Sharp 32SC26B Service Manual

SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
EX1 FAO VOLUME 0-50 (00h-32h) 36 (24h) 24
EX2 CC-POSITION 0-127 (00h-7Fh) 27 (1Bh) 1C
EX3 INT 0-255 (00h-FFh) 122 (7Ah) Interrupt period adjustment 7A
EX4 A-ATT 0-127 (00h-7Fh) 90 (5Ah) 5A
EX5 TUNER data 0-3 (00h-03h) 00 (00h) 00
EX6 Think chip-Slice LEVEL 0-255 (00h-FFh) 54 (36h) 12
EX7 RLY DELAY TIME 0-255 (00h-FFh) 00 (00h) For the power control 00
EX8 ADG ON TIME 0-255 (00h-FFh) 10 (0Ah) For the power control 0A
B. SPECIAL SETTING
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
C. OPTION SETTING
OP1 OPTION1 0-255 (00h-FFh) 213 (D5h) D5
OP2 OPTION2 0-255 (00h-FFh) 60 (3Ch) 18
OP3 OPTION3 0-255 (00h-FFh) 143 (8Fh) 9C
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
D. SOUND ADJUSTMENT
M01 INPUT LEVEL 0-15 (00h-0Fh) 07 (07h)
M02 MTS VCO 0-63 (00h-3Fh) 38 (26h) 26
M03 FILTER 0-63 (00h-3Fh) 36 (24h) 24
M04 WIDEBAND 0-63 (00h-3Fh) 28 (1Ch)
M05 SPECTRAL 0-63 (00h-3Fh) 23 (17h)
D01 V POSITION 0-7 (00h-07h) 00 (00h) 00
D02 H POSITION 0-31 (00h-1Fh) 15 (0Fh)
D03 V SIZE 0-127 (00h-7Fh) 89 (59h)
D04 H SIZE 0-63 (00h-3Fh) 36 (24h)
D05 V-LINEARITY 0-15 (00h-0Fh) 08 (08h)
D06 V-S CORRECTION 0-15 (00h-0Fh) 12 (0Ch) 0B
D07 EW PARABOLA 0-63 (00h-3Fh) 43 (2Bh)
D08 EW TRAPEZIUM 0-63 (00h-3Fh) 36 (24h)
D10 AFC GAIN 0-3 (00h-03h) 02 (02h) 02
D11 V EHT 0-7 (00h-07h) 06 (06h) 06
D12 H EHT 0-7 (00h-07h) 06 (06h) 06
D13 EW CORNER 0-31 (00h-1Fh) 08 (08h) 0F
D14 EW CORNER BOTTOM 19-81 (13h-51h) 50 (32h) 32
D15 NOISE DET LEVEL 0-3 (00h-03h) 00 (00h) 00
D18 V CENTERING 0-63 (00-3Fh) 36 (24h)
D19 V-AGC 0-1 (00h-01h) 00 (00h) 00
D20 V POSITION-VCOMP 0-7 (00h-07h) 00 (00h) 16:9 Format 00
D21 H POSITION-VCOMP 0-31 (00h-1Fh) 15 (0Fh) 16:9 Format "D2"
D22 V SIZE-VCOMP 0-127 (00h-7Fh) 52 (34h) 16:9 Format "D3" -30
D23 H SIZE-VCOMP 0-63 (00h-3Fh) 36 (24h) 16:9 Format "D4"
D24 V-LINEARITY-VCOMP 0-15 (00h-0Fh) 08 (08h) 16:9 Format 08
D25 V-S CORRECTION-VCOMP 0-15 (00h-0Fh) 10 (0Ah) 16:9 Format 0A
D26 EW PARABOLA-VCOMP 0-63 (00h-3Fh) 22 (16h) 16:9 Format 15
D27 EW TRAPEZIUM-VCOMP 0-63 (00h-3Fh) 35 (23h) 16:9 Format "D8"
D28 V EHT-VCOMP 0-7 (00h-07h) 06 (06h) 16:9 Format 06
D29 H EHT-VCOMP 0-7 (00h-07h) 06 (06h) 16:9 Format 06
D30 EW CORNER-VCOMP 0-31 (00h-1Fh) 12 (0Ch) 16:9 Format 10
D31 EW CORNER BOTTOM-VCOMP 19-81 (13h-51h) 50 (32h) Offset toward D30 32
D32 V BLK UPPER-VCOMP 0-3 (00h-03h) 02 (02h) 16:9 Format 02
D33 V BLK LOWER-VCOMP 0-3 (00h-03h) 02 (02h) 16:9 Format 02
D34 V CENTERING-VCOMP 0-63 (00h-3Fh) 36 (24h) 16:9 Format "D18"
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
NOTES FIXED VALUE
(HEX)
RANGE
32SC260
8
