Sharp 32SC26B Service Manual

PWB-A: DUNTKD571WEA7
MAIN UNIT
Ref. No. Part No.  Description Code
C926 VCEA0A1EW476M+ X 47 25V EL. AA
C928 VCEA0A1HW105M+ X 1 50V EL. AA
C930 VCEA0A1HW475M+ X 4.7 50V EL. AA
C931 VCKYCY1HB183KY X 0.018 50V Ceramic AA
C932 VCKYCY1HB183KY X 0.018 50V Ceramic AA
C933 VCEA0A1HW475M+ X 4.7 50V EL. AA
C934 VCEA0A1EW476M+ X 47 25V EL. AA
C935 VCEA0A1HW475M+ X 4.7 50V EL. AA
C936 VCEA0A1HW475M+ X 4.7 50V EL. AA
C937 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C953 VCKYCY1HB681KY X 680p 50V Ceramic AA
C956 VCEA0A1CW477M+ X 470 16V EL. AB
C962 VCCCCY1HH470JY X 47p 50V Ceramic AA
C1101 VCCCCY1HH271JY X 270p 50V Ceramic AA
C1102 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C1103 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1104 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C1105 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1106 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C1107 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1108 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C1109 VCKYCY0JF105ZY X 1000000pF 6.3V Ceramic AA
C1110 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C1111 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C1112 VCKYCY0JF105ZY X 1000000pF 6.3V Ceramic AA
C1113 VCEA0A1CW476M+ X 47 16V EL. AA
C1114 VCKYCY0JF105ZY X 1000000pF 6.3V Ceramic AA
C1115 VCKYCY0JF105ZY X 1000000pF 6.3V Ceramic AA
C1116 VCEA0A1AW477M+ X 470 10V EL. AB
C1117 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C1118 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C1120 VCEA0A1HW475M+ X 4.7 50V EL. AA
C1434 VCEA0A1EW476M+ X 47 25V EL. AA
C1437 VCEA0A1EW476M+ X 47 25V EL. AA
C2001 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2002 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C2025 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2040 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2041 VCEA0A1HW105M+ X 1 50V EL. AA
C2044 VCCCCY1HH100DY X 10p 50V Ceramic AA
C2046 VCEA0A1EW476M+ X 47 25V EL. AA
C2047 VCKYCY1CB473KY X 0.047 16V Ceramic AA
C2060 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2061 VCCCCY1HH101JY X 100p 50V Ceramic AA
C2062 VCEA0A1CW107M+ X 100 16V EL. AA
C2063 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2064 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C2201 VCKYCY1HB681KY X 680p 50V Ceramic AA
C2202 VCCCCY1HH330JY X 33p 50V Ceramic AA
C2601 VCEA0A1EW476M+ X 47 25V EL. AA
C2602 VCCCCY1HH101JY X 100p 50V Ceramic AA
C3001 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3002 VCKYCY1HB562KY X 5600p 50V Ceramic AA
C3003 VCKYCY1EB123KY X 0.012 25V Ceramic AA
C3004 VCEA0A1HW105M+ X 1 50V EL. AA
C3005 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3006 VCEA0A1HW106M+ X 10 50V EL. AA
C3007 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3008 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C3009 VCEA0A1CW477M+ X 470 16V EL. AB
C3010 VCE9GA1HW475M+ X 4.7 50V EL. AB
C3011 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3012 VCEA0A1HW475M+ X 4.7 50V EL. AA
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
Ref. No. Part No.  Description Code
C3013 VCKYCY1HB272KY X 2700p 50V Ceramic AA
C3014 VCKYCY1CB473KY X 0.05 16V Ceramic AA
C3015 VCEACA1HC335K+ X 3.3 50V EL. AC
C3016 VCE9GA1HW475M+ X 4.7 50V EL. AB
C3017 VCEACA1CC106K+ X 10 16V EL. AC
C3018 VCEA0A1HW105M+ X 1 50V EL. AA
C3019 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3020 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3021 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3022 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3025 VCKYCY1CB473KY X 0.05 16V Ceramic AA
C3027 VCKYCY1CB473KY X 0.05 16V Ceramic AA
C3028 VCKYCY1HB682KY X 6800p 50V Ceramic AA
C3029 VCKYCY1HB682KY X 6800p 50V Ceramic AA
C3036 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3038 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C3039 VCEA0A1HW475M+ X 4.7 50V EL. AA
C3040 VCEA0A1AW227M+ X 220 10V EL. AB
C3041 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C3043 VCEA0A1CW106M+ X 10 16V EL. AA
RJ7 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ8 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ11 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ12 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ14 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ16 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ17 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ20 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ21 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ23 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ24 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ25 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ30 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ33 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ36 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ38 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ39 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ40 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ42 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ45 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ48 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ49 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ50 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
RJ51 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R201 VRS-CY1JF151JY X 150 1/16W M-Ox. AA
R202 VRS-CY1JF122JY X 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270JY X 27 1/16W M-Ox. AA
R205 VRS-CY1JF331JY X 330 1/16W M-Ox. AA
R206 VRD-RA2BE101JY X 100 1/8W Carbon AA
R211 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R212 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R225 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R226 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R227 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R232 VRS-CY1JF471JY X 470 1/16W M-Ox. AA
R234 VRD-RA2BE271JY X 270 1/8W Carbon AA
R236 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R301 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R305 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R306 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R307 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R308 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R355 VRD-RA2BE821JY X 820 1/8W Carbon AA
R361 VRD-RA2BE224JY X 220k 1/8W M-Ox. AA
R362 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R363 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
32SC260
