AE-X15PU
[5] FLOW CHART OF REFRIGERANT CYCLE
[6] CHARACTERISTIC OF COOLING AND HEATING OPERATION
4 – 3
6-1 AY-XPC15PU / AE-X15PU
6-1-1 COOLING 6-1-2 HEATING
5-2 HEATING5-1 COOLING & DEFROSTING
CAUTION: Indoor fan speed is set to [HIGH].
Airflow direction is initial.
Air inlet temperature of is 80℉ (26.7℃) during COOLING operation, and 70℉ (21.1℃) during HEATING operation.
800
900
1000
1100
1200
1300
65 75 85 95 105 115
POWER CONSUMPTION (W)
OUTSIDE TEMPERATURE（℉)
1100
1250
1400
1550
1700
1850
23 31 39 47 55 63
OUTSIDE TEMPERATURE（℉)
12.0
13.0
14.0
15.0
16.0
17.0
65 75 85 95 105 115
COOLING CAPABILITY (kBTU)
6.0
10.0
14.0
18.0
22.0
26.0
18 28 38 48 58 68
HEATING CAPABILITY (kBTU)
OUTSIDE TEMPERATURE（℉) OUTSIDE TEMPERATURE（℉)
POWER CONSUMPTION (W)
