Sharp 32U-S50B Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
30
32U-S50B
32U-S60B
PWB-B: DUNTKB568WEV1
CRT UNIT
TRANSISTORS
Q850 VS2SC4544LB1E X 2SC4544LB AC
Q851 VS2SC4544LB1E X 2SC4544LB AC
Q852 VS2SC4544LB1E X 2SC4544LB AC
Q853 VS2SC3198-G-1+ X 2SC3198-G AB
Q854 VS2SC3198-G-1+ X 2SC3198-G AB
Q855 VS2SC3198-G-1+ X 2SC3198-G AB
Q890 VS2SC3198-G-1+ X 2SC3198-G AB
Q891 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q894 VS2SA1266-Y-1+ X 2SA1266-Y AB
DIODES
D850 VHD1SS119//-1∗ X 1SS119 AA
D851 VHD1SS119//-1∗ X 1SS119 AA
D852 VHD1SS119//-1∗ X 1SS119 AA
D891 VHD1SS119//-1∗ X 1SS119 AA
D892 VHD1SS119//-1∗ X 1SS119 AA
D893 VHD1SS119//-1∗ X 1SS119 AA
D894 VHD1SS119//-1∗ X 1SS119 AA
D895 VHD1SS119//-1∗ X 1SS119 AA
D896 RH-EX0616GEZZ∗ X Zener Diode, 5.6V AB
D897 VHD1SS119//-1∗ X 1SS119 AA
D898 VHD1SS119//-1∗ X 1SS119 AA
D899 VHD1SS119//-1∗ X 1SS119 AA
COILS
L852 VP-MK221K0000+ X Peaking, 220µHAB
L853 VP-MK221K0000+ X Peaking, 220µHAB
L854 VP-MK221K0000+ X Peaking, 220µHAB
CAPACITORS
C850 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C851 VCEA0A1CW107M+X 100 16V Electrolytic AA
C852 VCKYPA1HB102K+ X 1000p 50V Ceramic AA
C876 VCCSPA1HL561J+ X 560p 50V Ceramic AB
C877 VCCSPA1HL471J+ X 470p 50V Ceramic AA
C878 VCCSPA1HL561J+ X 560p 50V Ceramic AB
C879 VCEA0A1EW476M+X 47 25V Electrolytic AA
C880 RC-KZ018JCEZZ X 0.01 3KV Ceramic AB
C890 VCEA0A1CW227M+X 220 16V Electrolytic AB
C892 VCEA0A1HW106M+X 10 50V Electrolytic AA
C893 VCEA0A1HW106M+X 10 50V Electrolytic AA
C895 VCEA0A1HW226M+X 22 50V Electrolytic AA
C896 VCEA0A2EW106M+X 10 250V Electrolytic AB
RESISTORS
R842 VRD-RM2HD104J∗ X 100k 1/2W Carbon AA
R849 VRD-RA2BE271J∗ X 270 1/8W Carbon AA
R850 VRD-RA2BE561J∗ X 560 1/8W Carbon AA
R851 VRD-RA2BE561J∗ X 560 1/8W Carbon AA
R852 VRD-RA2BE561J∗ X 560 1/8W Carbon AA
R854 VRD-RA2BE271J∗ X 270 1/8W Carbon AA
R855 VRD-RA2BE271J∗ X 270 1/8W Carbon AA
R856 VRD-RA2BE121J∗ X 120 1/8W Carbon AA
R857 VRD-RA2BE121J∗ X 120 1/8W Carbon AA
R858 VRD-RA2BE121J∗ X 120 1/8W Carbon AA
å R859 VRS-VV3DB273J X 27k 2W Metal Oxide AA
å R860 VRS-VV3DB273J X 27k 2W Metal Oxide AA
å R861 VRS-VV3DB273J X 27k 2W Metal Oxide AA
å R862 VRS-VV3DB273J X 27k 2W Metal Oxide AA
å R863 VRS-VV3DB273J X 27k 2W Metal Oxide AA
å R864 VRS-VV3DB273J X 27k 2W Metal Oxide AA
R865 VRD-RA2BE103J∗ X 10k 1/8W Carbon AA
R868 VRD-RM2HD224J∗ X 220k 1/2W Carbon AA
R870 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R871 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R872 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R873 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R874 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R875 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R876 VRD-RA2BE121J∗ X 120 1/8W Carbon AA
