Sharp 21v-r70MM - SUB-COLOR Adjustment (V03)

21V-R70MM
5 – 18
ADJU ST MENT
ITE M
ADJU ST MENT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INPUT
COND ITIO N
OUTPUT
ADJ US TMENT
PROCEDURE
SYMBOL
MOD E L N AME
SUB-COLOR
V03 STEP R ANGE 0-127
21V -R 70MM
I2C BUS C O N TR OL
OPTION S ET UP, BUS S E T UP, VCO ADJ, R F -AGC , S UB -PIC T, S UB -T NT
US 10 CH HALF COLOR BAR PATTERN
220 V
R -AMP TR BAS E (TP851)
CONF IR M WITH OS C IL L O S CO PE
1)SETTHEV03BUSDATATOGETAWAVEFORMASBELOW
2)THIS WAVEF OR M SHOWS T HAT T HE 75% W HIT E & R E D P OR T IONS O F C OL OR BAR B E
AT T H E SAME LE VE L
[ C HE C K IN G CON F IR MAT IO N ]
HIS TOR Y
OF R E V IS ION
REVISED CONTENT .
W
Y
Cy G
100% WHITE
Mg R B
**PLS TAKE NOTE THAT SERVICE MODE DATA F60 NEED TO SET +10
