Sharp AE-X12ER - Replacement Parts List (AE-X Series - Part 1); Control Box Parts (AE-X); Cabinet and Unit Parts (AE-X)

11
AE-X07ER
AE-X09ER
AE-X12ER
REF. NO. PART NO. DESCRIPTION Q'TY CODE
REPLACEMENT PARTS LIST (AE-X07ER / AE-X09ER / AE-X12ER)
CONTROLBOX PARTS
1- 1 CMOTLB078JBEZ Fan moter 1 BL
1- 2 DSGY-B541JBKZ Control board ass’y [AEX07ER] 1 CB
1- 2 DSGY-B531JBKZ Control board ass’y [AEX09ER] 1 CB
1- 2 DSGY-B549JBKZ Control board ass’y [AEX12ER] 1 CC
1- 2-1 QFS-GA050JBZZ Fuse 1 AD
1- 2-2 QFS-GA051JBZZ Fuse 1 AD
1- 2-3 QFS-GA052JBZZ Fuse 1 AD
1- 2-4 QFS-GA058JBZZ Fuse 1 AV
1- 2-5 QFS-GA059JBZZ Fuse 2 AU
1- 2-6 RH-IXA694JBZZ Ipm [AEX07ER] [AEX09ER] 1 BD
1- 2-6 RH-IXA732JBZZ Ipm [AEX12ER] 1 BF
1- 3 QW-VZE511JBZZ Lead wire [AEX07ER] [AEX09ER] 1 AM
1- 3 QW-VZE172JBZZ Lead wire [AEX12ER] 1
1- 4 RCILZA009JBZZ Reactor 2 BA
1- 5 RTHM-A022JBE0 Thermistor 1 AN
1- 6 QTANZA001JBZZ Terminal board 1 AQ
1- 7 QW-VZE497JBZZ Lead wire 1 AG
1- 8 QW-VZE498JBZZ Lead wire 1 AG
1- 9 QW-VZE499JBZZ Lead wire 1 AF
1- 10 RFIL-A064JBE0 Ferrite core 4 AF
1- 11 RH-HXA029JBZZ Thermistor ass’y1AX
CABINET AND UNIT PARTS
2- 1 LANGKA157JBPZ Motor angle 1 AQ
2- 2 CCAB-A367JBKZ Top plate ass’y [AEX07ER] [AEX09ER] 1
2- 2 CCAB-A368JBKZ Top plate ass’y [AEX12ER] 1
2- 3 TLABCB879JBRZ Wiring diagram [AEX07ER] [AEX09ER] 1 AC
2- 3 TLABCB879JBRZ Wiring diagram [AEX12ER] 1 AC
2- 4 LX-BZA261JBEZ Special screw 4 AC
2- 5 PCOV-A881JBFA Reactor cover [AEX07ER] [AEX09ER] 1 AL
2- 6 LANG-A504JBYZ Reactor angle [AEX12ER] 1 AP
2- 7 CFTA-A268JBKZ Cover 1 AN
2- 7-1 PCOV-A594JBPZ Terminal cover 1 AE
2- 7-2 PFTA-A090JBFA Cover 1 AL
2- 8 PRDAFA170JBEZ Heat sink 1 AR
2- 9 FDAI-A006JBWZ Capacitor angle assy 1 AG
2- 10 LBNDKA105JBWZ Capacitor clamp 1 AD
2- 11 PBOX-A396JBFZ Control box 1 AP
2- 12 PDAI-A138JBWZ Terminal base [AEX07ER] [AEX09ER] 1 AG
2- 12 PDAI-A134JBWZ Terminal base [AEX12ER] 1
2- 13 PCOV-A595JBFZ Cover 1 AE
2- 14 PSKR-A258JBPZ Bulkhead [AEX07ER] [AEX09ER] 1 AH
2- 14 PSKR-A283JBPZ Bulkhead [AEX12ER] 1 AS
2- 15 GCAB-A237JBTA Front panel [AEX07ER] [AEX09ER] 1 AY
2- 15 GCAB-A220JBTA Front panel [AEX12ER] 1 BC
2- 16 GGADPA004JBFA Fan guard [AEX07ER] [AEX09ER] 1 AR
2- 16 GGADPA007JBFA Fan gaurd [AEX12ER] 1 AS
2- 17 JHNDPA015JBFA Handle 1 AD
2- 18 LHLD-A449JBF0 Thermistor holder 1 AH
2- 19 LHLD-A491JBFZ Cord clamp 1
2- 20 LHLD-A492JBFZ Cord clamp base 1
2- 21 MSPR-A026JBE0 Spring 2 AB
2- 22 MSPR-A027JBE0 Thermistor spring [AEX07ER] [AEX09ER] 1 AB
2- 23 MSPR-A036JBE0 Thermistor spring [AEX12ER] 1 AB
2- 24 MSPR-A143JBEZ Spring [AEX12ER] 1 AD
2- 25 NFANPA110JBEZ Propeller fan [AEX07ER] [AEX09ER] 1 AQ
2- 25 NFANPA118JBEZ Propeller fan [AEX12ER] 1 AU
2- 26 PPLT-A370JBTZ Side cover r [AEX07ER] [AEX09ER] 1
2- 26 PPLT-A375JBTA Side cover r [AEX12ER] 1 AW
2- 27 PSPF-A871JBEZ Comp cover top [AEX07ER] [AEX09ER] 1 AF
