PART NAMES
1 DUST COLLECTION FILTER
(non-washable)
2 DEODORANT FILTER
(washable)
3 Inlet (Air)
4 Open Panel
5 Air Filters
6 POWER SELECTOR SWITCH
(only for AY-XP13CE)
7 AUX. Button
8 RECEIVER Window
9 Power Supply Cord
0 Indicator Panel
q Vertical Adjustment Louvres
w Horizontal Adjustment
Louvres
e Outlet (Air)
r Remote Control
t OUTDOOR Temp. Lamp
(green
)
y TEMPERATURE INDICATOR
u ROOM Temp. Lamp
(green )
i POWER MONITOR
o PLASMACLUSTER Lamp
(blue,green)
p TIMER Lamp (orange )
a OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
s Inlet (Air)
d Refrigerant Tube and
Interconnecting Cord
f Drainage Hose
g Outlet (Air)
E-3
