AYXP7FR
1 – 1
AYXP7FR
Service Manual
CHAPTER 1. SPECIFICATION
[1] SPECIFICATION
1. AY-XP7FR – AE-X7FR
MODEL INDOOR UNIT OUTDOOR UNIT
ITEMS AY-XP7FR AE-X7FR
Cooling capacity(Min. > Max.) kW 2.1 (0.9 - 2.5)
Heating capacity(Min. > Max.) kW 2.4 (0.9 - 3.4)
Moisture removal(at cooling) Liters/h
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 230
Rated current ✩
(Min - Max.)
Cool A 2.5 (1.0 - 4.1)
Heat A 2.4 (0.9 - 4.5)
Rated input ✩
(Min - Max.)
Cool W 530 (200 - 760)
Heat W 510 (160 - 1100)
Power factor ✩ Cool % 92
Heat % 92
Compressor Type Hermetically sealed rotary type
Model DA89X1F-23F
Oil charge 370cc (VG74)
Refrigerant system Evaporator Louver Fin and Grooved tube type
Condenser Corrugate Fin and Grooved tube type
Control Expansion valve
Refrigerant (R410A) 830g
De-lce system Micro computer controled reversed systems
Noise level
(at cooling)
High dB(A) 37 45
Low dB(A) – –
Soft dB(A) 28 –
Fan system
Drive Direct drive
Air flow quantity
(at cooling)
High m3/min. 8.0 23.2
Low m3/min. 6.8 –
Soft m3/min. 5.5 –
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4"
Drain piping mm O.D φ18
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 790 730
Height mm 278 540
Depth mm 198 250
Net weight kg 10 33
