Sharp 21V1-L Service Manual

21V1-L
4 – 4
Setting Mode Items
Data Service Mode Function Range Default Dat a
F01 ABCL-Gain ABCL-G 0/1 0
F02 SHP-AV-PRE VIDEO-TONE (PRE) -16~+16 0
F03 SHP-YUV-PRE VIDEO-TONE (PRE) -16~+16 0
F04 SHP-P-PRE VIDEO-TONE (PRE) -31~+31 0
F05 SHP-N3-PRE VIDEO-TONE (PRE) -31~+31 0
F06 SHP-AV-OVER VIDEO-TONE (OVER) -16~+16 0
F07 SHP-YUV-OVER VIDEO-TONE (OVER) -16~+16 0
F08 SHP-P-OVER VIDEO-TONE (OVER) -31~+31 0
F09 SHP-N3-OVER VIDEO-TONE (OVER) -31~+31 0
F10
SHP ANT-ON II OFFSET
VIDEO-TONE -15~0 -10
F11 RGB-CLIP EXTRGB-CLIP 0/1 0
F12 E-SAVE CONTRAST(OFFSET) 0~63 30
F13 FAO-VOL A-ATT
0~127 (O20=0)
0~255 (O20=1)
120
246
F14 VIF-G VIF-GAIN 0~7 5
F15 YDL-TV Y-DELAY 0~7 5
F16 YDL-TV-P Y-DELAY 0~7 5
F17 YDL-TV-N3 Y-DELAY 0~7 5
F18 YDL-AV Y-DELAY 0~7 5
F19 YDL-AV-P Y-DELAY 0~7 5
F20 YDL-AV-N3 Y-DELAY 0~7 5
F21 YDL-YUV Y-DELAY 0~7 0
F22 TINT-AV TINT(OFFSET) -32~+32 6
F23 COL-AV COLOR(OFFSET) -32~+32 0
F24 COL-P COLOR(OFFSET) -31~+31 24
F25 COL-N3 COLOR(OFFSET) -31~+31 0
F26 R-R R-DRI(OFFSET) -32~+32 3
F27 R-B R-DRI(OFFSET) -32~+32 -2
F28 B-R B-DRI(OFFSET) -32~+32 -8
F29 B-B B-DRI(OFFSET) -32~+32 6
F30 GAMMA GAMMA 0~3 1
F31 BS-D BS-DISCHARGE 0~3 0
F32 BS-C BS-CHARGE 0~3 0
F33 SL-TV S-SLICE DOWN 0~7 2
F34 SL-AV S-SLICE DOWN 0~7 2
F35 SL-YUV S-SLICE DOWN 0~7 0
F36 AFC2 AFC2-G 0/1 0
F37 VD-TV VSYNC-DET 0~7 5
F38 VD-AV VSYNC-DET 0~7 7
F39 VD-YUV VSYNC-DET 0~7 1
F40 AS-TV AUTO-SLICE 0/1 1
F41 AS-AV AUTO-SLICE 0/1 1
F42 AS-YUV AUTO-SLICE 0/1 0
F43 FBP-TV FBP VTH 0/1 0
F44 FBP-AV FBP VTH 0/1 0
F45 FBP-YUV FBP VTH 0/1 0
F46 C.Clip Level C.CLIP LEVEL 0/1 0
F47 CP CP 0/1 1
F48 CC LEVEL CC LEVEL 0~31 0
F49 OSD POS-H OSD POS 0~31 0
F50 OSD POS-V50 OSD POS 1~55 38
F51 OSD POS-V60 OSD POS 1~50 23
F52 OFFSET-ADJ-COLOR COLOR -32~+32 10
F53 OFFSET-ADJ-TINT TINT -32~+32 2
F54
WAIT
㵘
MD
㵘
TIMER
(SLOW MODE) 0/1 1
