21L-FG1SA/SF/SM/RU
3 – 11
A2-ID-Response SETTING IDENTIFICATION RESPONSE
TIME
F125 0(NORMAL) / 1(FAST) 0 FIX
R-DRI YUV OFFSET RGB OUTPUT RED GAIN OFFSET (YUV) F126 -63~0~+63 0 FIX
B-DRI YUV OFFSET RGB OUTPUT BLUE GAIN OFFSET (YUV) F127 -63~0~+63 0 FIX
R-CUT YUV OFFSET RGB OUTPUT-RED BIAS LEVEL OFFSET
(YUV)
F128 -63~0~+63 0 FIX
G-CUT YUV OFFSET RGB OUTPUT-GREEN BIAS LEVEL OFF-
SET (YUV)
F129 -63~0~+63 0 FIX
B-CUT YUV OFFSET RGB OUTPUT-BLUE BIAS LEVEL OFFSET
(YUV)
F130 -63~0~+63 0 FIX
CON YUV OFFSET SUB-CONTRAS OFFSET (YUV) F131 -63~0~+63 0 FIX
BRT YUV OFFSET SUB-BRIGHT OFFSET (YUV) F132 -63~0~+63 0 FIX
SHP ANT-ONII OFF-
SET
SHARP ANT-ON II OFFSET FOR VIDEO
TONE
F133 -31~0~+31 0 FIX
WAIT MD TIME SETTING CYCLE PROCESS TIME AT
LOW POWER
F134 0~4 2 FIX
Contrast OFFSET CONTRAST (PICTURE LEVEL) OFFSET F135 -63~0~+63 0 FIX
Bright OFFSET PICTURE BLACK LEVEL (BRIGHT) OFF-
SET
F136 -63~0~+63 0 FIX
CR-PEDESTEL-ADJ Cr SIGNAL LEVEL ADJUSTMENT F137 0~15 8 FIX
CB-PEDESTEL-ADJ Cb SIGNAL LEVEL ADJUSTMENT F138 0~15 8 FIX
SIF-PAL SOUND S/N SWITCH FOR PAL F139 0(DISABLE) / 1(ENABLE) 0 FIX
AV2 BRIGHTNESS
OFFSET
AV2 BRIGHT OFFSET F140 -15~0~+15 +7 FIX
BASS OFFSET BASS OFFSET F141 -30~0~+30 15 FIX BUS SETUP
TREBLE OFFSET TREBLE OFFSET F142 -30~0~+30 10 FIX BUS SETUP
AS-SPEED-DN AUTO SLICE SPEED SWITCH (DOWN) F143 0(DISABLE) / 1(ENABLE) 0 FIX
AS-SPEED-UP AUTO SLICE SPEED SWITCH (UP) F144 0(DISABLE) / 1(ENABLE) 0 FIX
SIF-BPF-WIDE SIF BPF BANDWIDTH SELECTOR F145 0~3 0 FIX
SIF-BPF-WIDE-574 SIF BPF BANDWIDTH SELECTOR F146 0~3 0 FIX
AGC-ADJ-
R2S15903SP
AGC LEVEL OF R2S15903SP F147 0~3(OFF) / 4(300mVrms /
5(400mVrms) /
6(500mC\Vrms)
0FIX
AGC-MODE AGC MODE OF R2S15903SP F148 0(DISABLE) / 1(ENABLE) 0 FIX
OSD-POS-V50 50Hz VERTICAL OSD POSITION F149 0~255 36 FIX BUS SETUP
OSD-POS-V60 60Hz VERTICAL OSD POSITION F150 0~255 31 FIX BUS SETUP
FSC-FREE FSC-FREE F151 0/1 1 FIX BUS SETUP
MCUVOUT MCUVOUT F152 0/1 0 FIX
HALF-H KILLER HALF-H KILLER F153 0/1 1 FIX BUS SETUP
V-AGC V-AGC F154 0/1 0 FIX
SETTING MODE (SECOND STAGE)
EEPROM ITEMS FUNCTION OSD DATA LENGTH
INITIAL
DATA
FIX/ADJ/
AUTO
REMARK
