Sharp 32U-S50B Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
28
32U-S50B
32U-S60B
R307 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R308 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R361 VRD-RA2BE224J∗ X 220k 1/8W Carbon AA
R362 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R363 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R364 VRD-RA2BE102J∗ X 1k 1/8W Carbon AA
R365 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R368 VRD-RA2BE222J∗ X 2.2k 1/8W Carbon AA
R369 VRD-RA2BE822J∗ X 8.2k 1/8W Carbon AA
R371 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R372 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R403 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R422 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R430 VRS-CY1JF391J∗ X 390 1/16W Metal Oxide AA
R431 VRS-CY1JF331J∗ X 330 1/16W Metal Oxide AA
R432 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R436 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R439 VRS-CY1JF104J∗ X 100k 1/16W Metal Oxide AA
R441 VRS-CY1JF472J∗ X 4.7k 1/16W Metal Oxide AA
R442 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R444 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R445 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R446 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R447 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R448 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R449 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
å R451 VRS-RG3AB103J+ X 10k 1W Metal Oxide AB
R452 VRD-RM2HD823J∗ X 82k 1/2W Carbon AA
R453 VRD-RM2HD223J∗ X 22k 1/2W Carbon AA
R454 VRS-CY1JF471J∗ X 470 1/16W Metal Oxide AA
R456 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R460 VRS-CY1JF471J∗ X 470 1/16W Metal Oxide AA
R461 VRS-CY1JF562J∗ X 5.6k 1/16W Metal Oxide AA
R462 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R463 VRD-RA2EE680J∗ X 68 1/4W Carbon AA
R464 VRS-CY1JF683J∗ X 68k 1/16W Metal Oxide AA
R465 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R466 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R467 VRS-CY1JF123J∗ X 12k 1/16W Metal Oxide AA
R483 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
'åR501 VRN-RL3ABR47J+ X 0.47 1W Metal Film AB
R502 VRN-RA2BK822F∗ X 8.2k 1/8W Metal Film AA
R503 VRS-CY1JF105J∗ X 1M 1/16W Metal Oxide AA
R504 VRS-CY1JF154J∗ X 150k 1/16W Metal Oxide AA
R505 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R510 VRN-RA2BK103F∗ X 10k 1/8W Metal Film AA
R511 VRN-RA2BK222F∗ X 2.2k 1/8W Metal Film AA
R512 VRN-RA2BK272F∗ X 2.7k 1/8W Metal Film AA
R513 VRD-RM2HD1R0J∗ X 1 1/2W Carbon AA
R517 VRS-CY1JF104J∗ X 100k 1/16W Metal Oxide AA
R518 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R521 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
å R523 VRN-RL3DBR82J+ X 0.82 2W Metal Film AB
å R524 VRS-RG3AB391J+ X 390 1W Metal Oxide AB
R601 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R603 VRD-RA2BE472J∗ X 4.7k 1/8W Carbon AA
å R604 VRS-KA3NG222J X 2.2k 7W Metal Oxide AB
R605 VRD-RM2HD331J∗ X 330 1/2W Carbon AA
R606 VRD-RM2HD331J∗ X 330 1/2W Carbon AA
å R609 VRS-RG3AB562J+ X 5.6k 1W Metal Oxide AB
R610 VRD-RM2HD220J∗ X 22 1/2W Carbon AA
å R611 VRW-KQ41C3R3K X 3.3 15W Cement AC
R612 VRS-CY1JF154J∗ X 150k 1/16W Metal Oxide AA
R613 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R614 VRS-CY1JF562J∗ X 5.6k 1/16W Metal Oxide AA
R618 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
å R621 VRN-RL3DB1R2J+ X 1.2 2W Metal Film AB
å R622 VRN-RL3ABR27J+ X 0.27 1W Metal Film AB
å R623 VRN-RL3AB4R7J+ X 4.7 1W Metal Film AB
å R624 VRS-RG3DB332J+ X 3.3k 2W Metal Oxide AB
R625 VRD-RA2BE102J∗ X 1k 1/8W Carbon AA
'åR627 VRN-RL3ABR47J+ X 0.47 1W Metal Film AB
