**AFTER INITIALIZED THE EEPROM (REFER TO FACTORY PRESETTING), READ DATA FROM
EEPROM ADDRESS 00H ~ 03H,AND COMPARE TO THE LIST BELOW, IF DIFFERENT,
INITIALIZE THE EEPROM.
ADDRESS DATA ADDRESS DATA
00H:
00H
02H:
03H
01H:
00H
03H:
1FH
*** There are two stages of service mode. First stage is ADJUSTMENT MODE; data from 01~36.
To go into second stage of service mode , press MENU key.Second stage is NVM MODE data from 000~3FF
ADJUSTMENT MODE (01~35)
1) Press CH UP/CH DOWN to select the item.
1) Press VOL UP/VOL DOWN to modify/ adjust the data.
01 RF-AGC
0…63 UOC-TV 23 AUTO AUTO
02 V-SLOPE
0…63 UOC-TV 28 ADJ ADJ
03 V-SHI-50
0…63 UOC-TV 33 ADJ ADJ
04 V-AMP-50
0…63 UOC-TV 28 ADJ ADJ
05 H-SHI-50
0…63 UOC-TV 38 ADJ ADJ
06 EW-W-50
0…63 UOC-TV 48 ADJ ADJ
07 E/W-PAR-50
0…63 UOC-TV 42 ADJ ADJ
08 H-PAR
0…63 UOC-TV 30 ADJ ADJ
09 H-BOW
0…63 UOC-TV 30 ADJ ADJ
10 UPCOR-PAR
0…63 UOC-TV 42 ADJ ADJ
11 LOCOR-PAR
0…63 UOC-TV 44 ADJ ADJ
12 E/W TRAP
0…63 UOC-TV 30 ADJ ADJ
13 V-LIN
0…63 UOC-TV 32 FIX 32
14 S-COR
0…63 UOC-TV 32 FIX 32
15 DRI-RS
0…63 UOC-TV 32 ADJ ADJ
16 DRI-GS
0…63 UOC-TV 32 FIX 32
17 DRI-BS
0…63 UOC-TV 32 ADJ ADJ
18 CUT-RS
0…63 UOC-TV 16 ADJ ADJ
19 CUT-GS
0…63 UOC-TV 16 ADJ ADJ
20 CUT-BS
0…63 UOC-TV 16 ADJ ADJ
21 SUB-BRI
0…63 UOC-TV 24 ADJ ADJ
22 SUB-CON
0…63 UOC-TV 59 ADJ ADJ
23 SUB-COL
0…63 UOC-TV 10 ADJ ADJ
24
SUB-TINT 0…63 UOC-TV 36 ADJ ADJ
25
SUB-SHARP 0…63 UOC-TV 10 FIX 10
26
V-SHI-60 0…63 UOC-TV 33 ADJ ADJ
27 V-AMP-60
0…63 UOC-TV 28 ADJ ADJ
28 H-SHI-60
0…63 UOC-TV 45 ADJ ADJ
29 EW-W-60
0…63 UOC-TV 48 ADJ ADJ
30
E/W-PAR-60 0…63 UOC-TV 42 ADJ ADJ
31 VSD
0/1 UOC-TV 1 FIX 1
32 CUT OFF
0…63 UOC-TV 25 FIX 25
33 DCXO
0…3 UOC-TV 50 FIX 50
34 ISP MODE
0/1 UOC-TV 0 FIX 0
35 BLOC
0…15 UOC-TV 4 FIX 4
FINAL DATA
PLS REFER
TO ADJ
ITEM FOR
WHITE
BALANCE
PLS REFER
TO ADJ
ITEM FOR
HORIZONT
AL,
VERTICAL,
DEFLECTIO
N LOOP
Default (DEC)
FIX/ADJ/AUT
O
Item
Setting Item
Setting Range
IC
REMARK