R877 VRD-RA2BE121J∗ X 120 1/8W Carbon AA
R878 VRD-RA2BE121J∗ X 120 1/8W Carbon AA
R879 VRD-RM2HD100J∗ X 10 1/2W Carbon AA
R880 VRC-MA2HG332K∗ X 3.3k 1/2W Solid AB
R881 VRC-MA2HG332K∗ X 3.3k 1/2W Solid AB
R882 VRC-MA2HG332K∗ X 3.3k 1/2W Solid AB
R883 VRD-RA2BE221J∗ X 220 1/8W Carbon AA
R884 VRD-RA2BE221J∗ X 220 1/8W Carbon AA
R885 VRD-RA2BE221J∗ X 220 1/8W Carbon AA
R886 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R887 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R888 VRD-RA2BE471J∗ X 470 1/8W Carbon AA
R890 VRD-RA2BE562J∗ X 5.6k 1/8W Carbon AA
R891 VRD-RA2BE102G∗ X 1k 1/8W Carbon AA
R892 VRD-RA2BE331G∗ X 330 1/8W Carbon AA
R894 VRD-RA2BE152J∗ X 1.5k 1/8W Carbon AA
R895 VRD-RA2EE561J∗ X 560 1/4W Carbon AA
R899 VRD-RA2BE222J∗ X 2.2k 1/8W Carbon AA
MISCELLANEOUS PARTS
P860 QPLGN0441CEZZ X Plug, 4Pin AA
P880 QPLGN0641CEZZ X Plug, 6Pin(CJ) AB
SC850 QSOCV1011CEZZ X CRT Socket AC
MSPRT0002MEZZ X Spring AB
PWB-D: DUNTKB572WEV0
2 LINE Y/C UNIT
INTEGRATED CIRCUIT
IC1401 VHiTC90A45F-1∗ X TC90A45F AH
TRANSISTORS
Q1401 VS2SD601AR/-1∗ X 2SD601AR AA
Q1402 VS2SD601AR/-1∗ X 2SD601AR AA
Q1404 VS2SB709AR/-1∗ X 2SB709AR AA
COILS
L1401 VP-XF100K0000∗ X Peaking, 10µHAA
L1402 VP-XF100K0000∗ X Peaking, 10µHAA
L1403 VP-XF100K0000∗ X Peaking, 10µHAA
L1404 VP-XF220K0000∗ X Peaking, 22µHAA
L1405 VP-XF220K0000∗ X Peaking, 22µHAA
L1408 VP-XF100K0000∗ X Peaking, 10µHAA
CAPCITORS
C1401 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1402 VCEA0A1AW227M+X 220 10V Electrolytic AB
C1403 VCCCCY1HH330J∗ X 33p 50V Ceramic AA
C1404 VCCCCY1HH181J∗ X 180p 50V Ceramic AA
C1405 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1406 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1407 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1408 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1409 VCEA0A1CW476M+X 47 16V Electrolytic AA
C1410 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1411 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1412 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1413 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1414 VCE9GA1HW105M+X 1 50V Electrolytic(N.P) AB
C1415 VCCCCY1HH120J∗ X 12p 50V Ceramic AA
C1416 VCCCCY1HH3R0C∗X 3p 50V Ceramic AA
C1417 VCCCCY1HH270J∗ X 27p 50V Ceramic AA
C1418 VCCCCY1HH120J∗ X 12p 50V Ceramic AA
C1419 VCCCCY1HH3R0C∗X 3p 50V Ceramic AA
C1420 VCCCCY1HH270J∗ X 27p 50V Ceramic AA
C1423 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1424 VCEA0A1CW107M+X 100 16V Electrolytic AA
C1425 VCCCCY1HH820J∗ X 82p 50V Ceramic AA
C1429 VCEA0A1CW107M+X 100 16V Electrolytic AA
C1430 VCKYCY1CB104K∗ X 0.1 16V Ceramic AA
C1431 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
C1432 VCKYCY1HB103K∗ X 0.01 50V Ceramic AA
