Sharp 32C241 User Manual

9
32C240
32C241
EX1 FAO VOLUME 0-50 (00h-32h) 36 (24h) 24
EX2 CC-POSITION 0-127 (00h-7Fh) 27 (1Bh)
EX3 INT 0-255 (00h-FFh) 122 (7Ah) Interrupt period adjustment. 7A
EX4 A-ATT 0-127 (00h-7Fh) 90 (5Ah) 5A
EX5 TUNER data 0-3 (00h-03h) 0 (00h) 00
EX6 Think chip-Slice LEVEL 0-255 (00h-FFh) 54 (36h) 12
EX7 RLY DELAY TIME 0-255 (00h-FFh) 0 (00h) For the power control 00
EX8 ADG ON TIME 0-255 (00h-FFh) 10 (0Ah) For the power control 0A
OP1 OPTION1 0-255 (00h-FFh) 245 (F5h) B5
OP2 OPTION2 0-255 (00h-FFh) 188 (BCh) 08
OP3 OPTION3 0-255 (00h-FFh) 15 (0Fh) 8C
M01 INPUT LEVEL 0-15 (00h-0Fh) 7 (07h)
M02 MTS VCO 0-63 (00h-3Fh) 38 (26h)
M03 FILTER 0-63 (00h-3Fh) 36 (24h)
M04 WIDEBAND 0-63 (00h-3Fh) 28 (1Ch)
M05 SPECTRAL 0-63 (00h-3Fh) 23 (17h)
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
B. SPECIAL SETTING
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
C. OPTION SETTING
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
D. SOUND ADJUSTMENT
NECESSARY UNNECESSARY
ADJUSTMENT
PART REPLACED
IC2001
IC201
X
Data is stored in IC2101.
The adjustment is needed to compensate for characteristics of parts
including IC201 and MTS level (M01).
Holding down both the VOL-up and CH-up buttons on the TV set at service mode for more than 2 seconds will
automatically write the above initial values into IC2101.
NOTES
X
IC2101
IC3001
CRT
Holding down both the VOL-up and CH-up buttons on the TV set in
the service mode for more than 2 seconds will automatically write the
above initial values into IC2101 Then perform a complete adjustment.
Adjust items related to picture tube only.
Adjust items related to MTS only (M01~M05).
X
X
X
