Sharp 32U-S50B Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
29
32U-S50B
32U-S60B
R948 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R949 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R950 VRS-CY1JF750J∗ X 75 1/16W Metal Oxide AA
R951 VRD-RA2BE680J∗ X 68 1/8W Carbon AA
R952 VRS-CY1JF333J∗ X 33k 1/16W Metal Oxide AA
R954 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R955 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R957 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R958 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R959 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R960 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R961 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R962 VRS-CY1JF332F∗ X 3.3k 1/16W Metal Oxide AA
R964 VRS-CY1JF152J∗ X 1.5k 1/16W Metal Oxide AA
R967 VRS-CY1JF682J∗ X 6.8k 1/16W Metal Oxide AA
R968 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R969 VRS-CY1JF472F∗ X 4.7k 1/16W Metal Oxide AA
R970 VRD-RA2BE6R8J∗ X 6.8 1/8W Carbon AA
R971 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R972 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R973 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R982 VRS-CY1JF750J∗ X 75 1/16W Metal Oxide AA
R983 VRS-CY1JF473J∗ X 47k 1/16W Metal Oxide AA
R984 VRS-CY1JF473J∗ X 47k 1/16W Metal Oxide AA
å R1420 VRN-RL3LB2R7J+ X 2.7 3W Metal Film AB
R2001 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R2004 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2006 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R2008 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R2010 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R2021 VRS-CY1JF334J∗ X 330k 1/16W Metal Oxide AA
R2024 VRS-CY1JF472J∗ X 4.7k 1/16W Metal Oxide AA
R2025 VRS-CY1JF472J∗ X 4.7k 1/16W Metal Oxide AA
R2026 VRS-CY1JF472J∗ X 4.7k 1/16W Metal Oxide AA
R2027 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R2028 VRD-RA2BE102J∗ X 1k 1/8W Carbon AA
R2031 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R2033 VRS-CY1JF334J∗ X 330k 1/16W Metal Oxide AA
R2040 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R2041 VRS-CY1JF333J∗ X 33k 1/16W Metal Oxide AA
R2042 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2043 VRS-CY1JF333J∗ X 33k 1/16W Metal Oxide AA
R2044 VRS-CY1JF153J∗ X 15k 1/16W Metal Oxide AA
R2046 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2047 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R2048 VRS-CY1JF562J∗ X 5.6k 1/16W Metal Oxide AA
R2051 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R2060 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R2061 VRS-CY1JF562J∗ X 5.6k 1/16W Metal Oxide AA
R2062 VRS-CY1JF223J∗ X 22k 1/16W Metal Oxide AA
R2063 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R2064 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R2073 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R2084 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R2086 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2090 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2092 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2101 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2102 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R2201 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R2202 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R2203 VRS-CY1JF473J∗ X 47k 1/16W Metal Oxide AA
