2T-C45AE1X
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DKEYMG912FM01 V MAIN UNIT (GENERAL)
N KSETLA735WJZZ V POWER UNIT
N KSETLA739WJZZ AM V JOGKEY UNIT
N KSETLA736WJZZ V LED/IR UNIT
N KSETLA734WJZZ V BLUETOOTH ANTENNA
N RUNTKB588WJQZ BK V WIFI UNIT
[2] LCD PANEL
N KSETLA740WJZZ V TFT LCD OPEN CELL
N CLCDTA452WEA4 V PANEL ASSEMBLY
N KSETLA741WJZZ V LED BAR
[3] MAIN UNIT ( DKEYMG912FM01) 2T-C45AE1X
IC3101 RH-IXE079WJQZQ V KLM8G1GETF-B041006
P9601 KSETLA732WJZZ V MECHANISM UNIT
P1701 KSETLA733WJZZ V MECHANISM UNIT
SC3802 QCNCWB143WJQZY AK V CONNECTOR
SC501 QJAKEA145WJN1Q V JACK
J502 QJAKGA181WJN1Q V JACK
J503 QJAKJA054WJQZY AD V JACK
J2201 QJAKZA151WJQZQ AF V JACK
LUG3303 QLUGHA022WJZZY AC V LUG
LUG3304 QLUGHA022WJZZY AC V LUG
P2003 QPLGNB148WJZZY AC V PLUG
P502 QPLGNB149WJZZY AC V PLUG
P2002 QPLGNB150WJZZY AC V PLUG
P501 QPLGNB260WJZZY AC V PLUG
J501 QSOCZA370WJQZY AD V SOCKET
SC1501 QSOCZA390WJQZY AE V SOCKET
SC1502 QSOCZA390WJQZY AE V SOCKET
FB506 RBLN-0104TAZZY AB V BALUN
FB507 RBLN-0104TAZZY AB V BALUN
FB503 RBLN-0244TAZZY AB V BALUN
FB1701 RBLN-A371WJQZY AB V BALUN
FB1702 RBLN-A371WJQZY AB V BALUN
FB1703 RBLN-A371WJQZY AB V BALUN
FB1704 RBLN-A371WJQZY AB V BALUN
FB3192 RBLN-A371WJQZY AB V BALUN
FB3501 RBLN-A371WJQZY AB V BALUN
FB9620 RBLN-A371WJQZY AB V BALUN
FB501 RBLN-A589WJQZY AA V BALUN
FB502 RBLN-A589WJQZY AA V BALUN
FB3301 RBLN-A589WJQZY AA V BALUN
FB9601 RBLN-A589WJQZY AA V BALUN
FB9602 RBLN-A589WJQZY AA V BALUN
FB9604 RBLN-A589WJQZY AA V BALUN
FB9606 RBLN-A589WJQZY AA V BALUN
FB9607 RBLN-A589WJQZY AA V BALUN
FB9616 RBLN-A589WJQZY AA V BALUN
FB510 RBLN-A593WJQZY AA V BALUN
FB511 RBLN-A593WJQZY AA V BALUN
FB512 RBLN-A593WJQZY AA V BALUN
FB513 RBLN-A593WJQZY AA V BALUN
FB514 RBLN-A593WJQZY AA V BALUN
FB1105 RBLN-A593WJQZY AA V BALUN
FB1106 RBLN-A593WJQZY AA V BALUN
FB2001 RBLN-A593WJQZY AA V BALUN
FB2004 RBLN-A593WJQZY AA V BALUN
FB2005 RBLN-A593WJQZY AA V BALUN
FB2006 RBLN-A593WJQZY AA V BALUN
FB2007 RBLN-A593WJQZY AA V BALUN
FB3814 RBLN-A593WJQZY AA V BALUN
FB3815 RBLN-A593WJQZY AA V BALUN
FB3816 RBLN-A593WJQZY AA V BALUN
FB3817 RBLN-A593WJQZY AA V BALUN
FB3818 RBLN-A593WJQZY AA V BALUN
FB3821 RBLN-A593WJQZY AA V BALUN
FB3822 RBLN-A593WJQZY AA V BALUN
FB3823 RBLN-A593WJQZY AA V BALUN
FB3824 RBLN-A593WJQZY AA V BALUN
FB3825 RBLN-A593WJQZY AA V BALUN
FB3826 RBLN-A593WJQZY AA V BALUN
FB3827 RBLN-A593WJQZY AA V BALUN
FB9603 RBLN-A593WJQZY AA V BALUN
FB9605 RBLN-A593WJQZY AA V BALUN
FB9615 RBLN-A593WJQZY AA V BALUN
C1704 RC-KZA213WJZZY AC V CAPACITOR
C1705 RC-KZA213WJZZY AC V CAPACITOR
C1713 RC-KZA213WJZZY AC V CAPACITOR
C1714 RC-KZA213WJZZY AC V CAPACITOR
C501 RC-KZA237WJZZY AB V CAPACITOR
C502 RC-KZA237WJZZY AB V CAPACITOR
C506 RC-KZA237WJZZY AB V CAPACITOR
C1114 RC-KZA237WJZZY AB V CAPACITOR
C1715 RC-KZA237WJZZY AB V CAPACITOR
