37DM-23SC
53
54
55
56
57
58
59
5A
5B
5C
5D
5E
5F
60
61-FF
100-18Dh
OSDWORD 1: BIT 0:OSD PROG SIZE. 0= LARGE
1=SHORT
BIT 1 :OSD PROG DISPLAYED TIME.
0=SHORT TIME / 1 = LONG TIME
RED REFERENCE FOR AUTO BKGD ADJUSTMENT
GREEN REFERENCE FOR AUTO BKGD ADJUSTMENT
BLUE REFERENCE FOR AUTO BKGD ADJUSTMENT
CONTROL2: OSO, VSD, CB, BLS, BKS, CS1, CSO, BB
CONTROL3: HOB, BPS, ACL, CMB, AST, CL2, CL1, CLO
VERTICAL ZOOM APPROX.
VERTIVAL SCROLL APPROX.
CONTROL0: INA, INB, INC, CCC-D, FOA, FOB, XA, XB
CONTROL,-!: FORF, FORS, DL, STB, POC, CM2, CM1, CMO
CONTROL5: EVG, HCO, LBM, VID, STM, NCIN, VIM, AKB
CONTROL6: IFS, AFW, IE1, COR, RBL, MAT, PRD, SBL
CONTROL7: EVSINC, EBS, FFI, HBL, GAI, IE2, DS, DSA
NOT USED
PROGRAMS (0-52)
PROGRAMS (53-99)
(14")
(21-)
VALUE= 9AH
VALUE= 24H
VALUE-ODH
VALUE= 20H
VALUE=1AH
VALUE=COH
VALUE=26H
VALUE=3CH
VALUE=OOH
PIF/AGC Adjustment Screen Adjustment
1. VCO + AFT Adjustment 3. Focus Adjustment
1. Connect the output of SSG (Standard Signal Gen-
erator) to the tuner IF output terminal.
• SSG output: 38.9 MHz (CW) ±5 kHz).
• SSG output level: approx. 90 dB^iV.
2. Enter into Service Mode.
3. Push CH A until AFT appears.
4. Press 0-n button on R/C. Setting is made automati-
cally. During this setting the colour bar shall go from
red to yellow. When setting is finished, colour bar
disappears and B-STOP (bus stop) is shown on
screen.
5. Switch set OFF and ON again, setting is now memo-
rized.
1. Receive the "COLOUR BAR" signal (Channel E-12).
• Signal strength: 60 dB|AV.
2. Enter into Service Mode.
3. Push CH A until AGC appears.
4. Press On button on R/C. Setting is made automati-
cally. During this setting the colour bar shall go from
red to yellow. When setting is finished, colour bar
disappears and B-STOP (bus stop) is shown on
screen.
5. Switch set OFF and ON again, setting is now memo-
rized.
2. RF-AGC Cut-in Adjustment (I2C BUS)
4. G2 Adjustment
1. Apply mains voltage of 220 V AC/50 Hz to TV.
2. Receive Phillips pattern signal to a level between 60
and 80 dBj^V.
3. Set contrast to 10/10, brightness to 5/10 and colour
0/10.
4. Adjust focus potentiometer to obtain maximum defi-
nition.
1. Apply mains voltage of 220 V AC/50 Hz to TV.
2. Receive MONOSCOPE PATTERN signal to a level
between 60 and 80 dB^V.
3. Enter into Service Mode. Press the TEXT key of R/C
and set to level.
4. Set to the point where the raster disappears on the
screen VR of FBT.
8
To Next Page