R2211 VRS-CY1JF222J∗ X 2.2k 1/16W Metal Oxide AA
R2212 VRS-CY1JF682J∗ X 6.8k 1/16W Metal Oxide AA
R2213 VRS-CY1JF333J∗ X 33k 1/16W Metal Oxide AA
R2401 VRD-RA2BE101J∗ X 100 1/8W Carbon AA
R2402 VRD-RA2BE101J∗ X 100 1/8W Carbon AA
R2403 VRD-RA2BE101J∗ X 100 1/8W Carbon AA
R2404 VRD-RA2BE101J∗ X 100 1/8W Carbon AA
R2501 VRS-CY1JF183J∗ X 18k 1/16W Metal Oxide AA
R2502 VRS-CY1JF183J∗ X 18k 1/16W Metal Oxide AA
R2503 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R2504 VRS-CY1JF103J∗ X 10k 1/16W Metal Oxide AA
R2505 VRD-RA2BE822J∗ X 8.2k 1/8W Carbon AA
R2506 VRD-RA2BE822J∗ X 8.2k 1/8W Carbon AA
R2507 VRD-RA2BE183J∗ X 18k 1/8W Carbon AA
R2508 VRD-RA2BE183J∗ X 18k 1/8W Carbon AA
R2509 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R2601 VRD-RA2BE100J∗ X 10 1/8W Carbon AA
R2603 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R2605 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R2606 VRS-CY1JF000J∗ X 0 1/16W Metal Oxide AA
R3001 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R3002 VRS-CY1JF221J∗ X 220 1/16W Metal Oxide AA
R3003 VRS-CY1JF105J∗ X 1M 1/16W Metal Oxide AA
R3004 VRS-CY1JF104J∗ X 100k 1/16W Metal Oxide AA
R3005 VRS-CY1JF623J∗ X 62k 1/16W Metal Oxide AA
R3007 VRS-CY1JF332J∗ X 3.3k 1/16W Metal Oxide AA
R3008 VRS-CY1JF302J∗ X 3k 1/16W Metal Oxide AA
R3010 VRS-CY1JF392J∗ X 3.9k 1/16W Metal Oxide AA
R3017 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R3018 VRS-CY1JF102J∗ X 1k 1/16W Metal Oxide AA
R3019 VRS-CY1JF101J∗ X 100 1/16W Metal Oxide AA
R3024 VRD-RA2BE102J∗ X 1k 1/8W Carbon AA
SWITCHES
S2501 QSW-KA003WJZZ+ X Switch, POWER AB
S2502 QSW-KA003WJZZ+ X Switch, MENU AB
S2503 QSW-KA003WJZZ+ X Switch, VOL.-DOWN AB
S2504 QSW-KA003WJZZ+ X Switch, VOL.-UP AB
S2505 QSW-KA003WJZZ+ X Switch, CH-DOWN AB
S2506 QSW-KA003WJZZ+ X Switch, CH-UP AB
MISCELLANEOUS PARTS
å ACC701 QACCDA012WJPZ X AC Cord AE
CF2040 RCRM-0003CEZZ+ X Ceramic Vibrator AC
FB601 RBLN-0047CEZZ∗ X Balun AB
FB706 RBLN-0037CEZZ∗ X Balun AA
FB2001RBLN-0037CEZZ∗ X Balun AA
å F701 QFS-B4023CEZZ X Fuse, 4A/125V AB
FH701 QFSHD1013CEZZ+ X Fuse Holder AA
FH702 QFSHD1014CEZZ+ X Fuse Holder AA
J904 QJAKGA032WJZZ X Front AV In Jack AC
J921 QSOCD0430CEZZ X S-Video Terminal AC
J1403 QTANJ0345CEZZ X AV In/Out Terminal AD
P361 QPLGN0461CEZZA X Plug, 4pin(S1-4) AB
P402 QPLGN0661CEZZA X Plug, 6pin(CJ) AB
P601 QPLGN0161FJZZ X Plug, 6pin(K1-6) AB
P622 QPLGN0461CEZZA X Plug, 4pin(YBN) AB
P651 QPLGN0361CEZZA X Plug, 3pin(TP651-3) AB
P702 QPLGN0269GEZZ X Plug, 2pin(P1-2) AB
P703 QPLGN0260CEZZ X Plug, 2pin(M1-2) AB
P2401 QPLGN0661CEZZA X Plug, 6pin AB
RMC2601 RRMCU0222CEZZ X Remote Receiver AD
RY701 RRLYJ0081CEZZ X Relay AD
TP701 QLUGP0102PEZZ X Lug AA
RDA361 PRDAR0258PEFW X Heat Sink for IC361 AC
RDA501 PRDARA039WJFW X Heat Sink for IC501 AD
RDA601 PRDARA041WJFW X Heat Sink for Q602 AD
RDA671 PRDARA057WJFW X Heat Sink for Q673 AC
RDA701 PRDAR0279PEFW X Heat Sink for Q701 AB
RDA750 PRDAR5072CEFW X Heat Sink for IC751 AB
RDA1403 PRDAR5072CEFW X Heat Sink for IC1403 AB
SLD1801 PSLDM0012MEFW X Shield AD
PWB-A: DUNTKB567WEV6
MAIN UNIT(Continued)
