21V-R70MM
5 – 10
ADJU S T ME NT
ITE M
ADJU S T ME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
COND ITIO N
OUTPUT
ADJ US TME NT
PROCEDURE
SYMBOL
HIS TOR Y
OF R E V IS ION
REVISED CONTENT .
IC 801 PIN 11
(MANU AL ADJ )
1)GO T O S E R V IC E MOD E ,
2)GO T O S E R V IC E DATA V 21, ADJ U NTIL F R E Q AS B E L O W
(S E L F ADJ )
1) GO TO SERVICE MODE, BY SELECTING THE SERVICE DATA V21
2) PRESS THE R/C TO OPERATE AUTO H-VCO, OSD APPEAR "OK" AT SCREEN
3) IF APPEAR "NG" PLS REPEAT STEP 2
[C H EC K ING S P E C ]
FREQ=15.735±.02KHz
OPTION S ET UP, BUS S E T UP
NO S IG NAL (R ASTE R ) CO N DIT IO N
AC 220
MOD E L N AME
H-V CO
V21 STE P R ANGE 0 - 7
21V -R 70MM
To Next Page
