Sharp AE-X24LR User Manual

AYXPC18LR
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1-3 LANGKA267JBPZ AY Motor Angle
1-4 LANGKA268JBPZ AP Motor Angle T
1-4-1 PSEL-E186JBEZ AE Angle Top Seal
1-5 GCAB-A409JBTA BE Front Panel L
1-5-1 PSEL-E132JBEZ AK Front Panel L Seal
1-6 GGADFA042JBFA BH Fan Guard
1-7 GCAB-A408JBTA AX Front Panel R
1-8 JHNDPA016JBFA AE Handle
1-10 GPLTMA072JBTA AZ Side Cabinet L
1-11 JHNDPA028JBFA AK Handle
1-12 GPLTMA075JBTA BC Side Cabinet R
1-13 LHLD-A539JBFA AE Cord Holder
1-14 LHLD-B095JBFA AK Cord Clamp Holder
1-15 PSEL-E120JBEZ AK Side Cabinet R Seal
1-16 CSKR-A512JBKZ BA Bulkhead Assembly
1-16-1 PSKR-A372JBPZ AU Bulkhead
1-16-2 PSEL-E135JBEZ AK Bulkhead Seal
1-17 DCAB-A167JBKZ BF Top Plate Assembly
1-17-1 GCAB-A410JBTA BD Top Plate
1-17-2 PSEL-E129JBEZ AK Top Plate Seal A
1-17-3 PSEL-E130JBEZ AN Top Plate Seal B
1-17-4 PSEL-E131JBEZ AK Top Plate Seal C
1-17-5 PSEL-E153JBEZ AK Top Plate Seal D
1-18 PCOV-B739JBFA AN Valve Cover
1-20 LANG-A737JBPZ AL Angle
1-21 LBND-A046JBE0 AE Wire Fixing Band
1-25 NFANPA142JBFA BE Propeller Fan
1-26 PSPF-B173JBEZ AZ Compressor Cover A
1-27 PSPF-B174JBEZ AX Compressor Cover B
1-33 TLABMA565JBRA AQ Inverter Label
1-34 TSPC-G722JBRZ AK Name Label [18]
1-34 TSPC-G769JBRZ AK Name Label [24]
1-35 PSPF-B161JBEZ AY Compressor Cover A
1-36 DCOV-A347JBKZ AW
Side Cover Assembly
1-36-1 LX-BZA461JBEZ AH Special Screw
1-36-2 PCOV-B726JBWZ AM Terminal Cover
1-36-3 PCOV-B740JBFA AN Side Cover 2
1-36-4 PSEL-C051JBEZ AE Side Cover Seal
1-37 PSPF-B162JBEZ AS Compressor Cover C
6-13 LX-NZA378JBEZ AK Special Nut
6-22 LBND-A042JBE0 AC Wire Fixing Band
[5] OUTDOOR UNIT PARTS

Sharp AE-X24LR Specifications

General

Brand	Sharp
Model	AE-X24LR
Category	Air Conditioner
Language	English
