Sharp 21v-r70MM User Manual

21V-R70MM
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
L751 RCILP0179CEZZ+ AB R Coil , CiLP0179CE
L801 VP-DF100K0000Y AB R Peaking , 10mH
L802 VP-DF100K0000Y AB R Peaking , 10mH
L803 VP-DF100K0000Y AB R Peaking , 10mH
L804 VP-XF150K0000Y AB R Peaking , 15mH
L806 VP-DF100K0000Y AB R Peaking , 10mH
L807 VP-XF1R2K0000Y AB R Peaking , 1.2mH
!
T602 RTRNFA137WJZZ AV R Transformer
!
T603 RTRNZA058WJZZ AB R Transformer
!
T701 RTRNWA216WJZZ AL R Transformer
C201 VCEA0A1CW476M+ AB R 47 16V Electrolytic
C202 VCEA0A0JW108M+ AB R 1000 6.3V Electrolytic
C203 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C205 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C206 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C207 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C208 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C209 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C210 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C213 VCKYCY1HB102KY AA R 1000p 50V Ceramic
C301 VCEA0A1CW477M+ AB R 470 16V Electrolytic
C304 VCEA9M1CW106M+ AA R 10 16V Electrolytic
C305 VCEA0A1HW474M+ AB R 0.47 50V Electrolytic
C310 VCEA0A1HW105M+ AB R 1 50V Electrolytic
C312 VCEA0A1HW335M+ AB R 3.3 50V Electrolytic
C313 VCKYCY1HB822KY AA R 8200p 50V Ceramic
C322 VCEA0A1HW105M+ AB R 1 50V Electrolytic
C391 VCKYPA1HB102K+ AA R 1000p 50V Ceramic
C392 VCQYTA1HM103J+ AB R 0.01 50V Mylar
C393 VCEA0A1EW108M+ AB R 1000 25V Electrolytic
C505 VCEA0A1HW107M+ AB R 100 50V Electrolytic
C508 VCFYAA2AA224J+ AC R 0.22 100V
C511 VCEA0A1VW477M+ AB R 470 35V Electrolytic
C512 VCKYPA2HB102K+ AB R 1000p 500V Ceramic
C513 RC-EZA332WJZZ+ AB R Capacitor
C515 VCEACA1HC335J+ AB R 3.3 50V Electrolytic
C601 VCQYTA1HM563J+ AA R 0.056 50V Mylar
C602 VCEA0A1HW475M+ AB R 4.7 50V Electrolytic
C603 VCEA0A1HW105M+ AB R 1 50V Electrolytic
C604 VCEA0A2EW336M+ AB R 33 250V Electrolytic
C606 VCKYPA2HB102K+ AB R 1000p 500V Ceramic
!
C607 VCFPVC3ZA772H AD R 7700p 1800V Metalized Polypro Film
C608 VCFYF1HA563J+ AB R 0.53 50V Mylar
C610 VCEA0A1EW227M+ AB R 220 25V Electrolytic
C611 VCFPVC2EC474J AB R 0.47 250V Metalized Polypro Film
C642 VCEA0A1EW476M+ AB R 47 25V Electrolytic
C643 VCEA0A1CW477M+ AB R 470 16V Electrolytic
C650 VCKYPA2HB101K+ AB R 100p 500V Ceramic
!
C701 RC-FZ029SCEZZ AB R Capacitor
C702 RC-KZ0029CEZZ+ AB R Capacitor
C703 RC-KZ0029CEZZ+ AB R Capacitor
C704 RC-KZ0029CEZZ AC R 0.01 250V Ceramic
!
C705 RC-EZA533WJZZ AD R 100 160V Electrolytic
C706 VCEA0A1HW476M+ AB R 47 50V Electrolytic
C708 VCKYPA1HB221K+ AA R 220p 50V Ceramic
C709 VCKYPA1HB103K+ AA R 0.01 50V Ceramic
C710 VCQYTA1HM222J+ AA R 2200p 50V Mylar
C711 VCKYPA1HB222K+ AB R 2200p 50V Ceramic
C720 VCFYFA1HA105J+ AE R 1 50V Mylar
C750 VCKYPA2HB102K+ AB R 1000p 500V Ceramic
C751 RC-KZ0102GEZZ AB R 250V Ceramic
C752 VCKYPH3DB561K AB R 560p 2000V Ceramic
C753 RC-EZA523WJZZ AD R 100 160V Electrolytic
C754 RC-EZA522WJZZ AD R 33 160V Electrolytic
C755 VCQYTA1HM103J+ AB R 0.01 50V Mylar
C756 VCEA0A1EW228M+ AE R 2200 25V Electrolytic
C757 VCKYCY1HB471KY AA R 470p 50V Ceramic
C784 VCKYPH3DB561K AB R 560p 2000V Ceramic
C801 VCFYFA1HA105J+ AE R 1 50V Mylar
C802 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C803 VCEA9M1CW476M+ AA R 47 16V Electrolytic
C804 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C805 VCEA0A1HW105M+ AB R 1 50V Electrolytic
C806 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C807 VCEA0A1CW337M+ AB R 330 16V Electrolytic
C808 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C809 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C810 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C811 VCEA9M1CW106M+ AA R 10 16V Electrolytic
C814 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C815 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C816 VCKYCY1EF104ZY AA R 0.1 25V Ceramic
C817 VCEA9M1CW107M+ AB R 100 16V Electrolytic
C818 VCEA9M1HW475M+ AB R 4.7 50V Electrolytic
[3] MAIN UNIT

Sharp 21v-r70MM Specifications

General

Brand	Sharp
Model	21v-r70MM
Category	TV
Language	English
