21V-R70MM
5 – 16
ADJU S T ME NT
ITE M
ADJU S T ME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
COND ITIO N
OUTPUT
ADJ US TME NT
PROCEDURE
SYMBOL
MOD E L N AME
SUB-PICTURE
V 01 S TE P R ANGE 0-127
21V -R 70MM
I2C B US C O N TR OL
OPTION SET UP, BUS SET UP, SCREEN, WHITE BALANCE, SUB-BRIGHTNESS
WINDOW PATTERN
220 V
CRT SCREEN DISPLAY
1) L E T THE G UN P O INT AT W H IT E PO S ITIO N (AS ATTAC H DR AWING ), ADJU S T V 01 B U S
DATA UNTILL BRIGHTNESS Y = 150 cd/m2.
NOTE: ALLOWABLE DATA FOR V01 IS >= 90, EVEN Y CAN'T MATCH THE SPEC
[VOL TAG E C ONFIR MAT ION ]
B R IG HTN E S S Y = 150 cd/m2
HIS TOR Y
OF R E V IS ION
REVISED CONTENT .
US 14
WHITE