å R628 VRN-RL3ABR47J+ X 0.47 1W Metal Film AB
'åR651 VRS-RG2HC270J+ X 27 1/2W Metal Oxide AB
'åR652 VRD-RA2EE103G∗ X 10k 1/4W Carbon AA
'åR653 VRD-RA2EE562G∗ X 5.6k 1/4W Carbon AA
å R658 VRS-RG3LB333J+ X 33k 3W Metal Oxide AB
R663 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R670 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R684 VRD-RA2BE472J∗ X 4.7k 1/8W Carbon AA
R685 VRD-RA2BE822J∗ X 8.2k 1/8W Carbon AA
R686 VRD-RA2EE332J∗ X 3.3k 1/4W Carbon AA
R687 VRD-RA2BE103J∗ X 10k 1/8W Carbon AA
å R688 VRN-RL3DB3R3J+ X 3.3 2W Metal Film AB
R689 VRD-RM2HD824J∗ X 820k 1/2W Carbon AA
å R690 VRS-RG3LB471J+ X 470 3W Metal Oxide AB
R691 VRS-CY1JF394J∗ X 390k 1/16W Metal Oxide AA
R692 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R693 VRS-CY1JF683J∗ X 68k 1/16W Metal Oxide AA
R694 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R695 VRS-CY1JF683J∗ X 68k 1/16W Metal Oxide AA
R696 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
å R701 RR-DZ0049CEZZ∗ X 3.9M 1/2W Sloid AB
å R703 VRW-KQ4AC1R2K X 1.2 10W Cement AB
å R705 VRN-RL3DBR15J+ X 0.15 2W Metal Film AB
å R706 VRN-RL3DBR18J+ X 0.18 2W Metal Film AB
R707 VRD-RM2HD270J∗ X 27 1/2W Carbon AA
R708 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R709 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
å R710 VRS-RG2HC103J+ X 10k 1/2W Metal Oxide AB
R711 VRS-CY1JF334J∗ X 330k 1/16W Metal Oxide AA
R712 VRD-RM2HD100J∗ X 10 1/2W Carbon AA
å R713 VRS-RG2HC122J+ X 1.2k 1/2W Metal Oxide AB
R715 VRD-RM2HD5R6J∗ X 5.6 1/2W Carbon AA
R716 VRD-RM2HD100J∗ X 10 1/2W Carbon AA
R720 VRD-RA2BE473J∗ X 47k 1/8W Carbon AA
R724 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R725 VRD-RM2HD221J∗ X 220 1/2W Carbon AA
R734 VRD-RM2HD124J∗ X 120k 1/2W Carbon AA
å R737 VRN-RL3DBR56J+ X 0.56 2W Metal Film AB
R742 VRD-RA2BE222J∗ X 2.2k 1/8W Carbon AA
R743 VRD-RM2HD470J∗ X 47 1/2W Carbon AA
R751 VRD-RA2BE473J∗ X 47k 1/8W Carbon AA
R752 VRD-RA2BE392J∗ X 3.9k 1/8W Carbon AA
R753 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R754 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R755 VRS-CY1JF473J∗ X 47k 1/16W Metal Oxide AA
R756 VRD-RA2BE152J∗ X 1.5k 1/8W Carbon AA
å R757 VRN-RL3DB4R7J+ X 4.7 2W Metal Film AB
R759 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R761 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R762 VRD-RA2BE103J∗ X 10k 1/8W Carbon AA
R764 VRD-RM2HD562J∗ X 5.6k 1/2W Carbon AA
R767 VRD-RM2HD151J∗ X 150 1/2W Carbon AA
R768 VRD-RA2BE473J∗ X 47k 1/8W Carbon AA
R770 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R775 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R776 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R801 VRS-CY1JF333J∗ X 33k 1/16W Metal Oxide AA
R802 VRS-CY1JF471J∗ X 470 1/16W Metal Oxide AA
R803 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R805 VRS-CY1JF682J∗ X 6.8k 1/16W Metal Oxide AA
R806 VRS-CY1JF681J∗ X 680 1/16W Metal Oxide AA
R807 VRS-CY1JF681J∗ X 680 1/16W Metal Oxide AA
R808 VRS-CY1JF681J∗ X 680 1/16W Metal Oxide AA
R810 VRS-CY1JF472J∗ X 4.7k 1/16W Metal Oxide AA
R927 VRS-CY1JF750J∗ X 75 1/16W Metal Oxide AA
R929 VRS-CY1JF473J∗ X 47k 1/16W Metal Oxide AA
R930 VRS-CY1JF473J∗ X 47k 1/16W Metal Oxide AA
R934 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R939 VRS-CY1JF333J∗ X 33k 1/16W Metal Oxide AA
R941 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R942 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R943 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R944 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R945 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R946 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R947 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
PWB-A: DUNTKB567WEV6
MAIN UNIT(Continued)
