C209 VCKYCY1HF103Z 0.01, 50V Ceramic
C210 VCKYCY1HF103Z 0.01, 50V Ceramic
D736 RH-EX0680GEZZ Zener, EX0680GE C213 VCKYCY1HB102K 1000p, 50V Ceramic
D751 RH-DXA044WJZZ DXA044WJ C301 VCEA0A1CW477M 470, 16V EL.
D752 RH-DX0247CEZZ DX0247CE C304 VCEA9M1CW106M 10, 16V EL.
D801 RH-EX1393CEZZ Zener, EX1393CE C305 VCEA0A1HW474M 0.47, 50V EL.
D802 RH-EX0630GEZZ Zener, EX0630GE C310 VCEA0A1HW105M 1, 50V EL.
D803 VHD1SS119//-1 D1SS119 C312 VCEA0A1HW335M 3.3, 50V EL.
D806 VHD1SS119//-1 D1SS119 C313 VCKYCY1HB822K 8200, 50V Ceramic
D810 RH-EX0263TAZZ Zener, EX0263TA C318 VCEA0A1CW107M 100, 16V EL.
D811 RH-EX0263TAZZ Zener, EX0263TA C322 VCEA0A1HW105M 1, 50V EL.
D812 RH-EX0263TAZZ Zener, EX0263TA C391 VCKYPA1HB102
K
1000p, 50V Ceramic
D1001 RH-PX0013PEZZ LED, Power C392 VCQYTA1HM103J 0.01, 50V Ceramic
D1081 VHD1SS119//-1 D1SS119 C393 VCEA0A1EW108M 1000, 25V EL.
D1085 RH-EX1393CEZZ Zener, EX1393CE C437 VCE9GA1HW106M 10, 50V EL.
D1086 RH-EX1393CEZZ Zener, EX1393CE C438 VCEA0A1CW106M 10, 16V EL.
D1089 RH-EX1393CEZZ Zener, EX1393CE C439 VCKYCY1HF103Z 0.01, 50V Ceramic
D1091 VHD1SS119//-1 D1SS119 C505 VCEA0A1HW107M 100, 50V EL.
D1094 VHD1SS119//-1 D1SS119 C508 VCFYAA2AA224J 0.22, 100V M-Poly.
D1095 VHD1SS119//-1 D1SS119 C511 VCEA0A1VW477M 470, 35V EL.
D1801 VHD1SS119//-1 D1SS119 C512 VCKYPA2HB102
K
1000p, 500V Ceramic
D1802 RH-EX1393CEZZ Zener, EX1393CE C513 RC-EZA332WJZZ EZA332WJ
D1803 RH-EX1393CEZZ Zener, EX1393CE C515 VCEACA1HC335J 3.3, 50V EL.
VA701 RH-VX0073CEZZ Varistor C601 VCQYTA1HM563J 0.056, 50V Mylar
C602 VCEA0A1HW475M 4.7, 50V EL.
C603 VCEA0A1HW105M 1, 50V EL.
NR701 RH-HXA013WJZZ Thermistor C604 VCEA0A2EW476M 47, 250V EL.
! PR701 RMPTPA016WJZZ Packaged Circuit C606 VCKYPA2HB102
K
1000p, 500V Ceramic
X801 RCRSAA010WJZZ Crystal Oscillator ! C607 VCFPVC3ZA772H 7700p, 1800V M-Poly.
C608 VCFYFA1HA563J 0.056, 50V Mylar
C610 VCEA0A1EW227M 220, 25V EL.
CF201 RFILC0447CEZZ Ceramic Filter C611 VCFPVC2DB474J 0.47, 200V M-Poly
CF802 RFILC0446CEZZ Ceramic Filter C642 VCEA0A1EW476M 47, 25V EL.
L203 VP-DF270K0000
Peaking 27
µ
H
C643 VCEA0A1CW477M 470, 16V EL.
L204 VP-XF1R2K0000
Peaking 1.2
µ
H
C650 VCKYPA2HB101
K
100p, 500V Ceramic
! L701 RCILFA187WJZZ Coil ! C701 RC-FZ029SCEZZ 0.22, 275V M-Poly.
L751 RCILP0179CEZZ Coil C702 RC-KZ0029CEZZ 0.01, 250V Ceramic
L801 VP-DF100K0000
Peaking 10
µ
H
C703 RC-KZ0029CEZZ 0.01, 250V Ceramic
L802 VP-DF100K0000
Peaking 10
µ
H
C704 RC-KZ0029CEZZ 0.01, 250V Ceramic
L803 VP-DF100K0000
Peaking 10
µ
H
! C705 RC-EZA533WJZZ 220, 400V EL.
L804 VP-XF150K0000
Peaking 15
µ
H
C706 VCEA0A1HW476M 47, 50V EL.
L806 VP-DF100K0000
Peaking 10
µ
H
C708 VCKYPA1HB221
K
220p, 50V Ceramic
L807 VP-XF1R2K0000
Peaking 1.2
µ
H
C709 VCKYPA1HB103
K
0.01, 50V Ceramic
SF201 RFILCA045WJPZ SAW Filter C710 VCQYTA1HM222J 2200p, 50V Mylar
C711 VCKYPA1HB222
K
2200p, 50V Ceramic
C720 VCFYFA1HA105J 1, 50V M-Poly
! T602 RTRNFA137WJZZ H-Volt Transformer ! C750 VCKYPA2HB102
K
1000p, 500V Ceramic
! T603 RTRNZA058WJZZ Transformer ! C751 RC-KZ0102GEZZ 680p, AC250V Porcelain
!
T701 RTRNWA216WJZZ Transformer C752 VCKYPH3DB561K 560p, 2kV Ceramic
C753 RC-EZA523WJZZ 100, 160V EL.
C754 RC-EZA522WJZZ 33, 160V EL.
C755 VCQYTA1HM103J 0.01, 50V Mylar
C201 VCEA0A1CW476M 47, 16V EL. C756 VCEA0A1EW228M 2200, 25V EL.
C202 VCEA0A0JW108M 1000, 6.3V EL. C757 VCKYCY1HB471K 470p, 50V Ceramic
C203 VCKYCY1HF103Z 0.01, 50V Ceramic C784 VCKYPH3DB561K 560p, 200V Ceramic
C205 VCKYCY1HF103Z 0.01, 50V Ceramic C801 VCFYFA1HA105J 1, 50V M-Poly.
C206 VCEA0A1HW106M 10, 50V EL. C802 VCKYCY1HF103Z 0.01, 50V Ceramic
C207 VCKYCY1HF103Z 0.01, 50V Ceramic C803 VCEA9M1CW476M 47, 16V EL.
C208 VCKYCY1HF103Z 0.01, 50V Ceramic C804 VCKYCY1HF103Z 0.01, 50V Ceramic
PACKAGED CIRCUITS
Ref. No. DescriptionPart No.
PWB-A: DUNTKD373WEA6 MAIN UNIT
Description
(Continued)
Ref. No. Part No.
FILTERS AND COILS
CAPACITORS
[EL. …Electrolytic, M-Poly. …Metalized Polypro Film]
TRANSFORMERS
21V-R70M
37
