Sharp 32SC26B Service Manual

PWB-A: DUNTKD571WEA7
MAIN UNIT
Ref. No. Part No.  Description Code
R2047 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2048 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2051 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2054 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R2060 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2061 VRS-CY1JF562JY X 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF223JY X 22k 1/16W M-Ox. AA
R2063 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2064 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R2084 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2085 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2086 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2087 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2088 VRS-CY1JF224JY X 220k 1/16W M-Ox. AA
R2089 VRS-CY1JF273JY X 27k 1/16W M-Ox. AA
R2090 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2092 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2093 VRS-CY1JF224JY X 220k 1/16W M-Ox. AA
R2094 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R2095 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2096 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2101 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101JY X 100 1/16W M-Ox. AA
R2201 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2202 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2203 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R2211 VRS-CY1JF222JY X 2.2k 1/16W M-Ox. AA
R2212 VRS-CY1JF682JY X 6.8k 1/16W M-Ox. AA
R2213 VRS-CY1JF333JY X 33k 1/16W M-Ox. AA
R2401 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2402 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2403 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2404 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2501 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2502 VRS-CY1JF183JY X 18k 1/16W M-Ox. AA
R2503 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2504 VRS-CY1JF103JY X 10k 1/16W M-Ox. AA
R2505 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R2506 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R2507 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R2508 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R2509 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2601 VRD-RA2BE100JY X 10 1/8W Carbon AA
R2603 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2605 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R2606 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3001 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R3002 VRS-CY1JF221JY X 220 1/16W M-Ox. AA
R3003 VRS-CY1JF105JY X 1M 1/16W M-Ox. AA
R3004 VRS-CY1JF104JY X 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623JY X 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332JY X 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302JY X 3k 1/16W M-Ox. AA
R3010 VRS-CY1JF392JY X 3.9k 1/16W M-Ox. AA
R3011 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3012 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3017 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3018 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3024 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R3027 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3029 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R3030 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R3031 VRS-CY1JF474JY X 470k 1/16W M-Ox. AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No.  Description Code
R3032 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3033 VRS-CY1JF474JY X 470k 1/16W M-Ox. AA
R3034 VRS-CY1JF000JY X 00 1/16W M-Ox. AA
R3035 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3036 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
R3037 VRS-CY1JF153JY X 15k 1/16W M-Ox. AA
R3038 VRS-CY1JF473JY X 47k 1/16W M-Ox. AA
R3039 VRS-CY1JF102JY X 1k 1/16W M-Ox. AA
S2501 QSW-K0003AJZZ+ X Push button switch AB
S2502 QSW-K0003AJZZ+ X Push button switch AB
S2503 QSW-K0003AJZZ+ X Push button switch AB
S2504 QSW-K0003AJZZ+ X Push button switch AB
S2505 QSW-K0003AJZZ+ X Push button switch AB
S2506 QSW-K0003AJZZ+ X Push button switch AB
FB601 RBLN-0047CEZZY X Ferrite Bead AB
FB706 RBLN-0037CEZZY X Ferrite Bead AA
FB707 RBLN-0020CEZZ+ X Ferrite Bead AB
FB1103 RBLN-0210TAZZY X Ferrite Bead AB
FB1104 RBLN-0210TAZZY X Ferrite Bead AB
FB2001 RBLN-0037CEZZY X Ferrite Bead AA
U
ACC701 QACCDA012WJPZ X AC Cord AH
F701 QFS-B4023CEZZ X FUSE - 4A 125V AC
FH701 QFSHD1013CEZZ+ X FUSE CLIP AA
FH702 QFSHD1014CEZZ+ X FUSE CLIP AA
J904 QJAKGA033WJZZ X Jack, Front AV IN JACK AE
J921 QSOCD0456CEZZ X Socket, S-Video AD
J1401 QTANJ1101SEZZ X AV In/Out Terminal AH
P361 QPLGN0461CEZZA X plug,4pin(S1-4) AB
P402 QPLGN0661CEZZA X plug,6pin AB
P601 QPLGN0161FJZZ X plug 6Pin(K1-6) AD
P622 QPLGN0461CEZZA X plug,4pin(S1-4) AB
P651 QPLGN0361CEZZA X plug,3pin (TP651-3) AB
P702 QPLGN0269GEZZ X plug 2pin(P1-2) AB
P703 QPLGN0260CEZZ X plug 2pin(M1-2) AB
P721 QPLGN0461CEZZA X plug,4pin(S1-4) AB
P722 QPLGN0461CEZZA X plug,4pin(S1-4) AB
P1101 QPLGN0561CEZZA X plug 5Pin(KA) AB
P2401 QPLGN0661CEZZA X plug,6pin AB
RDA361 PRDAR0258PEFW X Heat Sink for IC361 AE
RDA501 PRDARA039WJFW X Heat Sink for IC501 AF
RDA601 PRDARA041WJFW X Heat Sink for Q602 AF
RDA671 PRDARA057WJFW X Heat Sink for Q671 AE
RDA701 PRDAR0279PEFW X Heat Sink for Q701 AD
RDA750 PRDAR5072CEFW X Heat Sink for IC750 AC
RDA1101 PRDAR5072CEFW X Heat Sink for IC1101 AC
RDA1102 PRDAR5072CEFW X Heat Sink for IC1102 AC
RDA1403 PRDAR5072CEFW X Heat Sink for IC1403 AC
RMC2601 RRMCUA022WJZZ X R/C Receiver AE
U
RY701 RRLYJ0081CEZZ X Relay AE
U
RY702 RRLYJ0088CEZZ X Relay AE
TP701 QLUGP0102PEZZ X Test point AA
SWITCHES
FERRITE BEAD
MISCELLANEOUS PARTS
