USER DATA IN SERVICE MODE
. While SERVICE mode ON, EEPROM DATA will switch to the service data.
Also, once SERVICE mode OFF, EEPROM will also switch to service (default) data .
. In the service mode, the user data establish as below,
USER DATA MODELS
PICTURE MAX 60
COLOUR CENTER 0
BRIGHT CENTER 0
TINT CENTER 0
SHARP CENTER 0
COLOR TEMP CENTER
S-VOLUME MIN
EQUALIZER *1
SURROUND OFF
BALANCE 0
AVL ON
BASS+ ON
OFF TIMER --:--
PASSWORD 0
BLUE BACK OFF
MP IN OFF
MTS STEREO
AIR / CABLE AIR
CH SEARCH AUTO
EZ SETUP AUTO
*1: Same as Movie mode default data
The flow of Mode list as following,
* Direct Key-in Mode for Service Items in Service Mode
RC CODE (HEX)
SERVICE-ITEM
C8 TV / VIDEO
28 DATA UP
A8 DATA DOWN
68 POWER / STANDBY
E8 S-MUTE
04 CHANGE MODE
64 V-LIN
54 V-SHI-50 / V-SHI-60
D4 V-SLOPE
74 H-SHI-50 / H-SHI-60
0C H-PAR
BC EW-W-50 / EW-W-60
E2 CUT-RS / CUT RS-DVD
0A DRI-GS / DRI-GS-DVD
6A CUT-RW / CUT-RW-DVD
9A DRI-GC / DRI-GC-DVD
3A DRI-GW / DRI-GW-DVD
9E VSD
31 SUB-TINT
B1 SUB-COLOR
71 SUB-BRI / SUB-BRI-DVD
F1 BLOC
C9 V-AMP-60 / V-AMP-50
83 AUTO RF-AGC
1F CUT-RC / CUT-RC-DVD
