43
26SL41M, 26SL71M
29SL81M
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
PWB-F: DUNTK9831WEV0 (26SL41M)
PWB-F: DUNTK9831WEV1 (26SL71M, 29SL81M)
FRONT AV UNIT
DIODE
D4001 RH-PX0383CEZZ X LED, Power Ind. AG
CAPACITOR
[EL.··· Electrolytic ]
C4601 VCEA0A1HW475M J 4.7 50V EL. AB
RESISTORS
R4501 VRD-RA2BE103J J 10k 1/8W Carbon AA
R4503 VRD-RA2BE273J J 27k 1/8W Carbon AA
R4504 VRD-RA2BE123J J 12k 1/8W Carbon AA
R4505 VRD-RA2BE563J J 56k 1/8W Carbon AA
R4506 VRD-RA2BE563J J 56k 1/8W Carbon AA
R4508 VRD-RA2BE153J J 15k 1/8W Carbon AA
R4509 VRD-RA2BE272J J 2.7k 1/8W Carbon AA
R4601 VRD-RA2EE331J J 330 1/4W Carbon AA
SWITCHES
S4501 QSW-K0095CEZZ J Power AB
S4502 QSW-K0095CEZZ J VOL-Down AB
S4503 QSW-K0095CEZZ J VOL-Up AB
S4504 QSW-K0095CEZZ J CH-Down AB
S4505 QSW-K0095CEZZ J CH-Up AB
S4506 QSW-K0095CEZZ J MENU AB
MISCELLANEOUS PARTS
J4001 QJAKE0185CEZZ J Audio IN (L) AE
(26SL71M, 29SL81M)
J4002 QJAKE0192CEZZ X Audio IN (R) AD
(26SL71M, 29SL81M)
J4002 QJAKE0183CEZZ X Audio IN AE
(26SL41M)
J4003 QJAKE0150CEZZ J Video IN AD
(26SL71M, 29SL81M)
J4003 QJAKE0108CEZZ J Video IN AC
(26SL41M)
P4001 QPLGN0541CEZZ J Plug, 5-pin (FA) AB
(26SL71M, 29SL81M)
P4001 QPLGN0841CEZZ J Plug, 8-pin (FA) AB
(26SL41M)
P4002 QPLGN0841CEZZ J Plug, 8-pin (FB) AB
RMC4601 RRMCU0235CEZZ J R/C Receiver AK
INTEGRATED CIRCUITS
IC1401 VHiTC90A45F-1 J TC90A45F AM
IC1402 VHiMM1111XF1E J MM1111XFBE AE
IC1403 VHiKA78L05B-1 J KA78L05BP AE
TRANSISTORS
You can substitute "VS2SD601AR/-1" for "VS2SC2412KQ-1".
Q1401 VS2SC2412KQ-1 J 2SC2412KQ AA
Q1402 VS2SC2412KQ-1 J 2SC2412KQ AA
Q1403 VS2SC2412KQ-1 J 2SC2412KQ AA
Q1404 VS2SC2412KQ-1 J 2SC2412KQ AA
Q1405 VS2SC2412KQ-1 J 2SC2412KQ AA
Q1406 VS2SC2412KQ-1 J 2SC2412KQ AA
Q1407 VS2SC2412KQ-1 J 2SC2412KQ AA
DIODES
You can substitute "RH-DX0475CEZZ" for "VHD1SS119//-1".
D1401 VHD1SS119//-1 J Diode AB
D1402 VHD1SS119//-1 J Diode AB
D1403 VHD1SS119//-1 J Diode AB
COILS
L1401 VP-XF100K0000 J Peaking 10µH AB
L1402 VP-XF100K0000 J Peaking 10µH AB
L1403 VP-XF150K0000 J Peaking 15µH AB
L1405 VP-XF330K0000 J Peaking 33µH AB
L1406 VP-XF100K0000 J Peaking 10µH AB
CAPACITORS
[EL.··· Electrolytic ]
C1401 VCCCCY1HH220J J 22p 50V Ceramic AA
C1402 VCFYSA1HA474J J 0.47 50V Mylar
C1403 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1404 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1405 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1406 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1407 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1408 VCEA0A1HW106M J 10 50V EL. AB
C1409 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1410 VCCCCY1HH181J J 180p 50V Ceramic AA
C1411 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1412 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1413 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1415 VCEA0A1CW476M J 47 16V EL AB
C1416 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1417 VCCCCY1HH390J J 39p 50V Ceramic AA
C1418 VCEA0A1HW106M J 10 50V EL. AB
C1419 VCEA0A1HW106M J 10 50V EL. AB
C1420 VCKYCY1HB103K J 0.01 50V Ceramic AA
C1421 VCCCCY1HH120J J 12p 50V Ceramic AA
C1423 VCCCCY1HH120J J 12p 50V Ceramic AA
C1424 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1425 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1426 VCKYCY1HB102K J 100p 50V Ceramic AA
C1427 VCEA0A1HW106M J 10 50V EL. AB
C1428 VCCCCY1HH270J J 27p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide ]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R1401 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1402 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1403 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R1404 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1405 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R1406 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
PWB-K: DUNTK9832WEV0 (29SL81M)
Y/C UNIT
