL4 F106 0~255 0 FIX
MEL5 S-BOOSTER LEVEL5 F107 0~255 0 FIX
MEL6 S-BOOSTER LEVEL6 F108 0~255 0 FIX
S-ST-POINT S-BOOSTER START POINT F109 0~60 0 FIX
S-SP-POINT S-BOOSTER STOP POINT F110 0~60 0 FIX
S-STEP S-BOOSTER STEP F111 0~60 0 FIX
POW-STORAGE CONTRAST/BRIGHTNESS INCREASE
GRADUALLY
F112 0(DISABLE) / 1(ENABLE) 1 FIX
S-B-BASS S-BOOSTER BASS LIMITER (WHEN S-
BOOSTER ON)
F113 -30~0~+30 0 FIX
S-B-TREB S-BOOSTER TREBLE LIMITER (WHEN S-
BOOSTER ON)
F114 -30~0~+30 0 FIX
S-BASS S-BOOSTER BASS LIMITER (WHEN S-
BOOSTER OFF)
F115 -30~0~+30 +30 FIX
S-TREB S-BOOSTER TREBLE LIMITER (WHEN S-
BOOSTER OFF)
F116 -30~0~+30 +30 FIX
V-STD-TV VERTICAL STANDARD SIGNAL DETEC-
TOR SWITCH (TV)
F117 0(DISABLE) / 1(ENABLE) 0 FIX
V-STD-AV VERTICAL STANDARD SIGNAL DETEC-
TOR SWITCH (AV)
F118 0(DISABLE) / 1(ENABLE) 0 FIX
V-STD-YUV VERTICAL STANDARD SIGNAL DETEC-
TOR SWITCH (YUV)
F119 0(DISABLE) / 1(ENABLE) 0 FIX
WO-Bright-after-WO-
TIME
WHITE OUT BRIGHT AFTER WHITE OUT
TIME
F120 0~255 255 FIX
WO-Contrast-after-
WO-TIME
WHITE OUT CONTRAST AFTER WHITE
OUT TIME
F121 0~127 127 FIX
WO-Bright-before-WO-
TIME
WHITE OUT BRIGHT BEFORE WHITE
OUT TIME
F122 0~255 255 FIX
WO-Contrast-before-
WO-TIME
WHITE OUT CONTRAST BEFORE WHITE
OUT TIME
F123 0~127 127 FIX
WO-TIME WHITE OUT F124 0~31 0 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH
INITIAL
DATA
FIX/ADJ/
AUTO
REMARK
