Sharp 21v-r70MM - X-RAY PROTECTION OPERATING CONFIRMATION

21V-R70MM
5 – 19
ADJU S T ME NT
ITE M
ADJU S T ME NT
POSITION
CONTROL
PRE-ADJUST
REQUIREMENT
CONTENT
INP UT
COND ITIO N
OUTPUT
ADJ US TME NT
PROCEDURE
21V -R 70MM
SYMBOL
AFTE R AL L ADJ US T ME NT F INIS HE D.
US 4 CH LION HEAD (MONOSCOPE PATTERN)
MOD E L N AME
X-RAY PROTECTION OPERATING CONFIRMATION
STEP RANGE
21V -R 70MM
AC 220V , R F INP UT
CONFIRMATION BY THE CRT
[ V O L T AG E C OMF IR MAT ION]
S E T T HE US E R C O NT R O L T O S HIPME NT P O S ITION.
[VOLTAGE CONFIRMATION]
CHECK THE VOLTAGE OF P603 PIN 3 AS SPECIFIED BELOW.
[OPERATION CONFIRMATION]
SUPPLY THE DC VOLTAGE TO P603 PIN 3 AND MAKE SURE THE PROTECTOR IS
FU NC TIONE D , H O R IZO N TAL O S CIL AT IO N S T O P AND P IC TU R E DIS AP P E AR .
[RECOVER INFORMATION]
PULL OUT THE AC CORD .
[C A UT IO N]
FROM THE RECOVER CONFIRMATION MENTIONED ABOVE,THE AC CODE MUST BE
P U L L E D O UT AT L E AS T 4 S E C O ND BE F O R E P L U G G ING IN AG AIN. (IN O R DE R T O MAK E
SUR E THE -COM HAS BEEN RESET.)
TP VOLTAGE OPERATION VOLTAGE
HIS T OR Y
OF R E VISION
REVISED CONTENT .
26 ± 1.1V DC 27V
