21V-R70MM
5 – 17
ADJU S T ME NT
ITE M
ADJU S T ME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
COND ITIO N
OUTPUT
ADJ US TME NT
PROCEDURE
SYMBOL
MOD E L N AME
SUB-TINT
V 02 S TE P R ANGE 0-127
21V -R 70MM
I2C C ONTR OL
OPTION S ET UP, BUS S E T UP, VCO ADJ, R F -AGC
US 10 CH HALF COLOR BAR PATTERN
220 V
B -AMP TR BAS E (TP 853)
CONF IR M W ITH OS C IL L O S CO P E
1)G E T IN Y -MUT E F UNC T ION B Y R /C .
2)ADJU S T TH E V02 BU S DAT A TO G E T A W AV E F O R M AS BE L O W .
[C O NF IR MAT ION ]
HIS TOR Y
OF R E V IS ION
REVISED CONTENT .
3) DIS ABL E T H E Y -MUTE
** PLS TAKE NOTE THAT SERVICE MODE DATA F62 NEED TO SET +8
B-AMP BASE (TP 853)MUST BE
IN STEPPING LEVEL
