AYXPC18LR
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] INDOOR UNIT PARTS
1-1 CMOT-A524JBKZ BS Fan Motor Sub Assembly
1-3 PCOV-B593JBFZ AP Motor Cover
1-4 CHLD-A067JBK0 AL Bearing Assembly
1-5 DCHS-A761JBKZ BM Cabinet Sub Assembly
1-6 NFANCA091JBEZ BD Cross Flow Fan
1-7 DSRA-A339JBKZ BF Drain Pan Sub Assembly
1-8 MJNTPA158JBFA AL Louver Link L
1-9 MJNTPA159JBFA AL Louver Link R
1-10 MLOV-A532JBFA AL Vertical Louver
1-11 MLOV-A533JBFA BB Horizontal Louver
1-12 MJNTPA160JBFA AL Motor Joint
1-13 NBRG-A057JBFA AL Holder
1-14 NBRG-A026JBFA AB Louver Bushing
1-16 PHOS-A058JBEZ AX Drain Hose
1-17 LPLT-A058JBPZ AC Hose Holder
1-18 DCOV-A207JBKZ AF Drain Cover Assembly
1-21 CCOV-A327JBKZ AU Cover R Assembly
1-21-1 PCOV-B581JBFA AL Receving Filter
1-21-2 PCOV-B747JBRA AK Cover R
1-21-3 PCOV-B583JBRA AS Cluster Display
1-21-4 PSHE-A278JBEZ AH Sheet
1-22 DCOV-A357JBKZ AK Cover Assembly
1-25 PFILMA250JBEB AN Air Filter
1-26 DHLD-A010JBKZ AK Tube Holder Assembly
1-27 DPNL-A062JBKZ BD Open Panel Assembly
1-28 PPLT-A756JBFZ AL Side Cover L
1-29 PPLT-A666JBFZ AV Side Cover R
1-34 DCOV-A349JBKZ AL Cover Assembly
1-35 DHLD-A049JBKZ AL Holder Assembly
1-36 LHLD-A277JBF0 AD Tube Holder
1-37 RMOT-A192JBZZ AZ Louver Motor
1-41 QW-VZG168JBZZ AP Lead Wire
1-43 TSPC-G721JBRA AK Name Label [18]
1-43 TSPC-G768JBRA AK
Name Label [24]
1-44 TLABCC718JBRZ AK Wiring Diagram
1-52 DWAK-B002JBKZ BB FRONT PANEL Assembly
1-53 PSEL-E004JBEZ AL SEAL
1-54 RMOT-A193JBZZ AZ Louver Motor
1-55 PSEL-E003JBEZ AK Seal
1-56 PSEL-E199JBEZ AH Insulator
1-58 PSEL-E087JBEZ AH Insulator (Attach to 1-28)
1-59 PCOV-B754JBFA AK Cover [18]
1-60 PCOV-B772JBEZ AK Cover
2-2 PBOX-A537JBFA AX Control Box
2-3 CCOV-A283JBKZ BB Control Cover Assembly
2-4 LHLD-B070JBFZ AK Thermistor Holder
2-6 PCOV-B584JBWZ AP Control Cover
2-7 CKITTA133AKKZ BM Plasmacluster Unit
2-10 DSGY-E156JBKZ BT Control Board Unit Main[18]
2-10 DSGY-E161JBKZ BT Control Board Unit Main[24]
2-13 QTANZA039JBZZ AQ Terminal Board (4P)
2-16 LHLD-B033JBFA AK Cord Holder
2-17 LHLD-A539JBFA AE Cord Holder
2-19 RH-HXA148JBZZ AX Thermistor
2-20 PCOV-B585JBFA AL LED Holder A
2-21 LHLD-B030JBFA AL LED Holder B
2-22 LHLD-B031JBFA AP PWB Holder
2-23 PCOV-B588JBWZ AP Terminal Cover
2-24 PCOV-A300JBF0 AB Thermo Holder Cover
2-25 DSGY-E160JBKZ BT Control Board Unit Sub
3-1 CPIPCB413JBKZ BN Tube Assembly[18]
3-1 CPIPCB428JBKZ BK Tube Assembly[24]
3-2 PSEN-A044JBKZ AG Flare Nut Assembly
3-3 PSEN-A053JBKZ AN Flare Nut Assembly
3-4 PVLV-A381JBEZ AN Flare Union (1/4 inch)
3-5 PVLV-A376JBEZ AS Flare Union (1/2 inch) [18]
3-5 PVLV-A379JBEZ AT Flare Union (5/8 inch) [24]
3-7
PSEL-E180JBEZ AG Evaporator seal
3-9 CCYC-C523JBKZ BU Evaporator Assembly [18]
3-9 CCYC-C533JBKZ BU Evaporator Assembly [24]
4-3 DHLD-A037JBKZ AV Cord Holder Assembly
4-7 PPLTNA120JBWZ AZ Mounting Angle
5-1 LX-BZA075JBE0 AA Special Screw
5-2 XTPS740P25000 AC TAPPING SCREW
