Sharp 21V-R70M User Manual

21V-R70M
C3080 VCEA0A1CW107M 100, 16V EL.
C3081 VCKYCY1HB103K 0.01, 50V Ceramic
C805 VCEA0A1HW105M 1, 50V EL. C3083 VCEA0A1CW106M 10, 16V EL.
C806 VCKYCY1HF103Z 0.01, 50V Ceramic
C807 VCEA0A1CW337M 330, 16V EL.
C808 VCKYCY1HF103Z 0.01, 50V Ceramic
C809 VCKYCY1HF103Z 0.01, 50V Ceramic RJ15 VRS-CY1JF000J 0, 1/16W M-Ox.
C810 VCKYCY1HF103Z 0.01, 50V Ceramic RJ16 VRS-CY1JF000J 0, 1/16W M-Ox.
C811 VCEA9M1CW106M 10, 16V EL. RJ18 VRS-CY1JF000J 0, 1/16W M-Ox.
C814 VCKYCY1HF103Z 0.01, 50V Ceramic RJ19 VRS-CY1JF000J 0, 1/16W M-Ox.
C815 VCKYCY1HF103Z 0.01, 50V Ceramic RJ26 VRS-CY1JF000J 0, 1/16W M-Ox.
C816 VCKYCY1EF104Z 0.1, 25V Ceramic RJ37 VRS-CY1JF000J 0, 1/16W M-Ox.
C817 VCEA9M1CW107M 100, 16V EL. RJ40 VRS-CY1JF000J 0, 1/16W M-Ox.
C818 VCEA9M1HW475M 4.7, 50V EL. R201 VRS-CY1JF101J 100, 1/16W M-Ox.
C819 VCCCCY1HH220J 22p, 50V Ceramic R202 VRS-CY1JF101J 100, 1/16W M-Ox.
C820 VCEA9M1HW474M 0.47, 50V EL. R205 VRS-CY1JF680J 68, 1/16W M-Ox.
C821 VCKYCY1HF153Z 0.015, 50V Ceramic R206 VRS-CY1JF122J 1.2k, 1/16W M-Ox.
C822 VCE9GA1HW105M 1, 50V EL. R207 VRS-CY1JF221J 220, 1/16W M-Ox.
C823 VCKYCY1EF104Z 0.1, 25V Ceramic R208 VRS-CY1JF331J 330, 1/16W M-Ox.
C824 VCEA0A1CW337M 330, 16V EL. R209 VRS-CY1JF392J 3.9k, 1/16W M-Ox.
C825 VCE9GA1HW105M 1, 50V EL. R216 VRS-VV3LB333J 33k, 3W, M-Ox.
C826 VCKYCY1HF103Z 0.01, 50V Ceramic R220 VRS-CY1JF221J 220, 1/16W M-Ox.
C827 VCEA0A1CW476M 47, 16V EL. R301 VRD-RA2BE102J 1k, 1/8W Carbon
C828 VCKYCY1HF103Z 0.01, 50V Ceramic R302 VRN-VV3DB2R2J 2.2, 2W M-Film
C829 VCEA9M1CW476M 47, 16V EL. R303 VRS-CY1JF473J 47k, 1/16W M-Ox.
C830 VCKYCY1CF224Z 0.22, 16V Ceramic R304 VRD-RA2BE683J 68k, 1/8W Carbon
C832 VCKYCY1CF224Z 0.22, 16V Ceramic R305 VRS-CY1JF274J 270k, 1/16W M-Ox.
C834 VCEA0A1CW107M 100, 16V EL. R311 VRD-RA2BE103J 10k, 1/8W Carbon
C835 VCEA0A1CW106M 10, 16V EL. R314 VRS-CY1JF332J 3.3k, 1/16W M-Ox.
C836 VCKYCY1HF103Z 0.01, 50V Ceramic R315 VRS-CY1JF272J 2.7k, 1/16W M-Ox.
C837 VCEA0A1HW105M 1, 50V EL. R365 VRS-CY1JF564J 560k, 1/16W M-ox.
C838 VCEA0A1CW106M 10, 16V EL. R366 VRS-CY1JF332J 3.3k, 1/16W M-Ox.
C839 VCKYCY1HB332K 3300p, 50V Ceramic R391 VRN-VV3ABR22J 0.22, 1W M-Film
