Sharp AF-R125CX User Manual

2
AF-R125CX
Models AF-R125CX
Cooling capacity BTU/h 12000
Moisture removal Pints/h 3.3
ELECTRICAL DATA
Phase Single
Rated frequency Hz 60
Rated voltage Volts 115
Rated current Amps 11.5
Rated input Watts 1200
Power factor % 91
EER BTU/Wh 10.0
COMPRESSOR
Type (Hermetically sealed rotary type)
Model, Remarks 44B124HX1EF, 1000 W
REFRIGERANT SYSTEM
Evaporator Slit fin, Grooved tube, ø 9.53 mm Hair pin
Condenser Louver fin,Grooved tube,7mm Hair pin
Control O.D. x I.D. x Length x Q'ty(mm) Capillary tube 2.7 x 1.2 x 800 x 2
Refrigerant volume R-22(OZ) 19.4 (Factory charged)
NET DIMENSIONS
Width Height Depth inches(mm) 22-1/16(560) x 14-3/4(375) x 24-5/16(617)
Net Weight lbs 85
GROSS DIMENSIONS
Width Height Depth inches(mm) 25-25/32(655) x 18-29/32(480) x 27-7/8(708)
Gross Weight lbs 96
FAN SYSTEM
Indoor side(Evaporator) Centrifugal fan
Outdoor side(Condenser) Propeller fan
Air flow rate(indoor side) CFM (High/Med/Low) 318 / 254 / 219
OTHERS
Safety devices Compressor: Overload relay
Fan motor: Internal thermal protector
Air filter Polypropylene net
Power cord length ft 4.3
Power plug type 125V, 15A
ELECTRICAL PARTS
Running capacitor 370V-50µF
Fan capacitor 250V-6µF x 2
Thermistor 15k at 78˚F
Fan motor ARS030ZUEA/SHP(MLA895)
Overload relay MRA98693-12007
SPECIFICATIONS
