AF-R125CX
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2- 4 QACC-A263JBZZ Power supply cord 1 AT
2- 5 RH-HXA011JBZZ Thermistor 1 AL
2- 6 QW-VZD104JBE0 Lead wire 1 AD
2- 7 QW-IZA036JBZZ Lead wire 1 AS
2- 8 RC-HZA256JBE0 Fan motor capacitor 2 AM
2- 9 RC-HZA407JBZZ Running capacitor 1 AY
2-10 TLABCB377JBRZ Wiring diagram 1 AC
2-11 DPWBFA193JBKZ Control board unit 1 BC
2-12 PSPA-A084JBE0 Spacer 2AC
2-13 PSPA-A085JBE0 Spacer 1AC
2-14 QFS-AA048JBE0 Fuse 1AB
2-15 LBND-A042JBE0 Wire fixing band 4 AC
CYCLE PARTS
3- 1 PCMPRA359JBEZ Compressor 1 CC
3- 2 PPIPCF655JB1Z Discharge tube 1 AR
3- 3 PPIPCF654JB1Z Suction tube 1 AS
3- 4 RHOG-A198JBZZ Overload relay 1 AT
3- 5 DCON-A167JBKZ Condenser ass’y 1 BT
3- 6 PEVA-A424JBEZ Evaporator 1 BQ
3- 7 GLEG-A105JBE0 Compressor cushion 3 BQ
3- 8 LPLTMA114JBW0 Condenser stay 2 AH
3- 9 PCOV-A321JBE0 Terminal cover 1 AR
3-10 PSEL-A971JBE0 Terminal gasket 1 AN
3-11 DCPY-A234JBKZ Capillary tube ass’y 1 AW
3-12 MSPR-A129JBE0 Cycle spring 1 AD
3-13 PGUM-0034JBE0 Damper rubber 1 AF
3-14 MSPR-A136JBE0 Protector spring 1 AF
ACCESSORY PARTS
4- 1 TINSEA320JBRZ Operation manual 1 AD
4- 2 PSEL-A349JBE0 Window insulator 1 AE
4- 3 PSEL-A350JBE0 Window insulator 1 AD
4- 4 PSEL-B365JBE0 Window insulator 1 AD
4- 5 TCAD-A351JBEZ Consummer card 1 AB
4- 6 DX-BZA027JBK0 Screws kit 1 AE
4- 7 CRMC-A526JBEZ Remote control 1 AT
4- 8 LHLD-A389JBFB Controller holder 1 AE
4- 9 SSAKAA017YDE0 Bag 1AC
4-10 UBATUA027JBE0 Battery pack 1 AE
PACKING PARTS
5- 1 CPADBA688YDK0 Top pad ass’y 1 AL
5- 2 CPADBA009JBK0 Bottom pad ass’y 1 AT
5- 3 SPAKCB066JBEZ Packing case 1 AY
5- 4 SSAKHA314YDE0 Protect 1AD
5- 5 PPAK-A007JBE0 Inner packing 1 AG
5- 6 TLABMA333JBRZ Color label 1 AC
5- 7 SSAKAA053YDE0 Bag 1AB
5- 8 TLABMA309JBRZ Feature card 1 AB
SCREWS AND NUTS
6- 1 XTTSD40P12000 Tapping screw 22 AA
6- 2 LX-BZA236JBE0 Special screw 1 AC
6- 3 XHTSD40P08000 Tap tight screw 8 AA
6- 4 LX-NZA136JBE0 Special nut 1 AL
6- 5 LX-HZA001JBE0 Special screw 6 AB
6- 6 XCTSD40P10000 Tapping screw 19 AA
6- 7 LX-NZA074JBE0 Special nut 1 AB
6- 8 LX-NZA028JBE0 Special nut 3 AB
6- 9 XTPSD40P08000 Tapping screw 3 AA
6-10 XCTSD40P06000 Tapping screw 16 AA
6-11 XBPSD40P12J00 Machine screw 2 AB
6-12 LX-CZA038WRE0 Special screw 6 AA
6-13 XHTSD40P10000 Tap tight screw 2 AA
6-14 XTPSD40P12000 Tapping screw 2 AA
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