C840 VCFYFA1HA105J 1, 50V M-Poly. R436 VRD-RA2BE101J 100, 1/8W Carbon
C841 VCCCCY1HH101J 100p, 50V Ceramic R461 VRS-CY1JF750J 75, 1/16W M-Ox.
C842 VCEA0A1HW474M 0.47, 50V EL. R462 VRD-RA2BE101J 100, 1/8W Carbon
C843 VCEA0A1HW105M 1, 50V EL. R501 VRD-RA2BE103J 10k, 1/8W Carbon
C845 VCKYCY1CF224Z 0.22, 16V Ceramic R503 VRN-VV3DB1R5J 1.5, 2W M-Film
C846 VCKYCY1HF103Z 0.01, 50V Ceramic R504 VRS-CY1JF222J 2.2, 1/16W M-Ox.
C847 VCCCCY1HH220J 22p, 50V Ceramic R506 VRS-VV3AB331J 330, 1W M-Ox.
C848 VCEA9M1HW105M 1, 50V EL. R507 VRD-RM2HD1R0J 1, 1/2W Carbon
C1001 VCEA0A0JW107M 100, 6.3V EL. R513 VRD-RM2HD333J 33k, 1/2W Carbon
C1003 VCEA0A1CW226M 22, 16V EL. R514 VRD-RM2HD562J 5.6k, 1/2W Carbon
C1004 VCKYCY1CF474Z 0.47, 16V Ceramic R520 VRS-CY1JF133J 13k, 1/16W M-Ox.
C1007 VCEA0A1CW107M 100, 16V EL. R524 VRD-RA2BE103J 10k, 1/8W Carbon
C1008 VCKYCY1HF103Z 0.01, 50V Ceramic R525 VRD-RA2BE122J 1.2k, 1/8W Carbon
C1009 VCKYCY1HF103Z 0.01, 50V Ceramic R526 VRD-RA2BE101J 100, 1/8W Carbon
C1011 VCKYCY1HB221K 220p, 50V Ceramic R601 VRD-RM2HD680J 68, 1/2W Carbon
C1012 VCEA0A1HW105M 1, 50V EL. R602 VRD-RA2BE393J 39k, 1/8W Carbon
C1013 VCKYCY1HB102K 1000p, 50V Ceramic R603 VRD-RA2BE223J 22k, 1/8W Carbon
C1014 VCE9GA1HW475M 4.7, 50V EL. R604 VRD-RA2BE473J 47k, 1/8W Carbon
C1015 VCCCPA1HH101J 100p, 50V Ceramic R605 VRD-RM2HD104J 100k, 1/2W Carbon
C1016 VCKYCY1EF104Z 0.1, 25V Ceramic R606 VRN-VV3LBR18J 0.18, 3W M-Film
C1020 VCEA0A0JW477M 470, 6.3V EL. R607 VRD-RM2HD680J 68, 1/2W Carbon
C1081 VCQYTA1HM104J 0.1, 50V Mylar
! R608 VRD-RM2HD102J 1k, 1/2W Carbon
C1849 VCFYFA1HA223J 0.022, 50V M-Poly.
! R609 VRD-RM2HD270J 27, 1/2W Carbon
C1855 VCKYCY1HB561K 560p, 50V Ceramic
! R611 VRN-VV3AB1R2J 1.2, 1W M-Film
C1856 VCKYCY1HB102K 1000p, 50V Ceramic R612 VRD-RM2HD270J 27, 1/2W Carbon
C1868 VCEA9M1CW336M 33, 16V EL. R614 VRD-RA2BE154J 150k, 1/8W Carbon
R615 VRD-RA2BE102J 1k, 1/8W Carbon
Part No.
(Continued)
PWB-A: DUNTKD373WEA6 MAIN UNIT
RESISTORS
[M-Ox. …Metal Oxide, M-Film …Metal Film]
Ref. No. Part No. Description DescriptionRef. No.
38

Sharp 21V-R70M Specifications

General

Brand	Sharp
Model	21V-R70M
Category	TV
Language	English
