Sharp 21v-r70MM User Manual

21V-R70MM
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PICTURE TUBE
!
RCILGA115WJN1 R Degaussing Coil
!
VB540ADAC1S1E R SEMI-ITC CRT
QEARC2107PEZZ R Grounding Strap
PMAGF3046CEZZ R Purity Magnet
[2] PRINTED WIRING BOARD ASSEMBLIES
DUNTKD373WEA5 - - MAIN Unit ( PWB-A )
DUNTKA599WE01 - - CRT Unit ( PWB-B )
[3] MAIN UNIT
!
TU201 VTUVT1Y5UF201 AT R Tuner
IC303 VHIAN17823A-1 R AN17823A
!
IC501 VHISTV9302A-1 AH R Vetical IC , STV9302A
IC601 VHIKA78R09AP1 AC R KA78R09AP
!
IC701 VHISTRW5453-1 AM R STRW5453
IC801 VHIM61250CF1EQ AS R M61250CF1
IC1003 VHIM24C04W6-1Y R M24C04W6-1Y
IC3002 VHIMM1501XN-1Y R MM1501XN
Q201 VS2SC2735//1EY AB R 2SC2735
Q601 VS2SC2235Y/1E+ AB R 2SC2235Y
Q602 VSTT2140+++-F AD R TT2140+++
Q603 VS2SC3198-G-1+ AA R 2SC3198-G
Q604 VS2SC3928AR-1Y AB R 2SC3928AR
Q751 VS2SD468-C/-1+ AD R 2SD468-C
Q752 VS2SD468-C/-1+ AD R 2SD468-C
Q753 VS2SC3198-G-1+ AA R 2SC3198-G
Q754 VS2SD468-C/-1+ AD R 2SD468-C
Q801 VS2SC3928AR-1Y AB R 2SC3928AR
Q804 VS2SA1530AR-1Y AB R 2SA1530AR
Q805 VS2SA1530AR-1Y AB R 2SA1530AR
Q1001 VS2SC3928AR-1Y AB R 2SC3928AR
Q1002 VS2SC3928AR-1Y AB R 2SC3928AR
Q1073 VS2SC3928AR-1Y AB R 2SC3928AR
D201 RH-EX0676GEZZY AA R Zener , EX0676GE
D203 VHDHSS4148+-1Y R SS4148+-1
D391 RH-DX0302CEZZ R DX0302CE
D503 RH-EX0612GEZZY AB R Zener , EX0612GE
D505 RH-DX0441CEZZY AB R DX0441CE
D510 RH-DX0131CEZZY AB R DX0131CE
D601 VHDHSS4148+-1Y R SS4148+-1
D602 VHD1SS244//-1Y AA R 1SS119
D603 RH-EX0667GEZZY AA R Zener , EX0667GE
D606 RH-DX0131CEZZY AB R DX0131CE
!
D701 RH-DX0476CEZZ AC R DX0476CE
D706 RH-DX0066GEZZY AB R DX0066GE
D707 RH-DX0066GEZZY AB R DX0066GE
D709 RH-DX0066GEZZY AB R DX0066GE
D710 VHDHSS4148+-1Y R SS4148+-1
D715 RH-EX0615GEZZY AA R Zener , EX0615GE
D721 RH-DX0066GEZZY AB R DX0066GE
D722 RH-EX0669GEZZY AA R Zener , EX0669GE
D723 RH-EX0640GEZZY AA R Zener , EX0640GE
D732 RH-EX0626GEZZY AB R Zener , EX0626GE
D736 RH-EX0680GEZZY AA R Zener , EX0680GE
D751 RH-DXA044WJZZ AB R DXA044WJ
D752 RH-DX0247CEZZ AB R DX0247CE
D801 RH-EX1393CEZZY AB R Zener , EX1393CE
D802 RH-EX0630GEZZY AA R Zener , EX0630GE
D803 VHDHSS4148+-1Y R SS4148+-1
D806 VHDHSS4148+-1Y R SS4148+-1
D810 RH-EX0263TAZZY AB R Zener , EX0063TA
D811 RH-EX0263TAZZY AB R Zener , EX0063TA
D812 RH-EX0263TAZZY AB R Zener , EX0063TA
D1001 RH-PX0013PEZZ AB R PhotoDiode
D1081 VHDHSS4148+-1Y R SS4148+-1
D1085 RH-EX1393CEZZY AB R Zener , EX1393CE
D1086 RH-EX1393CEZZY AB R Zener , EX1393CE
D1089 RH-EX1393CEZZY AB R Zener , EX1393CE
D1091 VHDHSS4148+-1Y R SS4148+-1
D1094 VHDHSS4148+-1Y R SS4148+-1
D1095 VHDHSS4148+-1Y R SS4148+-1
D1801 VHDHSS4148+-1Y R SS4148+-1
D1802 RH-EX1393CEZZY AB R Zener , EX1393CE
D1803 RH-EX1393CEZZY AB R Zener , EX1393CE
VA701 RH-VX0073CEZZ AB R Varistor
!
PR701 RMPTPA011WJZZ R Packaged Circuit
X801 RCRSAA010WJZZ AE R Crystal
CF201 RFILC0447CEZZ AB R Filter , FiLC0447CE
CF802 RFILC0446CEZZ AB R Filter , FiLC0446CE
SF201 RFILCA045WJPZ AF R Filter , FiLCA045WJ
L202 QJUM-0001AJFWY AA R Jumper
L203 VP-DF270K0000Y AB R Peaking , 27mH
L204 VP-XF1R2K0000Y AB R Peaking , 1.2mH
L701 RCILFA060WJZZ AD R Coil , CiLFA060WJ
