21V-R70MM
5 – 11
MOD E L N AME
ADJU S T ME NT
ITE M
ADJU S T ME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
COND ITIO N
OUTPUT
(AT SELF ADJUSTMENT MODE)
1)GO INTO SERVICE MODE,BY SELECTING THE SERVICE DATA V10
2)PR ES S TH E R /C FO R AU T O P IF -V C O K E Y , O S D AP P E AR "O K" AT S C R EE N
3)IF APPE AR "N G " P L S R E P E AT S T E P 2
(AT MANUAL ADJ US T ME NT MO DE )
ADJ US T
1)G O IN TO S E R VIC E MO DE , BY S E LE CTIN G TH E S E R V IC E DAT A V 10
P R O C E DUR E 2) ADJ US T T HE DAT A UP /DOW N UNT IL IC 801 P IN 2 V OLT AG E B E C OME AS S P E C IFIE D B E LO W
HIS T OR Y
OF RE VIS ION
SYMBOL
REVISED CONTENT .
CONFIRMATION ON CRT DISPLAY(AUTO), IC801 PIN 2 VOLTAGE (MANUAL).
[C H EC K ING S P E C ]
2.5 ± 0. 5 V DC (C HE C KING SP E C : 2. 50 ± 1.5 V )
OPTION S ET UP, BUS S E T UP
NO S IG NAL (R ASTE R ) CO N DIT IO N
AC 220
21V -R 70MM
PIF-VCO
V10 S TE P R ANGE 0 - 63
