Sharp 21V1-L Service Manual

21V1-L
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
L802 VP-CF100K0000Y AB R Peaking 10mH
L803 VP-CF220K0000Y AB R Peaking 22mH
L804 QJUM-0001AJFWY R Jumper wire
L805 QJUM-0001AJFWY R Jumper wire
L807 QJUM-0001AJFWY R Jumper wire
L808 VP-CF100K0000Y AB R Peaking 10mH
SF201 RFILCA055WJQZS R Coil
T602 RTRNFA137WJZZ R H-Volt Transformer
T603 RTRNZA058WJZZ AD R Transformer
T702 RTRNWA216WJZZ R Transformer
C202 VCEA0A1AW108M+ AC R 1000 10V Electrolytic
C203 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C204 VCEA0A1HW105M+ AB R 1 50V Electrolytic
C206 VCEA0A1HW106M+ AB R 10 50V Electrolytic
C207 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C208 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C209 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C210 VCKYCY1HF103ZY AA R 0.01 50V Ceramic
C301 VCEA0A1EW476M+ AB R 47 25V Electrolytic
C304 VCEA0A1HW224M+ AB R 0.22 50V Electrolytic
C305 VCKYCY1HB472KY AA R 4.7 50V Ceramic
C306 VCEA0A1CW226M+ AC R 22 16V Electrolytic
C308 VCEA0A1EW477M+ AD R 470 25V Electrolytic
C309 VCFYFA1HA474J+ AE R 0.47 50V Mylar
C314 VCEA0A1HW475M+ AB R 4.7 50V Electrolytic
C370 VCEA0A1CW106M+ AC R 10 16V Electrolytic
C372 VCEA0A1HW225M+ AB R 2.2 50V Electrolytic
C391 VCKYPA2HB102K+ AA R 1000p 500V Ceramic
C393 VCEA0A1EW108M+ AD R 1000 25V Electrolytic
C395 VCEA0A1HW225M+ AB R 2.2 50V Electrolytic
C451 VCEA0A1CW477M+ AC R 470 16V Electrolytic
C501 VCFYFA1HA104J+ AE R 0.10 50V Mylar
C505 VCEA0A1HW107M+ AB R 100 50V Electrolytic
C508 VCFYAA2AA224J+ AD R 0.22 100V Mylar
C511 VCEA0A1VW477M+ AB R 470 35V Electrolytic
C513 RC-EZA332WJZZ+ AD R Capacitor
C515 VCEACA1HC335J+ AC R 3.3 50V Electrolytic
C601 VCQYTA1HM563J+ AB R 0.56 50V Mylar
C602 VCEA0A1HW475M+ AB R 4.7 50V Electrolytic
C604 VCEA0A2EW336M+ AD R 33 250V Electrolytic
C607 VCFPVC3ZA772H AD R 7.7 1.8KV Metalized Polypro Film
C608 VCFYFA1HA563J+ R 0.56 50V Mylar
C610 VCEA0A1EW227M+ AB R 220 25V Electrolytic
C611 VCFPVC2EC474J AD R 0.47 200V Metalized Polypro Film
C612 VCKYPA1HB561K+ AB R 560p 50V Ceramic
C650 VCKYPA2HB101K+ AB R 100p 500V Ceramic
C701 RC-FZ029SCEZZ AD R 220 275V Metalized Plastic Film
C702 RC-KZ0029CEZZ+ AC R 0.01 250V Ceramic
C703 RC-KZ0029CEZZ+ AC R 0.01 250V Ceramic
C704 RC-KZ0029CEZZ+ AC R 0.01 250V Ceramic
C705 RC-EZA229WJZZ AM R 220 400V Electrolytic
C706 VCFYSA1HB105J+ AE R 1 50V Mylar
C708 VCKYPA1HB221K+ AB R 220p 50V Ceramic
C709 VCQYTA1HM103J+ AB R 0.01 50V Mylar
C710 VCQYTA1HM222J+ AB R 2.2 50V Mylar
C711 VCKYPA1HB222K+ AB R 2200p 50V Ceramic
C719 VCEA0A1HW476M+ AB R 47 50V Electrolytic
C750 VCKYPA2HB102K+ AA R 1000p 500V Ceramic
C751 RC-KZ0102GEZZ AC R 2kV Ceramic
C752 VCKYPH3DB561K AC R 560p 2KV Ceramic
C753 RC-EZA235WJZZ AD R 160V Electrolytic
C754 RC-EZ0638CEZZ AD R 33 160V Electrolytic
C755 VCEA0A1CW226M+ AB R 22 16V Electrolytic
C756 VCEA0A1EW228M+ AE R 2200 25V Electrolytic
C757 VCEA0A1CW226M+ AB R 22 16V Electrolytic
C758 VCEA0A1CW476M+ AB R 47 16V Electrolytic
C760 VCEA0A1CW476M+ AB R 47 16V Electrolytic
C761 VCEA0A1CW226M+ AB R 22 16V Electrolytic
C784 VCKYPH3DB561K AC R 560p 2KV Ceramic
C803 VCKYCY1HB104KY AA R 0.10 50V Ceramic
C804 VCEA0A1HW474M+ AB R 0.47 50V Electrolytic
C805 VCKYCY1HB153KY AA R 0.15 50V Ceramic
C806 VCEA0A1CW476M+ AB R 47 16V Electrolytic
C807 VCKYCY1HB103KY AA R 0.01 50V Ceramic
C808 VCKYCY1CF105ZY AB R 1 16V Ceramic
C810 VCKYCY1HB103KY AA R 0.01 50V Ceramic
C811 VCFYFA1HA224J+ AA R 0.22 50V Mylar
C814 VCKYCY1HB153KY AA R 0.15 50V Ceramic
C815 VCCCCY1HH470JY AA R 47p 50V Ceramic
C816 VCEA0A1HW474M+ AB R 0.47 50V Electrolytic
C818 VCEA0A1CW227M+ AB R 220 16V Electrolytic
C819 VCKYCY1HB103KY AA R 0.01 50V Ceramic
C820 VCKYCY1HB103KY AA R 0.01 50V Ceramic
C822 VCKYCY1HB104KY AA R 0.1 50V Ceramic
C823 VCKYCY1HB104KY AA R 0.1 50V Ceramic
[3] MAIN UNIT
