Sharp 21V1-L Service Manual

21V1-L
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1012 VRS-CY1JF183JY AA R 18K 1/16W Metal Oxide
R1013 VRS-CY1JF000JY AA R 0 1/16W Metal Oxide
R1014 QJUM-0001AJFWY R Jumper wire
R1015 VRS-CY1JF000JY AA R 0 1/16W Metal Oxide
R1016 VRD-RA2BE332JY AA R 3.3K 1/8W Carbon
R1017 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1019 VRD-RA2BE101JY AA R 100 1/8W Carbon
R1020 VRS-CY1JF183JY AA R 18K 1/16W Metal Oxide
R1021 VRS-CY1JF822JY AA R 8.2K 1/16W Metal Oxide
R1022 VRS-CY1JF183JY AA R 18K 1/16W Metal Oxide
R1024 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1025 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1026 VRS-CY1JF183JY AA R 18K 1/16W Metal Oxide
R1027 VRS-CY1JF104JY AA R 100K 1/16W Metal Oxide
R1028 VRD-RA2BE391JY AA R 390 1/8W Carbon
R1030 VRD-RA2BE103JY AA R 10K 1/8W Carbon
R1031 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1032 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1040 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1041 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1042 VRS-CY1JF000JY AA R 0 1/16W Metal Oxide
R1046 VRD-RA2BE102JY AA R 1K 1/8W Carbon
R1047 VRS-CY1JF101JY AA R 100 1/16W Metal Oxide
R1048 VRS-CY1JF471JY AA R 470 1/16W Metal Oxide
R1049 VRS-CY1JF105JY AA R 1M 1/16W Metal Oxide
R1056 VRS-CY1JF332JY AA R 3.3K 1/16W Metal Oxide
R1074 VRS-CY1JF103JY AA R 10K 1/16W Metal Oxide
R1087 VRS-CY1JF000JY AA R 0 1/16W Metal Oxide
R1092 VRS-CY1JF000JY AA R 0 1/16W Metal Oxide
R1800 VRD-RA2EE474JY AA R 470K 1/4W Carbon
R1801 VRS-CY1JF682JY AA R 6.8K 1/16W Metal Oxide
R1802 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
R1803 VRS-CY1JF473JY AA R 47K 1/16W Metal Oxide
R1804 VRD-RA2BE222JY AA R 2.2K 1/8W Carbon
R1805 VRS-CY1JF124JY AA R 120K 1/16W Metal Oxide
R1872 VRS-CY1JF750JY AA R 75 1/16W Metal Oxide
R3002 VRS-CY1JF102JY AA R 1K 1/16W Metal Oxide
R3006 VRD-RA2BE101JY AA R 100 1/8W Carbon
S701 QSW-PA003WJZZ AG R Switch , POWER
S1001 QSW-KA019WJZZ+ AC R Switch , CH UP
S1002 QSW-KA019WJZZ+ AC R Switch , CH DOWN
S1003 QSW-KA019WJZZ+ AC R Switch , VOL UP
S1004 QSW-KA019WJZZ+ AC R Switch , VOL DOWN
S1005 QSW-KA019WJZZ+ AC R Switch , MENU
!
F701 QFS-C3225CEZZ AC R Fuse , 3.15A 250V
FH701 QFSHD1013CEZZ+ AC R Fuse Holder
FH702 QFSHD1014CEZZ+ AC R Fuse Holder
J402 QJAKEA056WJ04 R Jack
J403 QJAKEA056WJ09 R Jack
J405 QJAKH0044AJZZ R Jack
P301 QPLGNA107WJZZ AB R Plug ,4Pin(S)
P601 QPLGN0660CEZZ AC R Plug ,6Pin(F)
P602 LHLDW1104PEZZ AB R Plug
P701 QPLGN0260CEZZ AC R Plug ,2Pin(M)
P702 QPLGN0269GEZZ AB R Plug ,2Pin
P1001 LHLDW1105PEZZ AB R Plug
P1002 QPLGNA110WJZZ AB R Plug ,5Pin(BC)
RMC1001 RRMCUA022WJZZ AG R Remote Receiver
RDA301 PRDARA420WJFW R Heat Sink for IC301
RDA501 PRDARA120WJFW AD R Heat Sink for IC501
RDA602 PRDARA361WJFW R Heat Sink for Q602
RDA701 PRDARA119WJFW AF R Heat Sink for IC701
[4] CRT UNIT
Q853 RH-TX0110BMZZ+ AC R TX0110
Q854 RH-TX0110BMZZ+ AC R TX0110
Q855 RH-TX0110BMZZ+ AC R TX0110
Q894 VS2SA1530AR-1Y AB R 2SA1530AR
D859 VHDHSS4148+-1Y AA R Diode
D896 VHEZJ5R6C++1EY AA R Zener Diode , 5.6V
D898 VHDHSS4148+-1Y AA R Diode
L851 VP-MK820K0000+ AB R Peaking 82mH
C851 VCKYPA1HB561K+ AA R 560p 50V Ceramic
C852 VCKYPA1HB331K+ AB R 330p 50V Ceramic
C853 VCKYPA1HB391K+ AA R 390p 50V Ceramic
C880 RC-KZ0016CEZZ AC R 10000p 1.5KV Ceramic
C893 VCEA0A1CW336M+ AB R 33 16V Electrolytic
R849 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R850 VRS-CY1JF470JY AA R 47 1/16W Metal Oxide
R851 VRS-CY1JF470JY AA R 47 1/16W Metal Oxide
R852 VRS-CY1JF470JY AA R 47 1/16W Metal Oxide
R854 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R855 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R859 VRS-VV3DB153J AA R 15K 12W Metal Oxide
R861 VRS-VV3DB153J AA R 15K 12W Metal Oxide
[3] MAIN UNIT
